Page 1 Installation Guide and Users Manual AirPRO 238 Professional Series (PST/T2) IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Under Cabinet/Wall Mount Range Hood Rev. 3060u.1d...
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction.
Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Troubleshooting...........18 Tools needed............3 Parts supplied...........4 Use and care information.......19 Venting requirements........5 Specifications..........19 Mount heights & clearance......5-6 Measurements & diagrams.......20-24 Calculating vent system length.......6 MAINTENANCE Venting methods..........7 Cleaning..........25 Electrical requirements........8 Replacing the filter & light bulb.....25 Preparation............9 WARRANTY Installation..........10-11...
Page 6: Parts Supplied
Parts supplied: Single-piece Chimney (Optional) Under Cabinet Range Hood (vary with model) Qty: 4 PCS Qty: 4 PCS (For sheet rock only) 10” Ducting Transition 8” Ducting Transition (Optional for Dual Blowers) (X2 for Dual Blowers) Qty: 8 PCS (Flat head) Optional for Qty: 8 PCS Single-piece...
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an at- tic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall Cabinet or Single- caps.
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 8” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting the exhaust on the hood to the ductwork.
Page 9: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages.
Page 10: Electrical Requirements
Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. (Please consult with a qualified electrician for 220-Volt 50 Hz voltage) It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 —...
Page 11: Preparation
Preparation WARNING Advanced Preparations: • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. • Place the range hood on a flat, stable surface. Connect the Excessive Weight range hood to a designated standard outlet (please refer the Require three or more person to move and product label for the suitable voltage of this unit) and turn on install this range hood.
Page 12: Installation
Installation Installations (refer to Page 4 for parts): Measure the distance between stove top and the bottom of range hood. A distance of 28” to 31” is recommended*. *Due to different ceiling height configurations, recom- mended height may not be applicable. You can mount this range hood to both under cabinet and wall: Height &...
Page 13 Installation (Continued) Store excess wires in the wiring box. OPTIONAL: If you purchased a single-piece chimney cover, attach it to the hood in this step. Drop oil tunnel into recess support near rear of hood. Refer to Figure 9. To install baffle filters and stainless spacer(s), refer to Baffle Filters and Stainless Steel Spacers on Page 22 for baffle filter and stainless spacer placement.
Page 14: Range Hood Operations
Range Hood Operations & Wiring Diagram Control Panel Layout and Buttons Configurations (Control type 1): Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator This range hood is designed to remove smoke, cooking vapors and odors from the cook top area.
Page 15: Level
Range Hood Operations & Wiring Diagram (Continued) Control Panel Layout and Buttons Configurations (Control type 1): Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator •...
Page 16 Range Hood Operations & Wiring Diagram (Continued) Control type 1 (6 speed) NOTE: Wiring Diagrams shown above with GU10/PAR20 light configuration. A transformer is required for MR16 Lights. Page 14...
Page 17: Level
Range Hood Operations & Wiring Diagram (Continued) Control Panel Layout and Buttons Configurations (Control type 2): Power Light Power-Off Delay Increase Value Decrease Value Power-Off Delay Digital Timer Blower Speed Indicator Cleaning Reminder Indicator The range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best results, start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear all smoke and odors from the kitchen.
Page 18: Level
Range Hood Operations & Wiring Diagram (Continued) Control Panel Layout and Buttons Configurations (Control type 2): Power Light Power-Off Delay Increase Value Decrease Value Power-Off Delay Digital Timer Blower Speed Indicator Cleaning Reminder Indicator • Controls: • Adjusting the timer function: •...
Page 19 Range Hood Operations & Wiring Diagram (Continued) Control type 2 (4 speed) Control type 2 (6 speed) NOTE: Wiring Diagrams shown above with GU10/PAR20 light configuration. A transformer is required for MR16 Lights. Page 17...
Page 20: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected.
Page 21: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing.
Page 22: Measurements & Diagrams
Measurements and Diagrams Measurements and Diagrams Measurements and Diagrams • • All measurements in parenthesis are in millimeter. All measurements in parenthesis are in millimeter. • • All inch measurements are converted from millimeters, thus inch measurements are estimated. All inch measurements are converted from millimeters, thus inch measurements are estimated. With optional single-piece chimney: With optional single-piece chimney: Single blower configuration:...
Page 23 Measurements and Diagrams (Continued) • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Without optional single-piece chimney: Single blower configuration: (AP238-PST) Dual blower configuration: (AP238-PST2) Page 21...
Page 24 Measurements and Diagrams (Continued) • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Single blower configuration: (AP238-PST) Dual blower configuration: (AP238-PST2) Page 22...
Page 25 Range Hood Assembly: Description Description Hood Casing Halogen Light Screws Ducting Transition Screws Gasket Blower Assembly Baffle Filter Wiring Box Cover Stainless Steel Spacer Wiring Box Baffle Filter Handle Heat Lamp Socket (optional) Screws Screws Switch Assembly Heat Lamp Socket Box (optional) Electrical Assembly Oil Tunnel Real Halogen Light / Heat Lamp Panel...
Page 26 Blower Assembly: Description Description 4.1 Air Chamber 4.5 Motor 4.2 Air Flow Grill 4.6 Right Squirrel Cage 4.3 Left Locknut 4.7 Right Locknut 4.4 Left Squirrel Cage 4.8 Air Chamber Optional Single-Piece Chimney (Sold Separately): Description Description Screws (3/16” x 3/8”) Single-Piece Chimney Cover (Size Varies) Page 24...
Page 27: Cleaning
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •...
Page 28: Coverage & Exceptions
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects.
Page 29: Disclaimer & Contact Us
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately.
Page 30 Your Notes Page 28...
Page 31 Your Notes Page 29...
Page 32 Your Notes Page 30...
Page 33 Cavaliere Cavaliere 7372 Doig Drive 7372 Doig Drive Garden Grove, California 92841 Garden Grove, California 92841 Tel: 714-622-1550 Fax: 714-622-1559 Tel: 714-622-1550 Fax: 714-622-1559 http://www.cavalierehoods.com http://www.cavalierehoods.com...
