  • Page 1 E100 User’s Manual (October 2007)
  • Page 2 TRADEMARKS ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. All other brand and product names are trademarks or registered trademarks of their respective owners. NOTE The information in this manual is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Preface ..................vi Chapter 1 Getting Started...........1-1 Getting the Tablet PC Running ..........1-2 Unpacking ................ 1-2 Connecting to AC Power ..........1-2 Turning On and Off the Tablet PC........1-5 Taking a Look at the Tablet PC ........... 1-7 Right-Side Components ...........
  • Page 4 Using the Video Features ........... 2-12 Configuring the Display Modes ........2-12 Using the Audio Features ........... 2-13 Connecting Audio Devices ..........2-14 Using the Communication Features ........2-15 Using the LAN ............... 2-15 Using the Wireless LAN ..........2-15 ®...
  • Page 5 Chapter 5 Using BIOS Setup and System Recovery Feature .........5-1 When and How to Use BIOS Setup ........5-2 When to Use..............5-2 Starting BIOS Setup............5-2 Moving Around and Making Selections ......5-4 Information Menu ..............5-5 Main Menu ................5-6 Advanced Menu ..............
  • Page 6 Taking Care of the Tablet PC..........7-3 Location Guidelines ............7-3 General Guidelines............7-3 Cleaning Guidelines ............7-4 Battery Pack Guidelines ........... 7-4 Touchscreen Guidelines ........... 7-5 When Traveling..............7-7 Chapter 8 Troubleshooting..........8-1 Preliminary Checklist ............8-2 Solving Common Problems..........8-3 Battery Problems..............
  • Page 7 European Union CE Marking and Compliance Notices ..B-8 ..B-12 产 质 称 量标...

  • Page 8: Preface

    Preface This manual contains information that will help you operate the tablet PC. It is divided into 8 chapters and 2 appendices. Chapter 1, Getting Started, takes you through the process of setting up the tablet PC and identifying its external components. Chapter 2, Operating Your Tablet PC, tells you how to use the tablet PC’s components and features.

  • Page 9: Notational Conventions

    Notational Conventions Throughout this manual, the following conventions are used to distinguish elements of text. NOTE: identifies additional information that requires special attention. CAUTION: identifies important information that, if not followed, may result in loss of data or damage to the tablet PC. Keypad keys are shown in a bold typeset.

  • Page 10: Chapter 1 Getting Started

    Chapter 1 CHAPTER Getting Started Congratulations on purchasing this rugged tablet PC. This chapter first tells you step by step how to get the tablet PC up and running. You will find instructions for these procedures: Unpacking Connecting to AC power Turning on the tablet PC Turning off the tablet PC Then, you will find a section briefly introducing the external components...

  • Page 11: Getting The Tablet Pc Running

    Getting the Tablet PC Running This section guides you through the procedures for getting the tablet PC ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: Tablet PC Accessories: − AC adapter − AC power cord −...
  • Page 12 3. Remove the four screws securing the battery compartment cover and remove it. 4. Fit the battery pack into place ( ) and secure with two screws ( ). 5. Replace the battery compartment cover and secure with four screws. 6.
  • Page 13 7. Plug the female end of the AC power cord to the AC adapter and the male end to an electrical outlet ( ). 8. Power is being supplied from the electrical outlet to the AC adapter and onto your tablet PC. Now, you are ready to turn on the tablet PC. 9.

  • Page 14: Turning On And Off The Tablet Pc

    Turning On and Off the Tablet PC Turning On 1. Place your tablet PC on a flat and stable surface or, the tablet PC can be operated while holding it as shown. 2. Make sure that the tablet PC is either connected to AC power or the battery has power.

  • Page 15: Turning Off

    4. Each time the tablet PC is turned on, it performs a Power-On Self Test (POST), and the operating system Windows XP Tablet PC edition should start (may support Windows Vista Business and Ultimate in the future). Turning Off To turn off the tablet PC power, use the “Shut Down” command of your operating system.

  • Page 16: Taking A Look At The Tablet Pc

    Taking a Look at the Tablet PC This section identifies the external components of the tablet PC and briefly describes the function of each component. NOTE: Depending on the model you purchased, the appearance of your tablet PC may not be exactly the same as those shown in this manual. Right-Side Components Component Description...

