VIDEO VBOX MANUAL

Using the OLED display - requirements

Upgrading firmware

Occasionally Racelogic will release new versions of firmware (internal code) for the Video VBOX product, often to
introduce new features. New firmware is loaded into the Video VBOX using an SD card.
Download the latest '.vidup' file from our website :
Copy this file onto an SD card (not into the 'media' folder), and insert into a powered unit. The LEDs will light up in
turn as the update progresses. After a period of up to two minutes, the unit will beep twice and resume operation.
The unit should then be power cycled. The upgrade file will have been deleted, and the scene will change back to the
default, so make sure you retain a copy of the scene previously loaded into the unit.

Upgrading multiple units

To prevent the Video VBOX from deleting the firmware file, create an empty file called 'no-delete-vidup.txt' file on
the SD card in the same directory as the upgrade file, the upgrade file will then remain on the card following a
successful upgrade.
Page | 11
The OLED display which can be used to display Speed, Max Speed,
Lap-time, Predictive Lap-time, and both Lateral and Longitudinal
Acceleration.
The cable must be plugged into the top connector (when viewed
with the buttons on the left hand side).
The OLED will use the Start/Finish line which is embedded in the
currently loaded Scene file.
www.videovbox.co.uk (Found under 'Support')
20 October 2010
