- Page 1 HAIKU ® Installation Guide Guide d’installation Guía de instalación bigassfans.com...
-
Page 2: Table Of Contents
CONTENTS Specifications....................1 Before You Start .................... 2 Universal Mount Installation ..............6 Low Profile Mount Installation..............24 Troubleshooting ..................35 Maintenance ....................37 Contact Us ....................38 Rev. D 05/08/2023 READ AND SAVE THESE INSTRUCTIONS... -
Page 3: Specifications
SPECIFICATIONS Universal Mount MK-HK4-042406, MK-HK4-041806, MK-HK4-042506, MK-HK4-052406, MK-HK4-051806, MK-HK4-052506, Models MK-HK4-071806, MK-HK4-071906, MK-HK4-04240601, MK-HK4-04180601, MK-HK4-05240601, MK-HK4-05180601, MK-HK4-07180601 Mounting Sloped or flat ceilings from 9 to ≥14 ft (2.7 to ≥4.3 m) Input Voltage 100–240 VAC, 1 Φ, 50–60 Hz Maximum Weight 26 lb (11.8 kg) Low Profile Mount MK-HK4-042400, MK-HK4-042500, MK-HK4-052400,... -
Page 4: Before You Start
BEFORE YOU START Turn O Power at Breaker Contact an electrician if you are uncomfortable performing electrical work. A licensed electrician must install the fan if required by local code. Gather Tools Prepare Fan Site and Gather Hardware CAUTION Do not use the fan with a dimmer switch. Outlet Box*: Make sure your outlet box is suitable for fan support. - Page 5 BEFORE YOU START Check Ceiling Slope (Universal Mount) Consult the table below to make sure you have the appropriate downrod length for your ceiling slope. Universal Mount fans can be installed on flat or sloped ceilings with an angle no greater than 33° (approximately 8:12 roof pitch). For minimum clearance guidelines, consult the Important Safety Instructions booklet included with this installation guide.
- Page 6 BEFORE YOU START Prepare Concrete Ceiling (if applicable) Universal Mount Drill three Ø 8 mm holes in the pattern shown (Fig. 1). The hole depth should not exceed 46 mm (Fig. 2). Remove dust from holes. Insert anchor bolts* into holes. Strike the heads of the anchor bolts with a hammer, ensuring bolt sleeves are flush with ceiling surface.
- Page 7 BEFORE YOU START Low Profile Mount Drill four Ø 8 mm holes in the pattern shown (Fig. 1). The hole depth should not exceed 46 mm (Fig. 2). Remove dust from holes. Insert anchor bolts* into holes. Strike the heads of the anchor bolts with a hammer, ensuring bolt sleeves are flush with ceiling surface.
-
Page 8: Universal Mount Installation
UNIVERSAL MOUNT INSTALLATION For Low Profile Mount installation, see page 24. Install fan stabilizer in covered outdoor locations on flat ceilings only. An EMI filter (not shown) is included for certain regions and fan diameters. If the EMI filter is included, install it with your fan. The lower cover is shipped attached to the motor unit to protect the fan’s internal electronics during installation. - Page 9 UNIVERSAL MOUNT INSTALLATION Hardware included Airfoil Hardware–Step 1 Grommet M5 Screw Lower Mounting Hardware–Step 2 M6 x 32 mm Bolt M6 Nut Lower Mounting Hardware–Step 3 M4 x 10 mm Screw M4 Lock Washer Upper Mounting Hardware–Step 8 6 mm Steel Pin 4 mm Screw Wedge Fan Stabilizer Hardware*–Step 12...
- Page 10 UNIVERSAL MOUNT INSTALLATION 1. Install airfoils Make sure the sticker color on each airfoil matches the corresponding sticker color on the motor unit. Moving clockwise, slide each airfoil edge under the lower cover, align the mounting holes with the holes on the motor unit, and secure with the airfoil hardware. Make sure the grommets are positioned correctly in the holes (Fig.
- Page 11 UNIVERSAL MOUNT INSTALLATION 2. Install downrod No Uplight If not installing an uplight, align holes on downrod with holes on motor bracket. Position downrod wiring harness so that it is on the same side of the motor shaft as the motor unit wiring harness.
- Page 12 UNIVERSAL MOUNT INSTALLATION 3. Install lower safety cable and ground wire Install safety cable and ground wire lugs with unpainted screws and lock washers (Fig. 3). Fig. 3 M4 Lock Washer M4 x 10 mm Screw Safety Cable Ground Wire (Green/Yellow) 4.
- Page 13 UNIVERSAL MOUNT INSTALLATION Skip this step if you are not installing an uplight. If you purchased the UV-C option, install the UV-C LED boards on the uplight before installing the uplight on the fan. Refer to the instructions packaged with the UV-C LED boards. Align rectangular cutouts in center of uplight with bolts on downrod.