  • Page 17: Left-Side Components

    Left-Side Components Component Description See Also RJ-45 Connector Connects the LAN cable. P. 2-15 Each of the two ports connects a USB device, P. 4-2 USB Ports such as a USB flash disk, printer, digital camera, joystick, and more. Getting Started...

  • Page 18: Rear Components

    Rear Components Component Description See Also Accepts a smart card for additional security P. 4-3 Smart Card feature. Reader PCMCIA Slot / Accepts a PC card or an ExpressCard/34 / P. 4-4, 4-6 ExpressCard/54 for additional functions. ExpressCard Slot (depending on your model) Connects a set of headphones, external P.

  • Page 19: Front Components

    Front Components Component Description See Also Connects to the optional antenna for wireless 3G Antenna WAN (wide area network) 3G transmission. pass-through Connector (option) Connects to the optional antenna for GPS GPS Antenna receiver. pass-through Connector (option) Connects to a docking station. P.

  • Page 20: Bottom Components

    Bottom Components Component Description See Also Inside is the battery pack that supplies P. 3-5 Battery Pack / power to your tablet PC when external 3G SIM Card Slot power is not connected. Compartment Also contains the 3G SIM card slot. P.

  • Page 21: Top Components

    Top Components Component Description See Also Displays and receives information for the P. 2-12 tablet PC. Touchscreen Turns the tablet PC power ON and OFF. P. 1-5 Power Button The LED lights green when tablet PC is on. Adjusts the LCD brightness automatically Light Sensor based on your tablet PC’s surrounding lighting condition.
  • Page 22 Component Description See Also Show the current status of the tablet PC’s Indicators devices. Lights green when WLAN is on. P. 2-16 WLAN/WWAN Lights amber when WWAN is on. Lights green when the battery is fully charged. P. 3-3 Battery Charge Lights amber when the battery is being charged.

  • Page 23: Where To Go From Here

    Where to Go from Here As your tablet PC is ready for operation, you may want to do any of the following now: For this purpose... Do this... To know more about the tablet PC... Go on to the next chapter. To install the operating system if your See the operating system manual.

  • Page 24: Chapter 2 Operating Your Tablet Pc

    Chapter 2 CHAPTER Operating Your Tablet PC This chapter provides information about the use of the tablet PC. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user but are new to tablet PCs, you may choose to read only the parts containing information unique to your tablet PC.

  • Page 25: Starting And Stopping The Tablet Pc

    Starting and Stopping the Tablet PC There are a number of ways to start and stop the tablet PC. Starting the Tablet PC You always start the tablet PC using the power button ( A computer starts up with an operating system (OS) existing on the storage device such as the hard disk.
  • Page 26 If you choose to stop in Standby or Hibernation mode, you can return to where you left off the next time you start up the tablet PC. (See “Power Management” in Chapter 3 for more information.) Operating Your...

  • Page 27: Using The Quick Buttons

    Using the Quick Buttons Located on top of the keypad are three quick buttons: Fn button toggles the Fn keylock ON and OFF ( icon appears on the system tray when ON). You can use the secondary functions of keypad buttons with blue color on top of each button (as described in the next section).

  • Page 28: Using The Keypad

    Using the Keypad Your keypad can be divided into two major categories: Numeric, Delete (Del), and Enter (Ent) keys Cursor-control keys NOTE: To use the keypad during poor lighting conditions, turn the keypad backlight ON by pressing the Fn button, then press the “8” ( ) button.

  • Page 29: Cursor-Control Keys

    – switches the sunlight-readable mode ON and OFF. – serves as the mouse right-click button. – C+A+D serves as the Ctrl+Alt+Del key. – ESC serves as the Escape button. Cursor-Control Keys The word “cursor” refers to the indicator on the screen (except for pointer on screen) that lets you know exactly where on your screen anything you type will appear.

  • Page 30: Using The On-Screen Keyboard

    Using the On-screen Keyboard Use the on-screen keyboard to enter text and perform various keyboard functions. 1. Click the on-screen keyboard icon ( ) located on the Windows system tray and the software keyboard will appear onscreen. 2. Tap the characters on the on-screen keyboard with the touchscreen / digitizer pen.

  • Page 31: Using The Touchscreen (Depending On Your Model)

    Using the Touchscreen (depending on your model) NOTE: Your tablet PC comes with either the touchscreen function or the Active Digitizer feature. The touchscreen function or the Active Digitizer feature is not available when running the BIOS Setup program. CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen.
  • Page 32 Term Action Right-click Press lightly on the display until a pop-up menu appears, then select the desired function. Drag and Press lightly on the touchscreen and move your finger drop until you reach your destination (drag). Finally, release your finger (drop) when you finish dragging your selection to the destination.

