Download Information - Safewatch QuickConnect Plus Programming Manual

Data Field Display
90 90 90 90
EVNT LOG OPTIONS EVNT LOG OPTIONS
EVNT LOG OPTIONS EVNT LOG OPTIONS
91 91 91 91
AAV/REM PHN AAV/REM AAV/REM AAV/REM PHN CTRL PHN PHN CTRL CTRL CTRL
92 92 92 92
SWINGER SHUTDOWN SWINGER SHUTDOWN SWINGER SHUTDOWN SWINGER SHUTDOWN
DOWNLOAD INFORMATION (693–695)
93 93 93 93
FLEXBLE FLEXBLE FLEXBLE FLEXBLE CALLBACK CALLBACK CALLBACK CALLBACK
94 94 94 94
DOWNLOAD DOWNLOAD DOWNLOAD DOWNLOAD PHONE PHONE PHONE PHONE
#
95 95 95 95
RING DET RING RING RING DET DET COUNT DET COUNT COUNT COUNT
Function& Programming Options
Event Logging
[3]
0 = None; 1 = Alarm/Alarm Restore; 2 = Trouble/Trouble Restore; 4 = Bypass/Bypass
Restore; 8 = Open/Close.
Example: To select "Alarm/Alarm Restore", and "Open/Close", enter 9 (1 + 8); To select
all, enter #15.
Alarm Audio Verification (AAV)/Remote Phone Control
[2]
0 = None
1 = AAV and remote phone control
2 = remote phone control only
4 = AAV only
Notes: (1) In order to activate the Remote Phone Control feature and defeat an answering machine,
ensure that the correct ring detection count ("15") has been programmed in field 695.
(2) Remote phone session will be terminated if a report must be sent.
(3) Alarm Audio Verification will only function when Contact ID® is selected. AAV cannot be
used for UL installations.
(4) If an alarm will be reported to primary and secondary phone numbers, AAV can only
function via the secondary number.
(5) If an alarm will be reported to a follow me phone number (10-12 in field 649) AAV cannot
be used.
(6) If AAV is selected and LRR/IP communications device is enabled, you must enter "0"
(primary dialer preferred channel) as the second entry in Field 677.
Swinger Shutdown
[1]
1 = shutdown after one alarm; 2 = shutdown after two alarms
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value "1", which is displayed on the keypad, and advances to
the next field.
Flexible Callback
[0]
0 = No flexible callback; 1 = Last digit flexible;
2 = Last 2 digits flexible; 3 = Last 3 digits flexible
Download Phone Number
Note: In UL installations, downloading may only be performed if a technician is at the site.
Enter up to 20 digits, 0–9; #+11 for '6'; #+12 for '#'; #+13 for a pause. Do not fill unused
spaces. If fewer than 20 digits entered, pressing 6 advances to the next field. To clear
entries from field, press 6946.
Ring Detection Count for Downloading/Remote Phone Control Mode
[15]
0 = Disable Station Initiated Download
1–14 = number of rings
(1–9, [#]+10 =10, [#] +11 =11, [#] +12 =12, [#] +13 =13, [#] +14 =14);
15 = answering machine defeat ([#] +15 =15)
[ ] = Programmed Table 1 Default Values
Note: System messages are logged when
- 10 -
any non-zero selection is made.
