Safewatch QuickConnect Plus Programming Manual page 15

Button Zones
Zone No. Zone
(A 01) Type (zt)
2|6 | [21]
2|7 | [22]
2|8 | [20]
2|9 | [23]
3|0 | [21]
3|1 | [22]
3|2 | [20]
3|3 | [23]
3|4 |
3|5 |
3|6 |
3|7 |
3|8 |
3|9 |
4|0 |
4|1 |
EXPLANATION OF ZONE ASSIGNMENT TABLE HEADINGS
A 01 = ZONE No. Zone Numbers are 01 (wired), 02-25 (RF) only, 26-41 (Button) only, 92 (duress), 95, 96, 99 (panic)
zt = ZONE TYPE
rc = ALARM REPORT CODE
i = INPUT TYPE
l = LOOP NUMBER
6 6 6 6 56 ENHANCED ZONE PROGRAMMING WORKSHEET
Alarm Report Input
Code in hex (rc) Type (i) No. (l)
| | [01 00]
| | [01 00]
| | [01 00]
| | [00 00]
| | [01 00]
| | [01 00]
| | [01 00]
| | [00 00]
| |
| |
| |
| |
| |
| |
| |
| |
00 = Not Used
01 = Entry/Exit #1
02 = Entry/Exit #2
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24 Hr Silent
07 = 24 Hr Audible
08 = 24 Hr Aux
Two Hex Digits. For each Hex Digit, enter: 00–09 for 0–9, 10 for A, 11 for B,12 for C, 13
for D, 14 for E, 15 for F. If "00" is entered as the first digit, there will be no report for that
zone.
For Contact ID reporting, this is enabling code only. Enter any hex digit (other than 00) in
the first pair of boxes. The second pair of boxes is ignored.
Enter 3 for RF: Supervised RF
Enter 4 for UR: Unsupervised RF
Enter 5 for BR: Button Type RF
Used with 5800 RF Loop Input Devices. Record transmitter loop number. Entries are 1-4,
depending on device being used. Refer to the transmitter's instructions for appropriate
loop numbers.
Loop Transmitter
Serial Number
[5] [3
[5] [2]
[5] [4]
[5] [1]
[5] [3]
[5] [2]
[5] [4]
[5] [1]
09 = Fire without Verification
10 = Interior with Delay
14 = Carbon Monoxide
16 = Fire with verification
20 = Arm–Stay
21 = Arm–Away
22 = Disarm
23 = No Alarm Response
24 = Silent Burglary
Zones 2-25 should be assigned as Input Type 3 or 4
and Zones 26-41 should be assigned as Type 5 only.
- 15 -
