ELECTRIC FIREPLACE/INSERT
ModELS CGEF32C, VEF32A and ES400
SAFETY INFoRMATIoN ANd INSTALLATIoN MANUAL
Read these instructions completely before beginning
installation. Failure to follow them could cause a heater
malfunction resulting in serious injury and/or property
damage.
WARNING: All electric heaters have hot and arcing or
sparking parts inside. Do not use it in areas where gaso-
line, paint or flammable liquids/vapors are or are stored.
WARNING: This heater is tested and listed for use only
with the optional accessories listed in these instruc-
tions. Use of optional accessories not specifically
tested for this heater could void the heater warranty
and/or result in a safety hazard.
This fireplace meets the construction and safety stan-
dards of H.U.D. for application in manufactured homes
when installed according to these instructions.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.desatech.com
Advertisement
Table of Contents
Related Manuals for Desa CGEF32C
Summary of Contents for Desa CGEF32C
- Page 1 ELECTRIC FIREPLACE/INSERT ModELS CGEF32C, VEF32A and ES400 SAFETY INFoRMATIoN ANd INSTALLATIoN MANUAL Read these instructions completely before beginning installation. Failure to follow them could cause a heater malfunction resulting in serious injury and/or property damage. WARNING: All electric heaters have hot and arcing or sparking parts inside.
-
Page 2: Table Of Contents
TAbLE oF CoNTENTS Safety Information .......... Operating Instructions ......... 7 Listing Approvals ..........3 Cleaning and Maintenance ........8 Product Dimension Specifications ....... 3 Technical Service..........10 Product Identification ........... 3 Wiring Diagrams ..........10 Locating Fireplace ..........4 Replacement Parts .......... -
Page 3: Safety Information
SAFETY INFoRMATIoN PRodUCT dIMENSIoN Continued SPECIFICATIoNS 12. Use this heater only as described in this 15.25 manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury to persons. 13. Avoid the use of an extension cord because the extension cord may overheat and cause a risk of fire. -
Page 4: Locating Fireplace
Figure 3 illustrates a variety of ways the heater may LoCATING FIREPLACE be located in a room. The heater may be installed directly on the floor or raised on a hearth. WARNING: Due to high tem- peratures, this heater should be located out of traffic. -
Page 5: Installation
LoCATING FIREPLACE CAUTION: Provide adequate Continued clearances around the air open- FRAMING ings and adequate accessibility Figure 4 shows a typical framing of this heater us- clearances for servicing and ing combustible materials. All required clearances to combustibles must be adhered to. Header height proper operations. - Page 6 This fireplace must INSTALLATIoN Unit to be hardwired: be installed by a qualified (certified or li- Continued censed) service person. It can be wired for 120 V 1600 W or 240 V 3000 W (see Wiring Diagram, page 10). WARNING: If the information in these instructions is not fol- lowed exactly, a fire or explosion WARNING: The solid fuel/gas...
-
Page 7: Finishing
1. Plug in your electric fireplace. FINIShING 2. Main ON/OFF power Switch and LED: Materials Combustible Finishing Material: This switch is located on the left side of made of or surfaced with wood, compressed paper, the control panel. The power LED will plant fibers, plastics or any material capable of light up when the unit is on (see Figure 5). -
Page 8: Cleaning And Maintenance
oPERATING CLEANING ANd INSTRUCTIoNS MAINTENANCE Continued WARNING: Always discon- 6. The HEATER button activates the heater, The heater is pre-set to the following nect power and allow the heater temperatures: to cool before performing any HI will shut off when room reaches approxi- cleaning, maintenance or reloca- mately 86°... -
Page 9: Bulb Replacement
CLEANING ANd Glass MAINTENANCE Brackets Continued BULB REpLACEMENT WARNING: The halogen light bulbs in your unit can become extremely hot. Allow at least 10 minutes between turning off the Bulbs heater and removing the light Figure 7 - Ember Bed Bulb Location bulbs to avoid accidental burns. -
Page 10: Technical Service
CLEANING ANd REPLACEMENT PARTS Note: Use only original replacement parts. This MAINTENANCE will protect your warranty coverage for parts Continued replaced under warranty. 10. Repeat steps 8 and 9 for second bulb. 11. Insert bottom edge of removed cylinder half pARTS UNDER WARRANTy into bottom drum track. -
Page 11: Troubleshooting
TRoUbLEShooTING WARNING: Turn off appliance and let cool before servicing. Only a qualified service person should service and repair heater. OBSERVED pROBLEM pOSSIBLE CAUSE REMEDy Fireplace turns off and will not 1. Fireplace has overheated 1. Reset switch by turning main turn on and safety devise has cause power switch off and waiting... -
Page 12: Illustrated Parts Breakdown
ILLUSTRATEd PARTS bREAkdoWN MODELS CGEF32C, VEF32A AND ES400 www.desatech.com 119635-01B... -
Page 13: Parts List
PARTS LIST MODELS CGEF32C, VEF32A AND ES400 This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on page 10 of this manual. pART NO. DESCRIpTION QTy. 117748-01 Blower and Heater Assembly 117757-01 Control Board (3"... - Page 14 NoTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ www.desatech.com 119635-01B...
- Page 15 NoTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 119635-01B www.desatech.com...
-
Page 16: Warranty Information
WARRANTY INFoRMATIoN kEEP ThIS WARRANTY Model Serial No. Date Purchased Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty.
