Summary of Contents for Baumatic FG65
- Page 1 Instruction manual...
- Page 3 GAS HOBS USER AND INSTALLATION INSTRUCTIONS...
- Page 4 For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….
- Page 5 CONTENTS General Information page 4 Warning and Safety Instructions page 5 Instructions for Use pages 6–7 Instructions for Installation pages 8–12 Technical Data pages 12–13...
-
Page 6: General Information
When first used, an odour may be emitted by any residual protective finish or moisture, which will cease after a short period of time. As Baumatic have a policy of continued product improvement, the right is reserved to adjust and make any modifications deemed necessary without notification. - Page 7 WARNING and SAFETY INSTRUCTIONS This appliance complies with all current European safety legislation, however Baumatic do wish emphasise that compliance does not remove the fact that surfaces will become hot during use and retain heat after operation. Baumatic therefore strongly advise that babies and young children are prevented from being near or touching the appliance at any time.
-
Page 8: User Instructions
USER INSTRUCTIONS INSTRUCTIONS FOR USE These User Instructions should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance. The following models are covered by these instructions: BK60 BK71 BKWK1 BK61 BK16.5 BK44 BK63 BK16.6... -
Page 9: Helpful Hints
USER INSTRUCTIONS HELPFUL HINTS Always use the correct diameter pan, one that is the same or slightly larger than the flame ring. The flame should never exceed the diameter of the pan. The bottom of the pan should be flat and wherever possible, keep the lid on the pan when cooking. -
Page 10: Instructions For Installation
85°C. PRE-COMMISSIONING THE APPLIANCE When unpacked, check that the following parts are included with the appliance: • Baumatic Ltd Instruction and Installation Book • Pan Supports • Burner Assemblies • Adhesive sealing strip and fixing clamps & screws •... -
Page 11: Installation Notes
INSTALLATION INSTRUCTIONS INSTALLATION NOTES 1. Cut the aperture to the dimensions shown below or use the template if printed on the packaging. 2. Invert the Hob and apply the sealing agent provided to match the outer perimeter edge. 3. If the sealing agent is a strip type, the protective covering must be removed from both sides. -
Page 12: Ventilation Of Rooms
INSTALLATION INSTRUCTIONS VENTILATION OF ROOMS The room in which this appliance is installed must be well ventilated by natural or mechanical means, or a combination of both to ensure correct combustion and the removal of spent air. The minimum quantity of air for combustion will depend on the room volume, number of appliances and their total power rating. -
Page 13: Electrical Connection
In order to adjust the minimum gas flow proceed as follows: • Ignite the burner and turn down to the minimum setting. • Remove the control knob from the gas tap. • Adjust the flow either clockwise to decrease or anti-clockwise to increase the flame. Use a screwdriver inserted down the gas tap rod or via the screw head adjacent to the rod for models fitted with a Flame Supervision Device. -
Page 14: Maintenance
INSTALLATION INSTRUCTIONS MAINTENANCE Refer back to the retailer the hob has beeen purchased from. Please note that intervention or repair by any unauthorised personnel will invalidate any warranty. Before carrying out any maintenance, disconnect the appliance from the gas and electricity supplies. - Page 15 BURNER TYPES AND POWER INPUTS : kW Model Large Medium Small Fish Total Max / Min Max / Min Max / Min Max / Min Max / Min Max / Min 3.0 / 0.75 1.75 / 0.44 1.0 / 0.3 7.50 BK44/60 3.0 / 0.75...
- Page 16 JET SIZING CONVERSION TABLE: NATURAL GAS / LPG Model Large Medium Small Fish NG/LPG NG/LPG NG/LPG NG/LPG NG/LPG 1.55 / 0.90 1.18 / 0.69 0.90 / 0.53 BK44/60 1.55 / 0.90 1.18 / 0.69 0.90 / 0.53 FG65SS 1.18 / 0.69 0.90 / 0.53 1.60 / 0.97 BK61...
- Page 17 BAUMATIC AUSTRALASIA Ltd distributed through Applico Group Ltd. Private Bag 92-900 Onehunga Auckland New Zealand Phone (09) 574 1077 Fax (09) 574 1051 For further information or any other query please contact the above numbers or visit: www.baumatic.co.nz www.applico.co.nz For service & spare parts please call:...
- Page 18 H01A0484...
- Page 20 Baumatic ® w w w . b a u m a t i c . c o m...
