- Page 1 5 0 0 W W a r n e r , S a n t a A n a C A 9 2 7 0 7 T e c h n i c a l S u p p o r t : 7 1 4 - 6 2 2 - 1 5 5 0 c a v a l i e r e h o o d s .
-
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. - Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........14 Parts supplied...........4 Use and care information.......15 Venting requirements........5 Specifications..........15 Mount heights & clearance......5-6 Measurements & Diagrams......16-22 Calculating vent system length.......6 MAINTENANCE Venting methods..........7 Cleaning..........23 Electrical requirements........8 Replacing the filter & light bulb.....23 Preparation............9 WARRANTY Installation..........10-11... -
Page 6: Parts Supplied
Parts supplied: Single-piece Chimney Under Cabinet Range Hood (Optional) Qty: 4 PCS Qty: 4 PCS (For sheet rock only) Hood-mounting Bracket (Qty: 2PCS) Ducting Transition Qty: 8 PCS (Flat head) Optional for Single-piece Qty: 8 PCS Chiomney Qty: 10 PCS Baffle Filters Qty: 8 PCS (Round head) -
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside (roof or side wall). • DO NOT terminate the vent system in an at- tic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall Cabinet or Single- caps. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 8” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separate- ly) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. -
Page 9: Venting Methods
Venting Methods • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: • NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. -
Page 10: Electrical Requirements
Electrical Requirements IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility: • To contact a qualified electrical installer. • To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/ NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No. 0-M91 - latest edition** and all local codes and ordinances. -
Page 11: Preparation
Preparation Advanced Preparations: WARNING • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. • Place the range hood on a flat, stable surface. Connect the Excessive Weight range hood to a designated standard outlet (120-Volt, 60Hz, Require three or more person to move and AC only) and turn on the range hood. -
Page 12: Installation
Installation Installations (refer to Page 4 for parts): I t ll ti ( f t P Measure the distance between stove top and the bottom of range hood. A distance of 27” to 30” is recommended*. *Due to different ceiling height configurations, recom- mended height may not be applicable. - Page 13 Installation (Continued) Store excess wires in the wiring box. OPTIONAL: If you purchased a single-piece chimney cover, attach it to the hood in this step. Drop oil tunnel into recess support near rear of hood. Refer to Figure 9. To install baffle filters and stainless spacer(s), refer to Baffle Filters and Stainless Steel Spacers on Page 18 for baffle filter and stainless spacer placement.
-
Page 14: Range Hood Operations
Range Hood Operations Control Panel Layout and Buttons Configurations: LED Light LED Speed Indicator Indicators Light Control Speed Control Power Control (On/Off) This range hood is equipped with four electronic controls, oversized powerful centrifugal squirrel cage motor with stainless steel grease tunnel, stainless steel baffle filters and spacers, two bright 12V 20W halogen lights and 120V 250W heating lamp sockets (heating lamps sold separately). - Page 15 Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: Decrease Increase Speed Speed LED Light LED Speed Indicator Indicators Light Control Power Control (On/Off) • During this 3-minutes delay, changing speeds will not affect the countdown. Immediate Power-off • While the fans are in 3-minute power-off delay mode, press the Power Control (On/Off) button once to turn OFF the fans immediately.
-
Page 16: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected. -
Page 17: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. -
Page 18: Measurements & Diagrams
Measurements and Diagrams • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. With optional single-piece chimney: Without optional single-piece chimney: Page 16 Page 16... - Page 19 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Without hood-mounting bracket: With hood-mounting bracket: Page 17...
- Page 20 • All measurements in parenthesis are in millimeter. • All inch measurements are converted from millimeters, thus inch measurements are estimated. Rear Knockout Holes: Hood-mounting Bracket: Page 18...
- Page 21 Baffle Filters and Stainless Steel Spacers: 30” Range Hood 36” Range Hood Circuit Diagram: Page 19...
- Page 22 Range Hood Assembly: Description Description Hood Casing Halogen Light Ducting Transition Screws (3/16” x 3/8”) Screws (3/16” x 3/8”) Gasket Blower Assembly Baffle Filter Wiring Box Cover Stainless Steel Spacer Wiring Box Baffle Filter Handle Heat Lamp Socket Screws (3/16” x 3/8”) Screws (3/16”...
- Page 23 Blower Assembly: Description Description 4.1 Air Chamber 4.5 Motor 4.2 Air Flow Grill 4.6 Right Squirrel Cage 4.3 Left Locknut 4.7 Right Locknut 4.4 Left Squirrel Cage 4.8 Air Chamber Optional Single-Piece Chimney (Sold Separately): Description Description Screws (3/16” x 3/8”) Single-Piece Chimney Cover (Size Varies) Page 21...
- Page 24 Electrical Assembly: Description Description 21.1 Bolt 21.8 Capacitor 21.2 Electrical Box 21.9 Transformer 21.3 Screws (3/16” x 3/8”) 21.10 Bolt Gasket 21.4 Processor Board 21.11 Screw Cap 21.5 Electrical Box Cover 21.12 Rubber Gasket 21.6 Electrical Box Base 21.13 Screws (3/16” x 3/8”) 21.7 Screws (3/16”...
-
Page 25: Cleaning
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! SAFETY WARNING N For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •... -
Page 26: Coverage & Exceptions
Warranty must rese sent chas date Pl Plea ease a an h a hase l e les re rece i n invo i in d e der ai ain se serv i c ice d e der warr rran One Year Parts Warranty: For one year from the date of original purchase, Euro-Kitchen, Inc. -
Page 27: Disclaimer & Contact Us
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 28 5 0 0 W W a r n e r , S a n t a A n a C A 9 2 7 0 7 T e c h n i c a l S u p p o r t : 7 1 4 - 6 2 2 - 1 5 5 0 c a v a l i e r e h o o d s .
