Summary of Contents for BIG ASS FANS Haiku 60

  • Page 1 Installation Guide...
  • Page 2 Installation Guide: Jan. 2014 Rev. N Model Number: K3150-A2 S3150-A2 May be protected by one or more of the following patents: www.bigasssolutions.com/patents Haiku and the Haiku logo are trademarks of Delta T Corporation, registered in the United States and/or other countries.
  • Page 3: Fan Assembly

    Securing the safety cable Operating the light Reversing fan rotation Fan mode indicators FAN MOUNTING (CONCRETE CEILING) TROUBLESHOOTING Preparing the ceiling hook Hanging the fan General troubleshooting Securing the safety cable MAINTENANCE Annual maintenance HAIKU ® by Big Ass Fans...
  • Page 4: Important Safety Instructions

    IMP O RTA N T S AF E TY I NST RU CT IO N S Read and save these instructions prior to installing and operating your Haiku. Retain this installation guide for maintenance and troubleshooting information. If you have further questions, contact Haiku Customer Service at www.haikufan.com/service.
  • Page 5: Technical Specifications

    STYLE. Backed by the engineering resources of Big Ass Fans, the fan of choice for smaller spaces that need extraordinary air movement is crystal clear—it’s Haiku.
  • Page 6: Parts And Hardware

    INTRODUCTION (CONT.) Parts and hardware If you are missing any parts or hardware required for the installation or operation of your Haiku, contact Haiku Technical Service. Note: Drawings below are not to scale. Rubber bushing Mounting hardware Airfoil hardware • M8 Bolt •...
  • Page 7 • Concrete ceiling mounting: Install the fan where there is a ceiling hook or other sufficient structural support in the ceiling. If there is no ceiling hook at the fan site, the optional hanger plate can be installed. The concrete mounting method is not available in North America. HAIKU ® by Big Ass Fans...
  • Page 8: Tools Needed

    PREPARATION (CONT.) Tools needed You will need the following tools to install the fan. If you are installing an outlet box, additional tools may be necessary. Consult the outlet box manufacturer’s instructions. • Ladder • Wire stripper • #1 Phillips screwdriver •...
  • Page 9 Be careful not to damage the circuit board while installing airfoils! Haiku ® Bamboo Haiku ® tip! To ease airfoil installation, the (3) motor top screws can be loosened. Do not forget to retighten them! Motor top screw HAIKU ® by Big Ass Fans...
  • Page 10 FAN ASSEMBLY (CONT.) Step 2. Installing the lower cover If you purchased the wall control kit or LED light kit, proceed to the instructions included with the kit. If installing both kits, install the wall control kit first. Return to these instructions once the kits are installed.
  • Page 11: Step 4. Attaching The Mounting Bracket

    If you have concerns about installing the safety cable, consult a structural engineer. Proceed to Step 7. Wiring the fan on page 10. HAIKU ® by Big Ass Fans...
  • Page 12 FAN M O UN TIN G ( CON C R ET E C E ILI N G ) The concrete mounting method is not available in North America. Step 4. Preparing the ceiling hook Seat the rubber bushing inside the eye of the ceiling fan hook as shown.
  • Page 13 Step 5. Securing the safety cable Loop the safety cable around the ceiling hook and through the anchor hook. Secure it with the locking pin. Proceed to Step 7. Wiring the fan on the following page. ® HAIKU by Big Ass Fans...
  • Page 14: Step 7. Wiring The Fan

    E l ec t ri c al CAUTION: Disconnect power to the fan location before wiring the fan! Step 7. Wiring the fan With the fan hanging from the safety cable, connect the fan wires to the EMI filter (if used) and the ceiling wires by twisting the ends together and securing them with wire nuts or a terminal strip.
  • Page 15: Wire Color Chart

    *Special Note: If installing the fan in Australia, a licensed electrician must perform the electrical installation. AC Hot / L1 Switched 100–240VAC 1 Ф , AC Neutral / L2 50–60Hz, 0.36A PE / Earth Ground HAIKU ® by Big Ass Fans...
  • Page 16 ELECTRICAL (CONT.) Wiring diagram (with EMI filter) Ensure power is disconnected before installing the fan! If the EMI filter is included with your fan (country dependent), install it with your fan. Do not use the fan with a dimmer switch. WARNING: Do not connect the fan to a damaged power source! Do not attempt to resolve electrical failures on your own.
  • Page 17 Wire Color Green with Yellow Tracer Southeast Asia Brown, Black, or Grey Blue Green with Yellow Tracer 220–240V System PE/Earth Ground AC Neutral / L2 AC Hot / L1 Switched 220–240VAC 1 , 50Hz, 0.36A HAIKU ® by Big Ass Fans...
  • Page 18: Operation

    Op e rati on Before using the Haiku remote control, remove the plastic tab in the battery tray. The fan mode indicators are located on the underside of the fan hub when tip! viewed from the floor. Remote Front Powering the fan To turn the fan on or off, press the On/Off button on the fan remote.
  • Page 19: Operating The Light

    Timer mode indicator The Timer LED indicates that Timer mode is active. A flashing Timer LED sleep indicates that the Timer mode is being adjusted. See the previous page for instructions on using Timer mode. timer HAIKU ® by Big Ass Fans...
  • Page 20: General Troubleshooting

    Tro u b l e sh ooting WARNING: To avoid electric shock, remove power from the fan before servicing! WARNING: Risk of fire, electric shock, or injury to persons during cleaning and servicing! WARNING: Do not operate fan with missing or damaged components! General troubleshooting Some issues can be resolved before requesting service.
  • Page 21: Annual Maintenance

    • If the fan is mounted to a concrete ceiling and the hanger plate accessory was installed, make sure the anchor bolts, anchor hook, and safety cable are secured. Outlet Box Mount Outlet Safety cable Wiring cover Wiring cover trim Airfoil Concrete Ceiling Mount Safety cable Wiring cover Wiring Airfoil cover trim HAIKU ® by Big Ass Fans...