- Page 14 UNIVERSAL MOUNT INSTALLATION 5. Connect wiring harnesses No Uplight If not installing an uplight, connect downrod wiring harness to motor unit wiring harness (Fig. 5a). Fig. 5a Downrod Wiring Harness Motor Unit Wiring Harness Uplight Tighten the two set screws at top of uplight. Connect uplight wiring harness to motor unit wiring harness.
- Page 15 UNIVERSAL MOUNT INSTALLATION 6. Reduce slack Make sure all hardware is secure, and then gently tug cables at top of downrod to reduce slack (Fig. 6). Make sure rubber plug at top of downrod stays in place. Fig. 6 7. Position wiring cover and canopy Slide wiring cover down the downrod, resting it on the motor unit or uplight.
- Page 16 UNIVERSAL MOUNT INSTALLATION 8. Install mounting ball Do not over-tighten the mounting ball screw. Slide mounting ball over downrod (Fig. 8.1). Insert 6 mm steel pin into hole at top of downrod, and then slide the mounting ball upward, seating the steel pin in the inner slots (Fig. 8.2). Insert wedge into mounting ball and secure with screw (Fig.
- Page 17 UNIVERSAL MOUNT INSTALLATION 9. Install mounting bracket WARNING Disconnect power to fan location before installing mounting bracket. Mount only to an outlet box marked acceptable for fan support. Secure mounting bracket to mounting structure with suitable hardware (not supplied) (Fig. 9). Outlet box shown. Your mounting structure may di er. Mounting bracket power supply omitted from illustration for visual clarity.
- Page 18 UNIVERSAL MOUNT INSTALLATION 11. Wire fan WARNING Disconnect power to fan location before wiring fan. Do not connect fan to a damaged power source. Do not attempt to resolve electrical failures on your own. Consult a qualifi ed electrician if uncertain of the electrical installation of this fan.
- Page 19 UNIVERSAL MOUNT INSTALLATION Fig. 11a: Wiring Diagram (No EMI Filter) AC HOT/L1 AC NEUTRAL/ PE/EARTH GROUND BROWN GREEN & YELLOW BLUE Mounting Bracket Safety Cable Power Supply Wiring Harnesses...
- Page 20 UNIVERSAL MOUNT INSTALLATION Fig. 11b: Wiring Diagram (With EMI Filter) The EMI fi lter is included only for certain regions and fan diameters. AC NEUTRAL/ AC HOT/L1 PE/EARTH GROUND BROWN BLUE EMI Filter GREEN & YELLOW Mounting Bracket Safety Cable Power Supply Wiring Harnesses...
- Page 21 UNIVERSAL MOUNT INSTALLATION 12. Install fan stabilizer (if included) Fan stabilizer is included only with damp-rated fans. Install stabilizer in covered outdoor locations on fl at ceilings only. Position stabilizer into notches on top of mounting ball (Fig. 12.1). Secure stabilizer plate to stabilizer with fan stabilizer hardware (Fig. 12.2). Stabilizer Mounting Ball Fig.
- Page 22 UNIVERSAL MOUNT INSTALLATION 13. Secure safety cable Some local safety codes require the safety cable to be secured directly to an existing part of the building structure (Canada, Singapore). It may be necessary to install additional structural material to provide attachment points.
- Page 23 UNIVERSAL MOUNT INSTALLATION Building Structure (not applicable for Singapore) Loop safety cable around building structure and secure with shackle (Fig. 13c). Acceptable building structures include a wooden beam or a metal mounting brace secured between two beams. In some cases, it may be necessary to install additional structural material to provide attachment points.
- Page 24 UNIVERSAL MOUNT INSTALLATION 15. Install downlight (optional) CAUTION To reduce the risk of electric shock, disconnect power to fan before installing downlight. Remove lower cover from bottom of motor unit by twisting counterclockwise (Fig 15.1). Save the lower cover. Reinstall it if you later uninstall the downlight. Plug downlight wiring harness into receptacle on bottom of motor unit.
- Page 25 To change the LED color (uplight only) or color temperature or to turn on the uplight’s UV-C option (if installed), download the Big Ass Fans mobile app. Note: The UV-C option will only turn on while the fan is spinning.
-
Page 26: Low Profile Mount Installation
LOW PROFILE MOUNT INSTALLATION For Universal Mount installation, see page 6. Use the two downtube screw caps that match the color of your fan. The lower cover is shipped attached to the motor unit to protect the fan’s internal electronics during installation. Mounting Plate Wiring Cover Wiring and Safety Cable... - Page 27 LOW PROFILE MOUNT INSTALLATION Hardware included Airfoil Hardware–Step 1 Grommet M5 Screw Mounting Hardware–Step 4, Step 8 6 mm Nylock Nut Safety Cable Shackle–Step 6 Shackle Wiring Cover Screws and Downtube Screw Caps–Step 9 5/16" Screw* Downtube Screw Cap** *One spare screw is included. **Use the two screw caps that match the color of your fan.
