Summary of Contents for BIG ASS FANS HAIKU H Series

  • Page 2: Before You Start

    Turn off power at breaker! Wood Ceiling Joist: Attach the mounting bracket directly to the joist using four wood screws (not supplied). Big Ass Fans recommends using corrosion-resistant 12-11 x 45 mm hex ☑ Gather Tools head timber screws with seal.

  • Page 3: Concrete Ceiling

    If required by local building and safety codes, install an anchor hook for the safety cable. Drill an Ø 8 mm hole for the anchor hook adjacent to the hanger plate. The hole depth should not exceed 46 mm. Remove any dust from the hole, and then insert the anchor hook and fully tighten. Ø 8 mm 40.2 mm 95 mm HAIKU® BY BIG ASS FANS...
  • Page 4 Clears active fan timer. Increases fan speed/light brightness. Varies fan speed to simulate a natural breeze. Automatically adjusts your fan speed overnight to Decreases fan speed/light brightness. keep you comfortable while you sleep. REV. B © 2021 BIG ASS FANS ALL RIGHTS RESERVED...

  • Page 5: Installation

    Wiring Cover Trim Motor Hub Airfoils (3) Grommets (6) M5 Screws (6) Lower Cover Use the extension tube screw caps that match the color of your fan. Outdoor Fans Indoor Fans Safety cable not shown. HAIKU® BY BIG ASS FANS...

  • Page 6: Install Mounting Bracket

    Do not fully tighten the hardware. suitable hardware (Fig. 1). Fig. 1 Fig. 2 M6 x 25 mm Screw Mounting Bracket M6 Nut Mount Brace Bracket (2) Rubber Bushing REV. B © 2021 BIG ASS FANS ALL RIGHTS RESERVED...

  • Page 7: Secure Safety Cable

    If required by local safety codes, the safety cable must be secured directly to an existing part of Wiring Cover Trim the building structure. It may be necessary to install additional structural material to provide attachment points. HAIKU® BY BIG ASS FANS...
  • Page 8 Wire the fan as shown in the diagram using the wire connectors (Fig. 5). YELLOW BLUE Fig. 5 BLUE GREEN & BROWN YELLOW AC Hot/L1 Brown Brown AC Neutral/L2 Blue Blue PE/Earth Ground Green with Yellow Green with Yellow REV. B © 2021 BIG ASS FANS ALL RIGHTS RESERVED...
  • Page 9 Twist the fan hub! clockwise to snap the trim into position (Fig. 6). Fig. 7 Fig. 6 Wiring Cover Airfoil Grommet Screw M5 Screw Screw Wiring Cover Trim HAIKU® BY BIG ASS FANS...

  • Page 10: Install Lower Cover

    Loosen the bolt with a 5 mm hex key to allow the fan to hang straight, and Fig. 8 then re-tighten. Indoor Fans Lower Motor Cover Trim Lower Cover Outdoor Fans Lower Cover REV. B © 2021 BIG ASS FANS ALL RIGHTS RESERVED...

  • Page 11: Troubleshooting

    Press and hold the On/Off button until the LED indicators start blinking. I need to reboot the fan. Within three seconds of the LEDs flashing, press the On/Off button again. When the LEDs stop blinking, the reboot is complete. HAIKU® BY BIG ASS FANS...
  • Page 12 NOTES...
  • Page 13 NOTES...
  • Page 14 NOTES...
  • Page 15 Models: S3127-A2, S3127-A2-XX-XX-02-C, S3127-A2-XX-XX-03-C, S3150-A2, S3150-A2-XX-XX-02-C, S3150-A2-XX-XX-03-C, FR127A-A2, FR150A-A2 © 2021 Big Ass Fans The information contained in this document is subject to change without notice. May be protected by one or more patents listed at www.bigassfans.com/patents Haiku is a trademark of Delta T LLC, registered in the U.S. and/or other countries.
  • Page 16 HKU-INST-308-ENG-01...
