POWERLINE CARRIER DEVICES WORKSHEET FOR 6 6 6 6 80 and 6 6 6 6 81
Applicable only if Powerline Carrier Devices are to be used, or chime-by-zone feature is used.
UL
Powerline Carrier Devices have not been evaluated by UL.

680 OUTPUT DEVICES

Fill in the required data on the worksheet on below and follow the programming procedure in the Installation
Instructions as you enter the data during the displays and prompts that appear in sequence.
Note: If using P.C.L.D. (X10 devices), Field 625 must be programmed with a House Code.
DEVICE ACTION
NUMBER
P.L.C.D.*†
01
P.L.C.D.*†
02
P.L.C.D.*† 03
P.L.C.D.* 04
P.L.C.D.* †05
P.L.C.D.*†
06
SYS. P.L.C.D.*† 07
SYS. P.L.C.D.*† 08
E-mail event trigger 09
E-mail event trigger 10
E-mail event trigger 11
E-mail event trigger 12
E-mail event trigger 13
E-mail event trigger 14
E-mail event trigger 15
E-mail event trigger 16
Note: If using an X10 Powerhouse Security SH10A Siren as device 08, you must change the action default to "3" if using default table 4.
Where:
A = DEVICE ACTION
ET = EVENT TYPE
Z L = ZONE LIST
ZT = ZONE TYPE/
SYSTEM OPERATION
Note: In normal operation mode:
6 6 6 6 81 ZONE LISTS FOR OUTPUT DEVICES
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter
the data during the displays and prompts that appear in sequence.
Zone List 1: Started or stopped by zone numbers (enter 00 to end entries).
Zone List 2: Started or stopped by zone numbers (enter 00 to end entries).
Zone List 3: Started or stopped by zone numbers AND/OR assignment of Chime zones (enter 00 to end entries)
either or both
EVENT ZONE
TYPE (et) LIST (zl)
(aa)
[2]
[2]
0 = No Response; 1 = Close for 2 sec; 2 = Close and stay closed; 3 = Pulse on and off.
0 = Not used; 1 = Alarm; 2 = Fault; 3 = Trouble.
1, 2, or 3 (from Field 681) or 0 = Not Used.
"START" ZONE LIST: Upon alarm, fault, or trouble of ANY zone on this list, device action will START.
"STOP" RESTORE of ZONE LIST: Upon restore of ALL zones on this list, device action will STOP. It need
not be same list as used for START.
Note: Do not assign zones with types 20, 21, or 22 to a zone list.
Choices for Zone Types are:
00 = Not Used
01 = Entry/Exit#1
02 = Entry/Exit#2
03 = Perimeter
04 = Interior Follower
Note: Any zone in "ZT" going into alarm, fault, or trouble will activate device with the exception of 01, 02
when the system is in alarm. Any zone that restores will stop device action.
Choices for System Operation are:
20 = Arming–Stay
21 = Arming–Away
22 = Disarming (Code + FF)
31 = End of Exit Time
32 = Start of Entry Time
For Devices 01-06:
Function + Lights On + NN
Function + Lights Off + NN
START
ZONE TYPE
SYS OPERATION (zt)
[33]
[33]
05 = Trouble Day/Alarm Night
06 = 24 Hour Silent
07 = 24 Hour Audible
08 = 24 Hour Aux
09 = Fire Zone without Verification
33 = Any Alarm (except ZT=08 or 09)
36 = *At Bell Timeout
38 = Chime
39 = Any Fire Alarm
* Or at Disarming, whichever occurs earlier.
For Devices 07 and 08:
Code + Function + Lights On + NN
Code + Function + Lights Off + NN
- 18 -
STOP
either or both
RESTORE ZONE TYPE/
ZONE LIST (zl) SYS OPERATION (zt)
[36]
[36]
10 = Interior with Delay
14 = Carbon Monoxide
16 = Fire with verification
24= Silent Burglary
40 = Bypassing
42 = System Battery Low
43 = Communication Failure
52 = Kissoff
58 = Duress
NN = 2- digit device number
(Entry starts Device NN)
(Entry stops Device NN)
.etc. [28][32]
.
.etc [29][33]
. etc. [02][03]
