- Page 1 Installation Guide and Users Manual 218 Series Pro Wall Hood IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall Mount Range Hood Rev. 1025u.1d...
-
Page 2: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. - Page 3 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 4: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Range hood operations & diagrams..12-16 Parts supplied...........4 Troubleshooting...........17 Venting requirements........5 Use and care information.......18 Mount heights & clearance......5-6 Specifications..........18 MAINTENANCE Calculating vent system length.......6 Venting methods..........7 Cleaning..........19 Electrical requirements........8 Replacing the filter & light bulb.....19 WARRANTY Preparation............9 Installation..........10-11... -
Page 5: Parts Supplied
Parts supplied: Range Hood (vary with model) Grease cup Lower standard chimney Ducting Transition Upper standard chimney Optional Duct Tube Screw Set Mounting Bracket For sheet rock only Baffle Filter Spacer Baffle Filters Grease Tunnel Page 4... -
Page 6: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an at- tic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall Cabinet or Single- caps. -
Page 7: Calculating Vent System Length
IMPORTANT: • A minimum of 8” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. -
Page 8: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. -
Page 9: Electrical Requirements
Electrical Requirements IMPORTANT: For Europe and Other Countries with 220~240V/50Hz, please observe your local governing codes and ordinances. It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 —... -
Page 10: Preparation
Preparation WARNING Advanced Preparations: Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. Place the range hood on a flat, stable surface. Connect the Excessive Weight range hood to a designated standard outlet, 110~120V/60Hz Require three or more person to move and (220~240V/50Hz for Europe &... -
Page 11: Installation
Installation Installations (refer to page 4 & 11 for parts): Measure the distance between stove top and the bottom of range hood. A distance of 28” to 31” is required. Make sure the range hood is level and not tilted. Mark the locations of the hanging bracket holes on the wall as shown in Figure 3A and Figure 3B. -
Page 12: Installation Overview
Installation (Continued) the height of the duct tube and extend approximately 6” (15 cm) longer than required, connect the Calculate lower end of the duct tube to the range hood and the upper end to the vent system. Make sure the main electri- cal supply remains disconnected then connect power plug to the electrical cord or wall plug. -
Page 13: Range Hood Operations & Diagrams
Range Hood Operations Control Panel Layout and Buttons Configurations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator This range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best re- sults, start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear all smoke and odors from the kitchen. - Page 14 Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator • Controls: • Adjusting the timer function: •...
- Page 15 Measurements & Diagrams Control type 1 - Touch Sensitive Version (Six speed with type GU10 bulb) Control type 1 - Touch Sensitive Version (Six speed with type MR16 bulb) 12V/75W Transformer Page 14...
- Page 16 Measurements & Diagrams (Continued) Control type 1 - Soft-Touch Version (Six speed with type GU10 bulb) Control type 1 - Soft-Touch Version (Six speed with type MR16 bulb) 12V/75W Transformer Page 15...
- Page 17 Measurements & Diagrams (Continued) • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Page 16...
-
Page 18: Troubleshooting
Troubleshooting If the range hood does not operate after installa- • Check if the range hood has been plugged in, make tion: sure that all power has been turned back on and all electrical wiring are properly connected. • Swap out light assembly to working ones to deter- mine whether it is caused by defective bulbs. -
Page 19: Use And Care Information
Use and Care Information WARNING — TO REDUCE THE RISK OF FIRE, ELEC- lowed to accumulate on fan or filter. TRIC SHOCK, OR INJURY TO PERSONS, OBSERVE Use proper pan size. Always use cookware appropriate for THE FOLLOWING: Use this unit only in the manner in- the size of the surface element. -
Page 20: Cleaning
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •... -
Page 21: Coverage & Exceptions
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. -
Page 22: Disclaimer & Contact Us
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 23 Your Notes Page 22...
