VIDEO VBOX MANUAL
Connector 6 – CAN
Pin I/O
1 -
2 -
3 I/O
4 I/O
5 O
Connector 7 – SER
Pin I/O
1 O
2 I
3 I/O
4 I/O
5 O
Connector 8 – USB
Pin I/O
1 I
2 I/O
3 O
4 I/O
5 I/O
Connector 9 – AUX Out
Pin I/O
1 O
2 O
3 I
4 O
5 O
6 O
Connector 10 – MIC
Pin I/O
1 O
2 -
3 I
4 I
5 O
Connector 11 – GPS (GPS Antenna)
Pin I/O
1 I
Chassis I
Page | 16
Function
-
-
CAN High
CAN Low
Power
Function
Tx-RS232
Rx-RS232
CAN High
CAN Low
Power
Function
USB - ID
DP
Ground
USB 5V
DM
Function
Ground
Video Output
Digital Input
Digital Output
Audio Output
Power
Function
Ground
-
Audio –right channel
Audio –left channel
Power
Function
Signal
Ground
20 October 2010
