2. Troubleshooting Instructions

2.1

POWER SUPPLY failure

2.1.1 Symptoms
- The Terminal does not see the power supply connected to its power jack.
2.1.2 Procedure
1. Before opening the Terminal, make sure you reproduce the issue with a reference
power supply.
2. If the failure disappears, change the power supply (even though the power supply
seems the root cause, check the power jack of the PCB_MAINBOARD, it might be
the problem)
3. If the failure is still present, change the PCB_MAINBOARD by a new one,
2.1.3 PSU control
1. Disconnect the power supply from the terminal.
2. Connect the power supply to the electrical wall plug.
3. Measure the DC output with a DC voltmeter, without charge and with a charge like a
reference terminal.
4. The voltage must be comprised between 6.65V and 7.35V.
