ELECTRIC FIREPLACE/INSERT
SAFETY INFORMATION AND INSTALLATION MANUAL
FOR MODELS CGEF21A AND VEF21A
Read these instructions completely before beginning
installation. Failure to follow them could cause a heater
malfunction resulting in serious injury and/or property
damage.
WARNING: All electric heaters have hot and arcing or
sparking parts inside. Do not use it in areas where gaso-
line, paint or flammable liquids are or are stored.
WARNING: This heater is tested and listed for use only
with the optional accessories listed in these instruc-
tions. Use of optional accessories not specifically
tested for this heater could void the heater warranty
and/or result in a safety hazard.
This fireplace meets the construction and safety stan-
dards of H.U.D. for application in manufactured housing
when installed according to these instructions.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Keep this manual for future reference.
For more information, visit www.desatech.com
