Model No. PFEL87076
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing com-
plete customer satisfaction. If
you have questions, or if there
are missing or damaged parts,
we will guarantee complete
satisfaction through direct
assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Keep this manual for future
reference.
USERÕS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFEL87076 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form PFEL87076

Summary of Contents for Pro-Form PFEL87076

  • Page 1 Patent Pending Model No. PFEL87076 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing com- plete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    ASSEMBLY ................6 HOW TO USE THE PROFORM ¨...

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the PROFORM ¨ 485E. 1. Read all instructions in this manual before using the 485E. 2. Use the 485E only as described in this manual.

  • Page 4: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is PFEL87076. The serial number can be found on a decal attached to the 485E (see the front cover of this manual for the loca- tion of the decal).

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the chart below to identify the small parts used in assembly. The number in parenthesis below each part refers to the key number of the part, from the PART LIST on page 14. The number after the dash indicates M6 x 16mm Screw (54)Ñ2 M6 Black Nylon Locknut (55)Ñ2 Weld Spacer (49)Ñ2...

  • Page 6: Assembly

    ASSEMBLY Assembly requires two people. Place all parts of the PROFORM packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires a phillips screwdriver mallet 1. While another person holds the Upright (3) near the...
  • Page 7 3. Find the Left Pedal (31), which has a ridge on the right side. Attach the Left Pedal to one of the Pedal Arms (12) with three M4 x 19mm Round Head Screws (16) as shown. Repeat this step to attach the Right Pedal to the other Pedal Arm (not shown).
  • Page 8 6. Attach the T-Handle (10) to the Upright (3) with two M6 x 16mm Screws (54) and two M6 Black Nylon Locknuts (55). 7. The Console (6) requires two ÒAAÓ batteries (not included). Alkaline batteries are recommended. To install batteries, first locate the battery clip under the Console (6).

  • Page 9: How To Use The Proform

    HOW TO USE THE PROFORM HOW TO EXERCISE ON THE 485E To mount the 485E, firmly hold the handlebars or the T-handle and carefully step onto the pedal that is in the lowest position. Next, step onto the other pedal.
  • Page 10 DESCRIPTION OF THE CONSOLE The console is designed to help you get the most from your workouts. As you exercise, you can watch your progress around the LED track, while the display provides continuous exercise feedback. The six modes of the display are described below. LED Track SpeedÑThis mode displays your current exercise speed, in miles per hour.

  • Page 11: Maintenance

    MAINTENANCE Inspect and tighten all parts of the PROFORM regularly. Replace any worn parts immediately. The 485E can be wiped clean with a soft cloth and mild detergent. Do not use abrasives or solvents. To prevent damage to the console, keep liquids away from the console.

  • Page 12: Conditioning Guidelines

    CONDITIONING GUIDELINES The following guidelines will help you to plan your exercise program. Remember that proper nutrition and adequate rest are essential for successful results. WARNING: Before beginning this or any exer- cise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems.
  • Page 13 Training zone exercise, consisting of 20 to 30 minutes of exercising with your heart rate in your training zone. (During the first few weeks of your exercise program, do not keep your heart rate in your training zone for longer than 20 minutes.) A cool-down, with 5 to 10 minutes of stretching.

  • Page 14: Part List

    PART LISTÑModel No. PFEL87076 Qty. Description Frame T-Handle Endcap Upright Right Side Shield Left Side Shield Console Foam Handlebar Grip Left Handlebar M8 Lock Washer T-Handle Rear Pedal Arm Bushing Pedal Arm M5 x 16mm Screw Resistance Strap Strap Buckle M4 x 19mm Round Head Screw 1/4Ó...

  • Page 15: Exploded Drawing

    EXPLODED DRAWINGÑModel No. PFEL87076 17 18 R0299A...

  • Page 16: How To Order Replacement Parts

    ¥ The KEY NUMBER and DESCRIPTION of the part(s) from page 14 of this manual. PROFORM is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
