1. General Information

1.1 FOREWORD
This manual must be read and understood before operating the machine. This will provide a better working knowledge of the
machine, for increased safety and to obtain the best results.

2. Machine Description

2.1

MACHINE IDENTIFICATION

There is a plastic identification plate fixed to the machine, containing the specifications, serial number.
2.2

GETTING TO KNOW YOUR MACHINE

3
2
1
17
1 Lifting handle
2 Handwheel
3 Face plate
4 Spur center
5 Tool rest
6 Live center
7 Tail stock
8 Tailstock handwheel
9 Tailstock spindle locking arm
4
6
7
5
16 15
8
9 10
14
10 Tool rest base
11 Tool holder
12 Motor
13 Lathe bed
14 Tailstock locking lever
15 Switch
16 Tool rest base locking lever
17 Spindle lock
3
13 12
11
