Data Fields ................................................................................................................................................................3
656 Enhanced Zone Programming ........................................................................................................................11
656 Enhanced Zone Programming Worksheet ......................................................................................................14
680 Device Programming.......................................................................................................................................16
681 Zone Lists ........................................................................................................................................................17
Powerline Carrier Device Worksheet for 680 and 681 ...........................................................................................18
683 Enhanced Sequential Mode ...........................................................................................................................19
684 Assign Zone Voice Descriptors .......................................................................................................................20
Vocabulary Index (for 684 Assign Zone Voice Descriptors)...................................................................................20
685 Record Custom Voice Descriptors ..................................................................................................................21
5800 Series Transmitter Loop Numbers Diagram ..................................................................................................22
Safewatch QuickConnect Plus Control Defaults.....................................................................................................23
Safewatch QuickConnect Plus Summary of Connections Diagram .......................................................................24
Refer to the Safewatch QuickConnect Plus Installation and Setup Guide P/N 800-03857-4 or later for
detailed information on programming the system. The Installation and Setup Guide contains full
descriptions for all data fields.
Safewatch QuickConnect Plus is not intended for UL985 Household Fire applications unless a 24-
UL
hour backup battery (P/N LYNXRCHKIT-HC or LYNXRCHKIT-SHA) is installed.
To Enter Programming Mode:
You may find it convenient to adjust the volume setting before entering the Programming Mode. This will allow
you to clearly hear feedback announcements or system beeps.
1. Power up, then depress [
OR
Enter: Installer Code (6 + 3 + 2 + 1) plus 8 + 0 + 0. System will display "Entering Program Mode".
Notes: 1. If a different Installer Code has been programmed, enter: the New Installer Code + 8 + 0 + 0.
2. If 98 was previously used to exit programming, the first method shown above must be used to re-
6
enter the program mode)
2. Upon entry into Program mode, data field "20 INSTALLER CODE" will be displayed (the first data field in
the system) and both keypad LEDs will flash.
To Program the Data Fields:
1. Press [ ] followed by the desired field number (e.g.,
6
2. The keypad beeps three times after entering data, then displays the next data field in sequence.
3. For phone number and account number fields, press [
number of digits is entered.
4. To view data entered in field, press [#] plus the field that you wish to view (e.g., #21). The system will beep
three times and data programmed for that field will be displayed to the right of the field number. The system
will scroll through the data for longer numbers and a beep will sound after each number is displayed or
three times after the final digit is displayed.
5. To delete an entry, simply press [
and account number fields
Interactive Menu Modes:
There are six interactive menu modes as listed below. To enter these modes, first enter Program mode. While in
Program mode, press [
6
56 Enhanced Zone Programming .............. For programming zone characteristics, report codes, etc.
6
80 Device Programming ............................. For programming Powerline Carrier Devices
6
81 Zone List Programming ......................... For programming zone lists for use with Powerline Carrier Devices
6
83 Enhanced Sequential Mode .................. For entering transmitter serial numbers
6
84 Assign Zone Voice Descriptors.............. For assigning voice descriptors to zones
6
85 Record Custom Voice Descriptors ........ For recording custom voice descriptors
6

TABLE OF CONTENTS

] and [#] both at once, within 50 seconds of powering up.
6
] plus that field number and reenter the correct data. For phone number
6
40- 44, 88 and
6 6 6
] plus the mode number desired (e.g.,
21), then make the required entry.
6
] to end the entry if less than number maximum
6
94, press [ ] + field number + [
6 6
56).
6
