PART IDENTIFICATION CHART

Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
is the key number of the part, from the PART LIST on
page 14. The number after the dash indicates the
Handlebar Spacer (39)Ñ2
Weld Spacer (49)Ñ2
Pedal Arm Spacer (41)Ñ3*
Pedal Arm Bushing (42)Ñ4
* Extra parts may be included.
quantity needed for assembly. Note: Some small
parts may have been pre-attached for shipping. If
a part is not in the parts bag, check to see if it has
been pre-attached.
1/4Ó x 3/4Ó Screw (54)Ñ2
1/4" Black Nylon Locknut (55)Ñ2
3/4Ó Axle Cap (43)Ñ4*
5
#8 x 3/4" Round Head Screw (16)Ñ10
3/8" Nylon Locknut (29)Ñ4
5/8Ó Axle Cap (57)Ñ2*
Pivot Bushing (56)Ñ4*
Rear Pedal Arm Bushing (11)Ñ4