  • Page 33: Using The Active Digitizer Feature (Depending On Your Model)

    Using the Active Digitizer Feature (depending on your model) NOTE: Your tablet PC comes with either the Active Digitizer feature or the touchscreen function. The Active Digitizer feature or touchscreen function is not available when running the BIOS Setup program. The active digitizer feature allows you to easily communicate with the tablet PC by using the optional digitizer pen.
  • Page 34 Term Action Click/Point Tap gently on the display. Right-click Press lightly on the display until a pop-up menu appears, then select the desired function. Double-click Tap twice on the display rapidly. Drag and Press lightly on the display and move drop your digitizer pen until you reach your destination (drag).

  • Page 35: Using The Video Features

    Using the Video Features The video subsystem of your tablet PC features: 8.4-inch wide TFT (Thin-Film Transistor) color LCD with SVGA transmissive display Toggle display between landscape view and portrait view using the LCD rotate button Built-in light sensor to automatically adjust the LCD brightness Manually adjust the display brightness using the LCD brightness up ) and down ( ) buttons...

  • Page 36: Using The Audio Features

    Using the Audio Features The audio subsystem of your tablet PC features: High density audio codec Manually adjust the sound volume using the sound volume up ( and down ( ) buttons Audio-out connector ( ) ( ) and Integrated speaker ( ) Ways of playing and recording sound vary with the operating system used.

  • Page 37: Connecting Audio Devices

    Connecting Audio Devices For higher audio quality, you can send sound through external audio devices such as speakers, headphones, or earphone set using the audio-out connector. NOTE: After connecting an external audio device, make sure that you specify the use of the correct audio device in Windows.

  • Page 38: Using The Communication Features

    Using the Communication Features Using the LAN The internal 10/100/1000Base-T LAN (Local Area Network) module allows you to connect your tablet PC to a network. It supports data transfer rate up to 1000 Mbps. To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector ( ) on the tablet PC and the other end to the network hub.
  • Page 39 NOTE: 802.11g mode is backward compatible with 802.11b mode. Turning Off/On the WLAN Radio NOTE: The FAA (Federal Aviation Agency) has deemed it unsafe to operate wireless devices in aircraft as this may interfere with flight safety. Remember to turn off wireless LAN when using your tablet PC in the airplane.

  • Page 40: Connecting To A Wireless Network

    Connecting to a Wireless Network To connect to a wireless network: 1. Make sure that the wireless LAN radio is “on” indicated by the wireless LAN indicator ( ) glowing in green. 2. Double-click the Wireless Network Connection icon located on your Windows system tray.

  • Page 41: Connecting To Another Bluetooth Device

    Using the Bluetooth Wireless Feature (Optional) ® Depending on your model, your tablet PC may incorporate the Bluetooth capability for short-range (about 10 meters) wireless communications between devices without requiring a cable connection. With Bluetooth, data can be transmitted through walls, pockets and briefcases as long as two devices are within range.
  • Page 42 3. The Add New Connection Wizard window appears. Select Express Mode (Recommended), and then click Next. 4. Select the device to connect to and click Next. Operating Your 2-19...
  • Page 43 5. Depending on the type of Bluetooth device that you want to connect to, you will need to enter the pertinent information. Sending a File 1. Make sure that the target Bluetooth device is turned on, discoverable and within close range. (See the documentation that came with the Bluetooth device.) icon, and then click Wireless File Transfer.

  • Page 44: Using The Gps (Optional)

    4. Click the target device from the list, and then click Send to start the transfer procedure. Using the GPS (Optional) Depending on the model you purchased, your tablet PC may have the GPS receiver module built in. GPS (Global Positioning System) is a constellation of 24 well-spaced satellites that orbit the Earth and make it possible for devices enabled with GPS receivers to pinpoint their location.

