- Page 1 UPStation GXT™ 700-3000 VA 230V ANUAL English / Deutsch / Français / Italiano / Español...
-
Page 2: Important Safety Instructions
Maximum load must not exceed that shown on the UPS rating label. If uncertain, consult your dealer. See Limited Warranty. WHEN REPLACING THE BATTERIES, USE THE APPROPRIATE LIEBERT-APPROVED DISPOSAL OF BATTERIES IS REQUIRED. REFER TO YOUR LOCAL LAWS AND REGULATIONS FOR DISPOSAL REQUIREMENTS. - Page 3 12. Operate UPS only from a properly earthed, 50 Hz or 60 Hz, 208-240 VAC mains supply. Models are available for 100-127 VAC supply voltages. 13. Route power supply cords so they are not walked on or pinched. 14. Never block or insert any object into the ventilation holes or other openings.
-
Page 4: Introduction And System Description
INTRODUCTION AND SYSTEM DESCRIPTION Congratulations on your choice of the UPStation GXT™ Uninterruptible Power System (UPS). It provides conditioned power to microcomputers and other sensitive electronic equipment. Upon generation, AC power is clean and stable. However, during transmission and distribution it may be subject to voltage sags, spikes, or complete power failure which may interrupt computer operations, cause data loss, or even damage equipment. -
Page 5: Major Components
MAJOR COMPONENTS Dynamic Bypass Inverter Rectifier/PFC TVSS OUTPUT INPUT EMI/RFI Filters DC to DC Converter Battery Battery Charger TRANSIENT VOLTAGE SURGE SUPPRESSION (TVSS) AND EMI/RFI FILTERS These UPS components provide surge protection, and filter both electromagnetic interference (EMI) and radio frequency interference (RFI). They minimize any surges or interference present in the mains line and keep the sensitive equipment protected. -
Page 6: General Installation
DC TO DC CONVERTER The DC-DC converter utilizes energy from the battery system and raises the DC voltage to the optimum operating voltage for the inverter. This allows the inverter to operate continuously at its optimum efficiency and voltage, thus increasing reliability. - Page 7 Re-plug the power input cable (A) into mains supply socket. Proceed with step 9.For 3000 VA models, a CEE 19 input cable is supplied. Proceed with the next step. Connect the molded connector of the mains AC input supply cable into the UPS.
-
Page 8: Rack-Mount Conversion Diagrams
4 and 5. Remove display template to change the orientation of the display. You may also rotate the “Liebert UPStation GXT™” plate located at left of display area. NOTE: UPS unit MUST be supported by a shelf, brackets or slide rails on each side. - Page 9 11. Ensure the load equipment is turned off, and plug all loads into the UPS output sockets. 12. For 700-2000 VA models, unplug power input cable from load equipment input socket and plug it into UPS input socket. Re-plug the power input cable into mains supply socket.
- Page 10 OPTIONAL BATTERY CABINET(S) INSTALLATION Up to two optional battery cabinets may be connected to the UPS to provide additional run time. Battery cabinets are designed to be placed on either side or beneath the UPS. Unpack the UPS battery cabinet(s) carefully noting the packing method. Retain the box and packing material for possible future shipment.
- Page 11 FERRITE BEAD INSTALLATION Serial Communications Attach the smaller enclosed ferrite bead clamp to the communication cable as shown in the drawing using the following directions: Open the ferrite bead. Place the communication cable inside the ferrite bead grove. Position the ferrite beads as close as possible to the end of the cable that connects to the DB9 connector of the UPS.
- Page 12 UPSTATION GXT™ On/Alarm Silence/ Manual Battery Test Button Off/ Bypass Button 1- Output Receptacles 2- DB-9 Interface Port 3- AC Inlet 4- Intellislot TM Communications Port 5- Circuit Protector or fuse 6- Output Voltage Selector Switches 7- Battery Cable Connector 700/1000 VA 1000/1500 VA Mini-Tower...
-
Page 13: Controls And Indicators
24 hours. After 24 hours, retest the batteries. If the batteries have been retested and the bottom two LEDs still do not illuminate, contact your dealer or Liebert Technical Support (LTS) for a battery replacement kit. -
Page 14: Operation
UPS On Indicator (Green) The UPS On indicator is illuminated when the UPS inverter is operating and supplying power to your connected loads. Battery Indicator (Amber)The Battery indicator is illuminated when the UPS is operating from the battery system. AC Input Indicator (Green) The AC Input indicator is illuminated when mains power is available and within the input specification. - Page 15 BATTERY MODE OPERATION Battery mode occurs in event of an extreme input voltage condition or complete mains failure. The battery system supplies power through the DC-DC converter to the inverter to generate power for the connected load. During battery mode an alarm sounds every 10 seconds. This will change to 2 beeps every 5 seconds when battery runs low (approximately 2 minutes remaining).
