- Page 1 5 0 0 W W a r n e r , S a n t a A n a C A 9 2 7 0 7 T e c h n i c a l S u p p o r t : 7 1 4 - 6 2 2 - 1 5 5 0 c a v a l i e r e h o o d s .
-
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. - Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........14 Parts supplied...........4 Use and care information.......15 Venting requirements........5 Specifications..........15 Mount heights & clearance......5-6 Measurements & Diagrams......16-21 MAINTENANCE Calculating vent system length.......6 Venting methods..........7 Cleaning..........22 Electrical requirements........8 Replacing the filter & light bulb.....22 WARRANTY Preparation............9 Installation..........10-11... -
Page 6: Parts Supplied
Parts supplied: Upper Chimney Lower Chimney Range Hood Chimney-mounting Bracket Qty: 4 PCS Baffle Filters Qty: 2 PCS (30-in models) Qty: 3 PCS (36-in models) Qty: 6 PCS Qty: 4 PCS (30-in models) Qty: 6 PCS (36-in models) Qty: 2 PCS (30-in models) Qty: 3 PCS (36-in models) Qty: 4 PCS Qty: 4 PCS... -
Page 7: Venting Requirements
Venting Requirements Height & Clearance Chimney- • Vent system must terminate to the outside (roof or side wall). mounting Maximum ceiling clearance • DO NOT terminate the vent system in an at- 110” at 30” hood mounting Bracket height above countertop/ tic or other enclosed area. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. -
Page 9: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. -
Page 10: Electrical Requirements
Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. (Please consult with a qualified electrician for 220-Volt 50 Hz voltage) It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 —... -
Page 11: Preparation
Preparation WARNING Excessive Weight Require three or more person to move and install this range hood. Spinal or other bodi- ly injuries could occur if it is not followed. Advanced Preparations: Range Hood Operations, Page 12. • Be familiar with the controls of the range hood by reading through •... -
Page 12: Installation
Installation Installations (refer to Page 4 for parts): Measure the distance between stove top and the bottom of range hood. A distance of 27” to 30” is recommended*. *Due to different ceiling height configurations, recom- mended height may not be applicable. Using references in Height &... -
Page 13: Installation
Installation (Continued) Connect the range hood to a designated standard outlet (please re- Figure 8 fer the product label for the suitable voltage of this unit) or cut off the plug and connect three wires (black, white and green) to house wires and cap with wire connectors. -
Page 14: Range Hood Operations
Range Hood Operations Control Panel Layout and Buttons Configurations: LCD Panel Light Decrease Power-Off Increase Delay Auto Function Remote Control Sensor This range hood is equipped with remote control and heat sensor that will self-calibrate within 5 seconds when the range hood is first electrically activated. -
Page 15: Level
Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: LCD Panel Light Decrease Power-Off Increase Delay Auto Function Remote Control Sensor Activating Light Function: • Press Light button once to turn on the lights, and once again to turn off the lights. •... -
Page 16: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected. -
Page 17: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. -
Page 18: Measurements & Diagrams
Measurements and Diagrams Installation Overview: Chimney- Qty: 4 PCS mounting bracket Qty: 6 PCS Upper support frame Qty: 4 PCS Upper chimney Back of the range hood Qty: 4 PCS (For sheet rock only) Hood-mounting bracket Round duct (exhaust) Range hood Page 16... - Page 19 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Overall: Page 17...
- Page 20 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Overall without Chiminey: Page 18...
- Page 21 Hood-mounting Bracket: Circuit Diagram: Page 19...
- Page 22 Range Hood Assembly: Description Description Chimney-Mounting Bracket Control Panel Assembly Upper Standard Chimney Processor Board Lower Standard Chimney Baffle Handle Chimney-Mounting Bracket Electrical Box Cover Hood-Mounting Bracket Electrical Box Base Power Cable Halogen Light Transformer Safety Screen Electrical Panel Locknut Control Panel Assembly Panel Squirrel Cage Hood Casing...
- Page 23 Blower Assembly: Description Description Motor Locknut Air Chamber Safety Screen Squirrel Cage Electrical Assembly: Description Description Screws (3/16” x 3/8”) Electrical Panel Electrical Box Cover Capacitor Processor Board Screws (3/16” x 3/8”) Screws (3/16” x 3/8”) Halogen Light Transformer Electrical Box Base Page 21...
-
Page 24: Cleaning
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •... -
Page 25: Coverage & Exceptions
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. -
Page 26: Disclaimer & Contact Us
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 27 Your Notes Page 25...
- Page 28 5 0 0 W W a r n e r , S a n t a A n a C A 9 2 7 0 7 T e c h n i c a l S u p p o r t : 7 1 4 - 6 2 2 - 1 5 5 0 c a v a l i e r e h o o d s .
