VIDEO VBOX MANUAL

Getting Started with your Video VBOX

Logging Modes

The Blue LED will come on when the unit is recording video, this LED will flash when the unit is closing the file.
NOT REMOVE the SD card if the Record LED is on or is flashing.
The Video VBOX has two modes:

Log only when moving (default)

The unit automatically starts logging data when the vehicle speed goes above 2.5km/h, and stops when it goes below
this value. This speed is configurable, see 'Scene propeties'. Pressing the REC button will stop the recording and close
the file.

Manual logging

By pressing the REC button on the front of the unit, the user may override the Automatic logging function. The unit
will then record until the card is full, the power is removed, or until the user presses the REC button once more.
Note : to prevent potential loss of video, the unit will revert back to automatic logging if the car then starts to move
again, or if the SD card is changed.
LED functions – PRO 4 CAM
LED
PWR
CAMERAS 1,2,3 & 4
DATA C
DATA S
USB
GPS
MEMORY
REC
Page | 9
COLOUR
Red
Green
Red
Green
Red
Red / Green
Red
Blue
INDICATES
Power on
A camera is connected
Correctly connected to a device and
receiving CAN signals. Note, must be
configured to receive in VVB setup
software.
Recognised serial information is
being received. E.g. From a
connected DriftBox
USB logging media is connected
i) Red indicates no satellite lock held
ii) Green indicates SAT lock achieved
i) Amount of memory used in the
attached logging media
(incrementing sequence)
ii) Status of scene upload or
firmware upgrade (incrementing
sequence)
iii) Searching for media
(in/out sequence)
Data being recorded to media.
20 October 2010
DO
