Specifications - Icom IC-M1V Service Manual

SECTION 1
Frequencycoverage
Mode
Power supply requirement
Usable temperature
Frequency stability
at 5 W
Tx
at 1 W
at maximum audio
Rx
at stand-by
Antenna impedance
Dimensions
(Projections not included)
Weight
(with antenna and BP-215)
RF output power (at 7.4 V DC)
Modulation system
Max. frequency deviation
Spurious emissions
Adjacent channel power
Residual modulation
Audio harmonic distortion
Microphone impedance
Receive system
Intermediate frequencies
Sensitivity
Squelch sensitivity
Adjacent channel selectivity
Spurious response
Intermodulation
Hum and noise
Audio output power ( at 7.4 V)
Audio frequency response
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

EIA-152C/204D
Tx: 156.025 MHz–157.425 MHz
Rx: 156.025 MHz–163.275 MHz
–10 ˚C to +60 ˚C (+14˚F to +140˚F)
± 10 ppm
× ×
52.5(W) 129(H)
65 dB
60 dB
0.35 µV at 12 dB SINAD
0.35 µV
70 dB (typical)
70 dB (typical)
70 dB (typical)
350 mW typical at 10 % distortion
with an 8 Ω load
–3 dB to +1 dB of –6 dB octave from 300 Hz to 3000 Hz
16K0G3E (FM)
BP-215 (7.4 V DC)
1.5 A max.
0.7 A max.
200 mA
20 mA
Type SMA / 50 Ω
×
30(D) mm; 2 ⁄ (W) 5 ⁄
1 16 3 32
285 g; 10.1 oz
5 W / 1 W / 0.5 W (High / Low / Extra low)
Variable reactance frequency modulation
± 5.0 kHz
40 dB
Less than 10 % at 60 % deviation
2 kΩ
Double-conversion super heterodyne
1st: 21.70 MHz, 2nd: 450 kHz
40 dB
1 - 1
EN301-178
Tx: 156.025 MHz–157.425 MHz
Rx: 156.025 MHz–162.025 MHz
–15 ˚C to +55 ˚C (+5˚F to +131˚F)
± 1.5 kHz
×
(H) 1 ⁄ (D) inch (with BP-215)
3 16
250 nW
0.5 µV at 12 dB SINAD
0.5 µV
70 dB
70 dB
68 dB
200 mW at 10 % distortion
with an 8 Ω load
