Table of Contents 1. Parts Identifications 1. Parts Identifications CONTROL PANEL Features LED indicators 2. Setting up the printer to indicate printer status 2.1 Unpacking and switches to operate PRINTER COVER the printer. 2.2 Connecting the cables Open this cover to load or replace paper.
2. Setting Up the Printer 2-1. Unpacking 2-2. Connecting the Cables Your printer box should include these items. If any items are damaged or missing, please contact your You can connect up the cables required for printing to the printer. dealer for assistance.
Page 5
2-2-1. Interface Connector Centronics Parallel Interface SIGNAL DESCRIPTION STROBE- Input Synchronize signal Data received DATA0~7 Input/Output Data bit Transmitted 0~7 ACK- Output Data receiving completed. BUSY Output Impossible to print of data receiving. Output Paper empty SELECT Output Printer status for ON/OFF line AUTO FEED- Input Paper auto feed signal...
2-2-2. Cash Drawer Connector 2-3. Loading the Roll Paper The printer can operate two cash drawers with a 6 pin RJ-11 modular connector. Notes: Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the The driver is capable of supplying a maximum current of 0.1A for 510ms or less when not printing.
5. Be sure to note the correct direction that the paper comes off the roll. 2-4. Di p Switch Setting The printer is set up at the factory to be appropriate for almost all users. On the other hand, offers some more settings for users with special requirements. It has DIP switches that allow you to change communication setting, such as handshaking and parity check, as well as print density.
Page 8
♣CAUTION: ♣CAUTION: Turn off the printer while removing the DIP switch cover to prevent an electric short, which can When the paper is jammed with cutter, the top cover might be stuck. In this case, repeat power on damage the printer. and off several times.
4. Self Test 3. Control panel and other functions The self-test lets you know if your printer is operating properly. It checks the control circuits, printer 3-1. Control panel mechanisms, print quality, ROM version and DIP switch settings. You can control the basic paper feeding operations of the printer with the button on the control panel. This test is independent of any other equipment or software.
5. Hexadecimal Dump 6. Specifications Appendix A : Specifications This feature allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. 6-1. General Specifications When you turn on the hex dump function, the printer prints all commands and other data in hexadecimal format along with a guide section to help you find specific commands.
(8) Overall dimension 6-2. Auto Cutter Specifications (1) Cutting Frequency Max. 30 cuts per minute (2) Thickness of paper 0.06 ~ 0.09 mm (3) Cutter Life 1.5 million cuttings 6-3. Interface RS232C Serial Interface, Centronics Parallel Interface(IEEE1284), USB Interface USB COMBO Interface, Ethernet Interface(10Mbps), Wi-fi(802.11b) 6-4.
7. Command List ♣Important! Command Function REMARKS When connecting or disconnecting the power supply from the printer, be sure that the following cautions are observed. Horizontal tab (1) Use a power supply (Limited Power Supply) of DC 24V±10% and more than 2.5A. Print and line feed (2) Be careful about installing the printer in an area where there is noise.
Page 13
Command Function REMARKS ESC t Select character code table ESC { Turn upside-down printing mode on/off FS p Print NV bit image FS q Define NV bit image GS ! Select character size GS $ Set absolute vertical print position in page mode GS * Define downloaded bit image GS /...
