- Page 1 All manuals and user guides at all-guides.com Océ TDS100 Quick reference guide...
- Page 2 A complete description on how to operate ■ User manual CD-ROM and maintain the Océ TDS100. Visit Océ on the internet at www.oce.com for more Note: information. Copyright © 2005, Océ-Technologies B.V. Venlo, The Netherlands All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ.
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Contents Chapter 1 About the Océ TDS100 The components 6 The operator panel 8 Make copies 11 Replace media rolls 12 Add toner 13 Clear jams 15 Contents... - Page 4 All manuals and user guides at all-guides.com Quick reference guide...
-
Page 5: About The Océ Tds100
All manuals and user guides at all-guides.com Océ TDS100 Quick reference guide Chapter 1 About the Océ TDS100... -
Page 6: The Components
All manuals and user guides at all-guides.com The components Nr. Component Function On / off switch Turn on and off the Océ TDS100. The on / off switch is not visible in the Note: illustration. Operator panel Set up, start and control the copy jobs. - Page 7 Middle cover Give access to the underside of the manual feed table. Some components may not be available on your Océ TDS100 due to the Note: differences between the configurations. About the Océ TDS100...
-
Page 8: The Operator Panel
All manuals and user guides at all-guides.com The operator panel 1 2 3 4 toner media jam paper media film manual roll 1 feed roll 2 trailing strip leading synchro standard Quick reference guide... - Page 9 All manuals and user guides at all-guides.com The indicators Indicator Function 'Toner' Indicate that the Océ TDS100 has run out of toner. Green light Indicate that the copier is ready. A blinking green light indicates that the copier runs a copy job. Red light Indicate that an error has occurred.
- Page 10 When you press the stop key twice while you set up ■ a copy job, the default values return. Start Start the copy job. Some functions may not be available on your Océ TDS100 due to the Note: differences in the configurations. Quick reference guide...
-
Page 11: Make Copies
How to copy on a roll medium (automatically) Step Action Place the original centrally and face down on the original feed table. The Océ TDS100 moves the original to the back. Make the required settings. Press the green start key. -
Page 12: Replace Media Rolls
All manuals and user guides at all-guides.com Replace media rolls How to replace a media roll Step Action Open the drawer with roll 1 or the door in front of roll 2. Replace the media roll and follow the instructions on the sticker. Use the 'Feed' key to select the roll number of the new roll. -
Page 13: Add Toner
Loosen the nut at the left back side. Open the left cover. Before you open the bottle, shake the toner bottle thoroughly. Put the toner bottle in the bottle holder. Turn the bottle clockwise to fasten the bottle. About the Océ TDS100... - Page 14 All manuals and user guides at all-guides.com Step Action Turn the bottle in the vertical position. Wait until the bottle is empty. Return the bottle into the original position. Turn the bottle anticlockwise to loosen the bottle from the bottle holder.
-
Page 15: Clear Jams
Pull the top cover towards you and lift the top cover to open it. Pull the original carefully with two hands towards you Check on a media jam also and clear the media jam if necessary About the Océ TDS100... - Page 16 All manuals and user guides at all-guides.com How to remove the media from the manual feed table Make sure you lower the sheet feeder before you remove the Attention: media. Step Action Open the middle cover. Press the two handles at the underside of the manual feed table to lower the manual feed table.
- Page 17 Caution: The jammed media can contain loose toner. Attention: Step Action Turn off the Océ TDS100. Loosen the nut at the left back side. Open the left cover. Lift the green handle and open the fuser cover. Remove the jammed media carefully.
- Page 18 All manuals and user guides at all-guides.com Step Action Lift the green handle and close the fuser cover. Close the left cover. Tighten the nut at the left back side. Turn on the Océ TDS100. Quick reference guide...
