TuffStuff Apollo 7000 series Owner's Manual page 18

STEP 14
5 5
20 20
NOTES:
1. SOME PARTS CUT OUT/NOT SHOWN FOR CLARITY.
18
115 115
104 104
69 69
10 10
75 75
115 115
87 87
Assembly List
Item #
5 BACK PAD
10 FOOT ROLL (1 X 5 1/2 X 9)
11 FOOT ROLL TUBE 1 X 28 3/8
20 SEAT PAD
66 FLAT WASHER SAE N/P 3/8"
69 FLAT WASHER N/P 3/8 ID X 1 1/2 OD X 3/16
74 METAL HINGE
75 NYLON FLAT WASHER 1 X 1 1/4 X 1/16
87 RUBBER BUMPER W/WASHER 3/8 X 1 1/2
98 SOCKET SET SCREW ALLOY 1/4-20 X 1/4
104 SPLIT LOCK WASHER N/P 3/8"
115 BUTTON HEAD SCREW GR-8 N/P 3/8-16 X 1 1/4
11 11
66 66
74 74
98 98
115 115
Description
115 115
74 74
66 66
75 75
10 10
AP-7000 SERIES MULTI PRESS STATION
Qty.
1
2
1
1
4
2
2
2
1
1
2
7
69 69
104 104
115 115