-
Page 16: Communications Interface Port
Monitoring of the UPS via a computer system is easily made with a Liebert SiteNet® 1 shutdown kit (sold separately). -
Page 17: Ups Intelligent Communications
Periodic tests of battery quality and replacement notification Timed and delayed shutdown of the UPS Logging of power disturbances and anomalies Consult your local Liebert sales representative for more information about SiteNet® 2 software. UPS INTELLISLOT™ COMMUNICATIONS The UPStation GXT™ UPS contains an Intellislot™ communications port for the optional internal Ethernet SNMP card. -
Page 18: Battery Replacement Procedures
Do not dispose of batteries in a fire, the batteries may explode. If you feel unqualified to replace the batteries, do not open the battery door. Call Liebert Technical Support (LTS). numbers are located at the end of this section. - Page 19 Carefully stand the UPS upright. Connect the UPS to the mains supply socket and turn on the UPS by pressing the on button. The UPS is ready for normal operation. Dispose of batteries in accordance with your local laws and regulations. FOR 1000 TO 3000 VA RACK/TOWER MODELS: CAUTION: The battery assembly is heavy.
- Page 20 RACK / TOWER BATTERY REPLACEMENT Rear View Two front rubber feet Top cover screws w/top cover removed Front bezel (cover) Large battery door Screw hidden by small battery door Large battery door Flange screws Aerial View Small battery door Battery connector...
- Page 21 UPSTATION GXT BATTERY RUN TIMES (Discharge times are at 25° C ambient) Internal Battery (minutes) Load% 700MT 1000MT 100% Internal Battery + 1 External Battery Cabinet (minutes) Load% 700MT 1000MT 100% Internal Battery + 2 External Battery Cabinets (minutes) Load% 700MT 1000MT 100%...
-
Page 22: Audible Alarm Conditions
AUDIBLE ALARM CONDITIONS CONDITION Battery mode (utility failure) Low battery Output overload (bypass) Over temperature (bypass) DC Bus overvoltage (bypass) Control power supply failure (bypass) PFC failure (bypass) Inverter failure Battery Test failure Input Fuse Fuse Holder Install ALARM One short beep every ten seconds; more than two minutes of run time remaining Two short beeps every five seconds;... -
Page 23: Troubleshooting
5 minutes while battery charger is not operational. If a problem persists consult your dealer, or contact Liebert Technical Support (LTS). World Wide Technical Support numbers are located at the end of this section. -
Page 24: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM UPS fails to start when on button is pressed Battery indicator is illuminated UPS has reduced battery time Fault and Bypass indicators and all load level LEDs are illuminated Fault and Bypass indicators and diagnostic LED A are illuminated Fault and Bypass indicators and diagnostic LED B are illuminated... -
Page 25: Specifications
MODEL NUMBER MODEL RATING VA/W DIMENSIONS: mm (in) Unit W x D x H Shipping W x D x H WEIGHT: kg (lbs) Unit Shipping INPUT AC PARAMETERS Voltage Range (typical) 100% - 70% Loading 70% - 30% Loading 30% - 0% Loading Frequency Input connector OUTPUT AC PARAMETERS... - Page 26 MODEL NUMBER MODEL RATING VA/W DIMENSIONS: mm (in) Unit W x D x H Shipping W x D x H WEIGHT: kg (lbs) Unit Shipping INPUT AC PARAMETERS Voltage Range (typical) 100% - 70% Loading 70% - 30% Loading 30% - 0% Loading Frequency Input connector OUTPUT AC PARAMETERS...
- Page 27 MODEL NUMBER MODEL RATING VA/W DIMENSIONS: mm (in) Unit W x D x H Shipping W x D x H (13.38 x 26.0 x 22.25) WEIGHT: kg (lbs) Unit Shipping INPUT AC PARAMETERS Voltage Range (typical) 100% - 90% Loading 90% - 70% Loading 70% - 30% Loading 30% - 0% Loading...
-
Page 28: Battery Cabinet Specifications
BATTERY CABINET SPECIFICATIONS MODEL NUMBER Used w/ UPS Model DIMENSIONS: in (mm) Unit W x D x H Shipping W x D x H WEIGHT: lbs (kg) Unit Shipping BATTERY PARAMETERS Type # of Strings x Qty/Str. x 2x3x12Vx7.0 or 7.2 AH Batt. -
Page 29: Limited Warranty
(4) to six (6) months when not in use. If the UPS fails to conform with the above warranty within the two year warranty period, Liebert will repair or replace the UPS, at Liebert's option. Repairs or replacements are warranted for the remainder of the original warranty period. -
Page 30: Technical Support
Outside the U.S.A. Worldwide FAX tech support The Company Behind The Products With more than 500,000 installations around the globe, Liebert is the world leader in computer protection systems. Since its founding in 1965, Liebert has developed a complete range of support...
