Océ
| Arizona T220UV
Site Preparation Guide
Revision B • January, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arizona T220UV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Oce Arizona T220UV

  • Page 1 Océ | Arizona T220UV Site Preparation Guide Revision B • January, 2005...
  • Page 2 Océ Display Graphics Systems © 2004 All Rights Reserved...
  • Page 3: Table Of Contents

    Copyright .................iii Document Summary ............iii Product Support, Documentation and Service....iii 1 Introduction General Description ............1 Arizona T220UV Specifications ........2 Physical..............2 Performance ............2 2 System Requirements Receiving and Moving the Arizona® T220UV ....3 Receiving the Shipping Crates......... 3 Hallway Requirements ..........
  • Page 4 Océ | List of Figures Arizona T220UV Printer ........... 1 Arizona T220UV Table Crate Dimensions ....... 3 Arizona T220UV Gantry Crate Dimensions ..... 4 Maximum Room Size Requirements ....... 5 Electrical Wiring Configuration......... 6 3010102253-B...
  • Page 5: Copyright

    1/12/05 3010102253 Added ColorBlend and web site MSDS. Product Support, Documentation and Service For further information on documentation and support for your Arizona T220UV or for information on other Océ Display Graphics Systems products, please contact: Web: http://www.dgs.oce.com FTP Site: http://www.cymbolic.com/ftp.html...
  • Page 6 When you call one of our customer service numbers you will be provided with telephone technical support. Outside of office hours, you can leave a message and your call will be returned the next working day. When you call, identify yourself as a Arizona T220UV customer and provide the following information: •...
  • Page 7 (604) 232-2345 Direct Dial (604) 273-7730 Reception (604) 273-2775 Fax 7:00AM - 4:30PM PST Representatives Marketing the Arizona T220UV in Europe: Océ-Deutschland GmbH Solinger Straße 5-7 45481 Mülheim/Ruhr Germany Telephone: (49) 2084 8450 Fax: (49) 2084 80950 E-mail: ves@oce.de...
  • Page 8 Océ | Océ (UK) Ltd. Langston Road Loughton, Essex IG10 3SL United Kingdom Telephone: (44) 870 600 5544 Fax: (44) 870 600 1113 E-mail: salesinformation@oce.co.uk Web site: www.oce.co.uk 3010102253-B...
  • Page 9: Introduction

    The printer uses UV-curable inks. A set of ultraviolet lamps attached to the gantry provides curing of the UV ink on the media. The Arizona T220UV must be operated in accordance with certain environmental and safety requirements noted in this document and detailed in the Arizona T22oUV User Guide.
  • Page 10: Arizona T220Uv Specifications

    Océ | Introduction Arizona T220UV Specifications Physical 1.2.1 Table Dimensions ..70.5” (180 cm) x 168” (427 cm) Gantry Dimensions ..36” (92 cm) x 145” (368 cm) Weight .......2300 lbs. (1043 kg) Performance 1.2.2 Max. Media Size ..62” (158 cm) wide x 120” (305 cm) long x 2” (6 cm) thick Max.
  • Page 11: System Requirements

    443 cm (14’ 7”) 193 cm (6’ 4”) 112 cm (3’ 8”) Figure 2 Arizona T220UV Table Crate Dimensions. Warning: The crates cannot be titled greater than 45 degrees. Once the machines have been lifted from the crates, they cannot be tilted or lifted.
  • Page 12 Océ | System Requirements Crate #2— with the dimensions shown in Figure 2 — contains the gantry and vacuum pump assemblies. The loaded crates weighs approximately 544 kg (1200 lb). The gantry must not be removed from its crate until it is to be installed on the table. The crate was specifically designed to be a tool for installing the gantry.
  • Page 13: Hallway Requirements

    Receiving and Moving the Arizona® T220UV | Hallway Requirements 2.1.2 The table assembly, once uncrated can be rolled on its 6 casters. The assembly weighs approximately 610 kg (1345 lb). To prevent collisions and/or damage, it is recommended that at least two people move it. The dimensions of the table assembly are 72” wide x 168” long x 30”...
  • Page 14: Electrical Requirements