  • Page 45: Using The 3G Feature (Optional)

    Refer to chapter 6 on using the GPS feature. Using the 3G Feature (Optional) 3G is the third generation of mobile phone standards and technology, after 2G. It is based on the International Telecommunication Union (ITU) family of standards under the International Mobile Telecommunications programme, “IMT-2000”.
  • Page 46 3. Remove the four screws securing the battery compartment cover and remove it. 4. Remove the two screws securing the battery pack to the battery compartment ( ) and, pull on the ribbon strip to lift the battery pack off the computer ( ). Operating Your 2-23...
  • Page 47 5. Locate the SIM card slot and push the SIM card into the slot. Make sure the beveled corner on the SIM card is facing towards the tablet PC and that the golden contact area on the card is facing downwards. To remove the SIM card, just push in ( ) the SIM card to pop-out ( ) and remove the card.
  • Page 48 6. Fit the battery pack into place and secure with two screws. 7. Replace the battery compartment cover and secure with four screws. WARNING: Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

  • Page 49: Chapter 3 Managing Power

    Chapter 3 CHAPTER Managing Power Your tablet PC operates either on external AC power or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.

  • Page 50: Ac Adapter

    AC Adapter CAUTION: The AC adapter is designed for use with your tablet PC only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your tablet PC is for use in the country where you purchased your tablet PC.

  • Page 51: Battery Pack

    Battery Pack The battery pack is the internal power source for the tablet PC. It is rechargeable using the AC adapter. The operating time of a fully charged battery pack depends on how you are using the tablet PC. When your applications often access peripherals, you will experience a shorter operating time.

  • Page 52: Initializing The Battery Pack

    Initializing the Battery Pack You need to initialize a new battery pack before using it for the first time or when the actual operating time of a battery pack is much less than expected. Initializing is the process of fully charging, discharging, and then charging.

  • Page 53: Replacing The Battery Pack

    By Gas Gauge On the exterior side of the battery pack is a gas gauge for displaying the estimated battery charge. When the battery pack is not installed in the tablet PC and you want to know the battery charge, you can press the switch with a pointed device to see the corresponding value of indicator segment that light green.
  • Page 54 3. Remove the four screws securing the battery compartment cover and remove it. 4. Remove the two screws securing the battery pack to the battery compartment ( ) and, pull on the ribbon strip to lift the battery pack off the tablet PC ( ). Managing Power...

  • Page 55: Battery Low Signals And Actions

    5. Fit another battery pack into place and secure with two screws. 6. Replace the battery compartment cover and secure with four screws. Battery Low Signals and Actions Battery Low occurs when the battery has approximately 10 % (Windows default setting) of its charge remaining. The tablet PC’s Battery Charge Indicator ( ) blinks red to alert you to take actions.

  • Page 56: Power Management

    Power Management Your tablet PC supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows XP, power supply to different tablet PC components is controlled on an as-needed basis.

  • Page 57: Hibernation

    Hibernation NOTE: Make sure that the hibernation feature is enabled in the Hibernate tab of the Power Options Properties from the Control Panel in Windows XP. Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the computer can be turned off.

  • Page 58: Power-Saving Tips

    Power-Saving Tips Aside from enabling your tablet PC’s power saving mode (see previous section), you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management. Decrease the LCD brightness to the lowest comfortable level. Shorten the length of time before Windows turn off the display.

  • Page 59: Chapter 4 Expanding Your Tablet Pc

    Chapter 4 CHAPTER Expanding Your Tablet PC You can expand the capabilities of your tablet PC by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter.

  • Page 60: Connecting A Usb Device

    Connecting a USB Device Your tablet PC has two USB ports for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB ports support transfer rates up to 12 MB/s for USB 1.1 devices and 480 MB/s for USB 2.0 devices. To connect a USB device, simply plug the device cable to one of the USB ports ( Expanding Your...

  • Page 61: Using Smart Cards

    Using Smart Cards Your tablet PC has a smart card slot for additional security feature, providing tamper-proof storage of user and account identity. A smart card is a type of plastic card embedded with a computer chip that stores and transacts data between you (user) and the tablet PC.

  • Page 62: Using Pc Cards (Depending On Your Model)

    Using PC Cards (depending on your model) Your tablet PC has a PC card slot which supports type II card and CardBus specifications. Inserting and Removing a PC Card NOTE: Some PC cards require additional system resources. Before using such PC card, you may have to free other system resources for the PC card.
  • Page 63 2. Select (highlight) the PC card from the list to disable the card. 3. Push the eject button and the card will slide out slightly. 4. Pull the card out of the slot. Expanding Your...

  • Page 64: Using Expresscards (Depending On Your Model)

    Using ExpressCards (depending on your model) NOTE: The ExpressCard interface is not compatible with the PC card interface. You need optional adapters for using PC cards if your tablet PC comes with the ExpressCard slot. Your tablet PC may have an ExpressCard slot instead of a PC card slot. ExpressCard supports the USB 2.0 serial data interface (supporting speeds of up to 480 Mbps), improving speed in data transfer while conserving power usage.

