VIDEO VBOX MANUAL
Quickstart Guide
As shipped, the Video VBOX can be used straight out of the box:
1. Mount the GPS antenna in the centre of the roof of the vehicle. Keep
away from roof bars
2. Connect the antenna to the Video VBOX
3. Connect the power connector, it takes about 35s to start
4. Attach the camera to the windscreen using the forward facing camera mount,
keep the camera level using the markings on the camera
5. Connect the camera to CAM1
