Multiple Station Assembly Steps - TuffStuff Apollo 7000 series Owner's Manual

STEP 3
Assembly List
Item #
A1 CENTER POST
A7 SOCKET CAP SCREW GR-8 N/P 3/8-16 X 1
A8 FLAT WASHER SAE N/P 3/8"
A10 SPLIT LOCK WASHER N/P 3/8"
6 BASE FRAME
38 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2
46 BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 1 3/4
50 BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 4 1/2
66 FLAT WASHER SAE N/P 3/8"
77 NYLON INSERT LOCK NUT N/P 3/8-16
81 PLASTIC PULLEY COVER
77 77
66 66
77 77
38 38
AP-7000 SERIES MULTI PRESS STATION
Description
A7 A7
A10 A10
81 81
46 46
Qty.
1
4
4
4
1
4
2
2
8
4
1
A8 A8
38 38
77 77
38 38
6 6
66 66
50 50
A1 A1
A10 A10
66 66
50 50
A8 A8
A7 A7
7