    AC Power 2.2.1 The Arizona T220UV requires two 3 Phase AC power circuits. One dedicated to the printer and the second dedicated to the vacuum pump. It is the customer’s responsibility to hire a qualified electrician to provide electrical service to the printer and pump assemblies. Both the printer and vacuum pump come equipped with panel mount inlet connectors.
  • Page 15: Vacuum Pump Power Requirements

    Electrical Requirements | Printer Power Requirements 2.2.2 The printer operates in the following two configurations. Delta (USA/Canada) Configuration: Voltage:......230VAC +/-10%, 3 Phase Frequency:....50 or 60 Hz Current:......25AMPS maximum steady state Power: .......15kW max. Circuit Breaker...30 Amps Wye (European) Configuration: Voltage:......400VAC +/-10%, 3 Phase Frequency:....50 or 60 Hz Current:......13AMPS maximum steady state Power: .......15kW max.
  • Page 16: Gfi Circuit Breakers

    Océ | System Requirements Current:......8 AMPS maximum steady state Power: .......6kW max. Circuit Breaker...15 Amps 190 Volts @ 50 Hz Voltage:......190 VAC +/-10%, 3 Phase Current:......16.5 AMPS maximum steady state Power: .......7kW max. Circuit Breaker...20 Amps 380 Volts @ 50 Hz Voltage:......380 VAC +/-10%, 3 Phase Current:......8 AMPS maximum steady state Power: .......7kW max.
  • Page 17: Ac Distribution Circuit

    For protection of personnel and equipment, use an appropriately rated and protected AC circuit to supply power to the Arizona T220. AC Distribution Circuit 2.2.5 The Arizona T220UV requires two dedicated AC distribution circuits, which means a separate branch circuit with an individual circuit protection device on each circuit. Grounding 2.2.6...
  • Page 18: Compressed Air Requirement

    Operating Conditions 2.4.1 The Arizona T220UV will operate at an optimum level if it is in a controlled environment. The area where the printer is installed should be reasonably free of dust and other airborne particles (for example, the printer should not be placed in an area where routers, sanders or trimmers are used).
  • Page 19: Shock And Vibration

    Environmental Requirements | Heat Removal The lamps that dry the UV ink on printed media on the Arizona T220UV can produce up to 15,000 BTU per hour (4400 watts). The printer will operate to specification in an ambient temperature of 20ºC to 27ºC (68º to 80º F). Depending on the print room size an air conditioning system may be necessary in order to maintain the ambient temperature.
  • Page 20: Safety Information

    Océ | System Requirements Safety Information The Arizona T220UV uses ultraviolet-based inks: • UV inks are toxic, if swallowed; • May cause eye irritation; • May cause skin irritation upon prolonged or repeated contact; • May be absorbed through the skin; and •...
  • Page 21: Customer Equipment Requirements

    If you think that you need this product, you must buy directly from the manufacturer. See the Arizona T220UV User Guide for for more information and sources.
  • Page 22: Host Computer Requirements

    Operator Training Maximum performance on the Arizona T220UV requires a properly trained operator. Océ trains the operator in the use of the Arizona T220UV hardware and software at installation. ® However, this is not a substitute for formal PosterShop training.
  • Page 23: Appendix A Pre-Installation Checklist

    Documentation and Service” on page iii). A well-prepared site will minimize installation time, provide an optimized environment for the Arizona T220UV printer and hence, reliable operation. Important: A completed copy of the forms on the following two pages must be returned to your local Océ...
  • Page 24: Customer Information

    Océ | Pre-Installation Checklist Customer Information Company: Date: Contact: Distributor: Address: Contact: Phone: Installation Start Date: ________________________________________ The customer agrees to have an operator available for the installation. This will allow the customer to get into production as quickly as possible. Signature of Océ...
  • Page 25: System Requirements Checklist

    System Requirements Checklist Requirement Space and Location Requirements: Page 2-5 Clear path from loading dock to operating site Minimum Room Dimensions: 5.5m (18’) ×7.35m (24.1’) Electrical Requirements (Printer): Page 2-6 Requirements met Electrical Requirements (Vacuum) Requirements met Environmental Requirements: Page 2-9 Requirements met Air Requirements: Page 2-9...
  • Page 26 Océ | Pre-Installation Checklist -18- 3010102253-B...
