Enhanced Sequential Mode - Safewatch QuickConnect Plus Programming Manual

Use this mode to enter transmitter serial numbers. Press 683 while in programming mode.
83 83 83 83
ENHANCD ENHANCD SEQ ENHANCD ENHANCD SEQ SEQ MODE SEQ MODE MODE MODE
A A A A
ZONE NUMBER ZONE ZONE ZONE NUMBER NUMBER NUMBER
1A 1A 1A 1A
ENROLL ENROLL M M M MOD OD OD ODE E E E
ENROLL ENROLL
1 1 1 1 b
SERIAL SERIAL SERIAL NUMBER SERIAL NUMBER NUMBER NUMBER
F F F F
DELETE DELETE DELETE DELETE ZONE ZONE ZONE ZONE CONF CONF CONF CONF

Enhanced Sequential Mode

0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
Zone Number
Enter the 2-digit zone number of the first transmitter to have its serial number entered. The
system will announce the Voice Descriptor for the selected zone if it has been programmed.
[ ] = Continue; system searches for zones not yet entered, (for zones 2 to 25 a zone type
6
must be entered) then advances to SERIAL NUMBER prompt (1b).
00 = Exit Sequential mode, upon which the prompt "83" blinks
Enroll Mode
Enter, View or Confirm Serial Number.
0 = Advance to next unlearned zone.
1 = Enter now and proceed to SERIAL NUMER prompt (1b). For 4-button keys (zones 26-
29, 30-33, 34-37 and 38-41) the serial number will be learned to all four buttons.
2 = copy the previous serial number entry from the buffer.
Note: Before you can copy a serial number you must first enter a serial number. If no serial is stored
in the buffer and a copy is attempted the panel will emit a long beep indicating an invalid
operation.
3 = View existing serial number. (Only if "L" is displayed. If "L" is not displayed, panel will
emit a long beep. Each digit will be displayed and the keypad will beep once for digits 1-6
and three times for last digit.
4 = Copy the 4-button key template set for zones 26 - 29 (includes all zone parameters
except serial numbers). Only valid on 4-button key zones 30-33, 34-37 and 38-41 that do
not have serial numbers learned. (Template acceptance is indicated by two beeps after
copying. A single long beep emitted when copying templates indicates the template is not
valid.)
9 = Delete existing serial number. Go to the (1A) prompt. (For 4-button key zones 26-29,
30-33, 34-37 and 38-41, deletes all four at once.)
[ ] = Advance to the next unlearned zone.
6
[#] = Return to previous prompt (1A).
Serial Number
Enroll transmitter serial number via RF transmission or manually.
RF Learning - Two (2) transmissions (two key depressions) at least five seconds apart will
be required for BR type or four (4) transmissions (fault, restore and fault, restore) for UR or
RF type.
If the learned serial number has a different loop number than that entered in
system will announce the Voice Descriptor, if it is programmed, followed by two beeps and
will return to Prompt (1A) and "LEARNED" will be displayed.
If the loop number captured by RF transmission and that entered in
system will announce the Voice Descriptor, if it is programmed, followed by three beeps
and return to Prompt (1A) and "LEARNED" will be displayed. No additional transmissions
are needed for confirmation.
Manual Entry - Enter the 7-digit serial number printed on the transmitter. If you enter an
incorrect digit, press the [#] key to backup to prompt (1A) and start over. When all 7 digits
are entered, press the [ ] key. If less than 7 digits are entered, the keypad will emit a
6
single long beep and return to the (1A) prompt without displaying "LEARNED". If more
than 7 digits have been entered, the first 6 digits will be saved along with the last digit that
was entered (entering 123456789 yields the serial number 1234569).
Note: If 52 seconds passes and no entry has been made, the system returns to prompt (1A).
Delete Zone Parameters Confirmation
0 = Discard the delete request.
1 = Confirm requested delete
6 6 6 6 83 ENHANCED SEQUENTIAL MODE
.
