Page 2: Before You Start
☑ Select Extension Tube Select the appropriate extension tube for your ceiling height and slope. See page 2 for a guide to select the most appropriate extension tube. READ AND SAVE THESE INSTRUCTIONS HAIKU® BY BIG ASS FANS REV. C 08/26/2020... -
Page 3: Concrete Ceiling
If required by local building and safety codes, install an anchor hook for the safety cable. Drill an Ø 8 mm hole for the anchor hook. The hole depth should not exceed 50 mm. Remove any dust from the hole, and then insert the anchor hook and fully tighten. Ø 6 mm 45 mm 43 mm © 2020 BIG ASS FANS ALL RIGHTS RESERVED... - Page 4 (>4.3 m) * (1524 mm) * (1.5 m) (813 mm) 84 in. 20 in. * Big Ass Fans recommends using an extended length 16° (2.1 m) (508 mm) extension tube for ceiling heights over 13 ft (4 m). The fan 84 in.
- Page 5 Clears active fan timer. Increases fan speed/light brightness. Varies fan speed to simulate a natural breeze. Automatically adjusts your fan speed overnight to Decreases fan speed/light brightness. keep you comfortable while you sleep. © 2020 BIG ASS FANS ALL RIGHTS RESERVED...
-
Page 6: Installation
M6 x 32 mm Bolt M6 Nut Light Motor Hub Airfoils (3) Grommets (6) Lower Cover M5 Screws (6) Safety cable not shown If the EMI fi lter is included, install it with your fan. HAIKU® BY BIG ASS FANS REV. C 08/26/2020... -
Page 7: Install Lower Cover
(Fig. 1). Make sure the sticker color on each airfoil matches the corresponding sticker color on the fan hub! Fig. 1 Fig. 2 Lower Cover M5 Screw Grommet Airfoil © 2020 BIG ASS FANS ALL RIGHTS RESERVED... - Page 8 (Fig. 3.1). Make sure the extension tube is not tilted and is perpendicular to the motor hub. Connect the wiring harness from the extension tube to the receptacle from the motor hub (Fig. 3.2). Fig. 3.1 Fig. 3.2 M6 Nut M6 x 32 mm Bolt Wiring Harness HAIKU® BY BIG ASS FANS REV. C 08/26/2020...
- Page 9 Make sure all hardware is secure, and then gently tug the cables at the top of the extension tube to reduce slack. Orient the remaining loose wiring receptacle from the motor hub upward as shown (Fig. 4.2). Fig. 4.1 Fig. 4.2 Ground Wire (Green) Safety Cable Lock Lock Washer Washer Screw © 2020 BIG ASS FANS ALL RIGHTS RESERVED...
- Page 10 WARNING: Skin or eye damage may result from directly viewing ultraviolet light produced by the lamp in this apparatus. Always disconnect power before relamping or servicing. Replace ultraviolet LEDs with Model No. 1050-39-30, manufactured by Big Ass Fans. Slide the light down the extension tube, resting it on the fan hub. Orient the light so that the tab at the top of the light rests in the groove at the top of the motor bracket (Fig.
- Page 11 Slide the wiring cover down the extension tube, resting it on the light. Make sure no wires are visible between the wiring cover and light. Slide the canopy down the extension tube, resting it on the wiring cover (Fig. 6). Fig. 6 Canopy Wiring Cover © 2020 BIG ASS FANS ALL RIGHTS RESERVED...
- Page 12 Insert the wedge into the mounting ball and secure it with the screw. Tighten the screw enough to prevent movement between the mounting ball and extension tube, but do not over-tighten (Fig. 7.3). Fig. 7.1 Fig. 7.2 Fig. 7.3 Screw Mounting Wedge Ball 6 mm Steel Pin Extension Extension Tube Tube HAIKU® BY BIG ASS FANS REV. C 08/26/2020...
-
Page 13: Install Mounting Bracket
Outlet box shown. Your mounting structure may diff er from the illustration. Fig. 8 Fig. 9 Mounting Bracket Mounting Mounting Bracket Ball Suitable Mounting Hardware © 2020 BIG ASS FANS ALL RIGHTS RESERVED... -
Page 14: Wire The Fan
Fig. 10 North America All other regions 100–120 V AC Hot/L1 Black Brown Brown AC Neutral/L2 White Blue Blue PE/Earth Ground Green or Bare Green with Yellow Green with Yellow Copper HAIKU® BY BIG ASS FANS REV. C 08/26/2020... - Page 15 Wiring Diagram Wiring Diagram (No EMI Filter) (With EMI Filter) BLACK WHITE GREEN & YELLOW BLACK BROWN GREEN & WHITE BLUE YELLOW EMI FILTER BROWN BLUE © 2020 BIG ASS FANS ALL RIGHTS RESERVED...
-
Page 16: Secure Safety Cable
It may be necessary to install additional structural Installation is now complete. Test your fan using the remote material to provide attachment points. control. HAIKU® BY BIG ASS FANS REV. C 08/26/2020... -
Page 17: Troubleshooting
Press and hold the On/Off button until the LED indicators start blinking. I need to reboot the fan. Within three seconds of the LEDs flashing, press the On/Off button again. When the LEDs stop blinking, the reboot is complete. © 2020 BIG ASS FANS ALL RIGHTS RESERVED... -
Page 18: Maintenance And Cleaning
Lights without lens: Clean the LEDs periodically to ensure optimal performance. Use a compressed air duster to remove dust and debris from the LEDs. Do not touch the LEDs while cleaning. Hold the duster can upright when using. HAIKU® BY BIG ASS FANS REV. C...
