Connector Assignments – Video VBOX Pro
Connector 1 – Power (Dedicated 9V to 15V DC Power Connector)
Pin I/O
1 I
2 I
Chassis I
Connector 2 – Camera 1
Pin I/O
1 O
2 I
3 O
4 O
5 I
Connector 3 – Camera 2
Pin I/O
1 O
2 I
3 O
4 O
5 I
Connector 4 – Camera 3
Pin I/O
1 -
2 I
3 O
4 O
5 -
Connector 5 – Camera 4
Pin I/O
1 -
2 I
3 O
4 O
5 -
Page | 15
Function
Power +
Ground
Ground
Function
Audio Ground
Video Input
Camera Power
Camera Ground
Audio Input (Left)
Function
Audio Ground
Video Input
Camera Power
Camera Ground
Audio Input (Right)
Function
-
Video Input
Camera Power
Camera Ground
-
Function
-
Video Input
Camera Power
Camera Ground
-