- Page 28 LOW PROFILE MOUNT INSTALLATION 1. Install airfoils Make sure the sticker color on each airfoil matches the corresponding sticker color on the motor unit. Moving clockwise, slide each airfoil edge under the lower cover, align the mounting holes with the holes on the motor unit, and secure with the airfoil hardware. Make sure the grommets are positioned correctly in the holes (Fig.
- Page 29 LOW PROFILE MOUNT INSTALLATION 3. Install mounting plate WARNING Disconnect power to fan location before installing mounting plate. Mount only to an outlet box marked acceptable for fan support. Secure mounting plate to mounting structure with suitable hardware (not supplied) (Fig. 3).
- Page 30 LOW PROFILE MOUNT INSTALLATION 5. Hang fan Raise fan to mounting plate and temporarily rest one rubber bumper in the space between the mounting bracket and mounting plate (Fig. 5). Fig. 5 6. Secure safety cable Two people are recommended for this step, or the fan should be placed upright on a stable surface during this step to allow both hands to be free for securing the safety cable.
- Page 31 LOW PROFILE MOUNT INSTALLATION Mounting Plate (not applicable for Singapore) While supporting the fan, loop safety cable around mounting plate and secure with shackle (Fig. 6a). Fig. 6a Safety Cable Mounting Plate Shackle Anchor Hook (applicable for Singapore) While supporting the fan, loop safety cable around anchor hook and secure with shackle (Fig.
- Page 32 LOW PROFILE MOUNT INSTALLATION Building Structure (not applicable for Singapore) While supporting the fan, loop safety cable around building structure and secure with shackle (Fig. 6c). Acceptable building structures include a wooden beam or a metal mounting brace secured between two beams. In some cases, it may be necessary to install additional structural material to provide attachment points.
- Page 33 LOW PROFILE MOUNT INSTALLATION Fig. 7 AC HOT/L1 PE/EARTH GROUND AC NEUTRAL/L2 BLUE GREEN & YELLOW BROWN Supply Power Wire Colors North America Australia All other regions 100–120 V AC Hot/L1 Black Brown or Red Brown Brown AC Neutral/L2 White Black or Light Blue Blue Blue...
- Page 34 LOW PROFILE MOUNT INSTALLATION 8. Secure mounting brackets Raise fan to mounting plate. Insert one rubber bumper between the mounting plate and the loosely installed mounting bracket. Secure the other bumper with the remaining mounting bracket and 6 mm nylock nuts (Fig. 8). Tighten all four nuts with a wrench until snug.
- Page 35 LOW PROFILE MOUNT INSTALLATION 10. Install downlight (optional) CAUTION To reduce the risk of electric shock, disconnect power to fan before installing downlight. Remove lower cover from bottom of motor unit by twisting counterclockwise (Fig 10.1). Save the lower cover. Reinstall it if you later uninstall the downlight. Plug downlight wiring harness into receptacle on bottom of motor unit.
- Page 36 Press Auto to enable motion sensing and automatic fan speed adjustment as room conditions change. To adjust your Auto preferences, download the Big Ass Fans mobile app. To change the downlight’s color temperature, download the Big Ass Fans mobile app. Automate your comfort with SenseME ®...
-
Page 37: Troubleshooting
TROUBLESHOOTING Issue Solution This is normal and may happen occasionally upon The fan jerks upon startup. startup. An initial slight jerking forward and backward does not a ect fan operation. • Make sure the fan is receiving power. Check your circuit breaker or fuse panel and wall switch for functionality. - Page 38 TROUBLESHOOTING Issue Solution Remove the downtube screw caps and locate the pivot bolt on the downtube. Loosen the bolt with a 5 mm hex key to allow the fan to hang straight, and then re-tighten. Reinstall the screw caps. The fan appears slightly tilted.
-
Page 39: Maintenance
MAINTENANCE WARNING Risk of fire, electric shock, or injury to persons during cleaning and user maintenance. Disconnect the appliance from the power supply before servicing. Please take a few moments each year to perform the following preventative maintenance procedures on your fan to ensure its safe and e cient operation. Check the safety cable, hardware, and wiring Check that the safety cable is properly installed by removing the canopy or wiring cover screws, sliding the canopy or wiring cover down the downrod or downtube,... -
Page 40: Contact Us
CONTACT US Canada United States 2180 Winston Park Drive 2348 Innovation Drive Oakville, Ontario L6H 5W1 Lexington, KY 40511 Canada 1 844-924-4277 877-244-3267 bigassfans.com/ca Outside the U.S. (+1 859-233-1271) bigassfans.com Singapore 50 Ubi Crescent Australia #01-01 Ubi TechPark 35 French Street Singapore 408568 Eagle Farm, Brisbane +65 6709 8500...