  • Page 65: Inserting And Removing An Expresscard

    Inserting and Removing an ExpressCard To insert an ExpressCard: 1. Locate the ExpressCard slot ( ) on the rear of the tablet PC. 2. Slide the ExpressCard, with its label facing up, all the way into the slot until the rear connectors click into place. 3.

  • Page 66: Using The Docking Station

    Using the Docking Station A docking station is available as an option. This device eliminates the hassles of having you connect and disconnect the various cables when carrying your tablet PC around and allows a variety of peripherals to be connected including a headphone or microphone, etc.

  • Page 67: Chapter 5 Using Bios Setup And System Recovery Feature

    Chapter 5 CHAPTER Using BIOS Setup and System Recovery Feature BIOS Setup Utility is a program for configuring the BIOS (Basic Input/ Output System) settings of the tablet PC. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the tablet PC hardware can understand.

  • Page 68: When And How To Use Bios Setup

    When and How to Use BIOS Setup When to Use You need to run BIOS Setup utility when: You see an error message on the screen requesting you to run BIOS Setup utility. You want to restore the factory default settings. You want to modify some specific settings according to the hardware.
  • Page 69 The BIOS Setup utility screen can be divided into four areas: On the top is the menu bar containing the titles of the available menus. Each menu title brings a specific menu. The left column of the menu displays the menu items. The right column of the menu provides more detailed information when a menu item is highlighted.

  • Page 70: Moving Around And Making Selections

    Moving Around and Making Selections You must go through two or three levels to complete the setting for an item. In most cases, there are two levels: menu title and submenu. Use the arrow buttons to move around and make selections. Button information can be found at the bottom of the screen.

  • Page 71: Information Menu

    Information Menu The Information menu contains the basic configuration information of the system. Using BIOS Setup...

  • Page 72: Main Menu

    Main Menu The Main menu contains the system time and date, as well as the USB setting of the system. System Time sets the system time. System Date sets the system date. Legacy USB Support enables or disables the system’s support for Legacy USB device in DOS mode.

  • Page 73: Advanced Menu

    Advanced Menu The Advanced menu contains the advanced settings as shown next. Total Graphics Memory allows you to select the amount of total graphics memory (pre-allocated + fixed + DVMT) for use by the internal graphics device. DVMT Graphics Memory shows the size of DVMT graphics memory. HDD Preheat allows your system to automatically turn on the optional heater when temperature of the hard disk drive is lower than 5 NOTE: The optional heater can function when your tablet PC is connected to AC power...

  • Page 74: Security Menu

    Security Menu The Security menu contains the TPM (Trusted Platform Module) setting. The TPM is a component on your tablet PC’s mainboard that is specifically designed to enhance platform security above-and-beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.

  • Page 75: Boot Menu

    Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system.

  • Page 76: Exit Menu

    Exit Menu The Exit menu displays ways of exiting BIOS Setup utility. After finishing with your settings, you must save and exit so that the changes can take effect. Exit Saving Changes saves the changes you have made and exits BIOS Setup utility.

  • Page 77: When And How To Use The System Recovery Feature

    When and How to Use the System Recovery Feature When to Use You need to run System Recovery when: Your tablet PC does not start correctly. Your Windows operating system does not start at all. You want to restore the factory default Windows settings. Starting System Recovery To run System Recovery: 1.
  • Page 78 1. The recovery software is solely the purpose of reinstalling or restoring software associated with the hard disk of this operating GETAC machine. 2. Except the above, no other use is granted hereunder. **************************************** (1)Yes, I agree to the provisions of this agreement and wish to continue.

  • Page 79: Chapter 6 Using The Tpm, Easytap, And G-Manager Utilities

    Chapter 6 CHAPTER Using the TPM, EasyTap, and G-Manager Utilities Your tablet PC comes with an added security feature known as the TPM (Trusted Platform Module) – a component on your tablet PC’s mainboard that is specifically designed to enhance platform security above-and- beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.

  • Page 80: Using Tpm (Trusted Platform Module)

    Using TPM (Trusted Platform Module) TPM is a hardware-based security feature that can be used to create and manage computer-generated digital certificates. When combined with security software, the TPM enhances existing network and computer security by enabling features such as file protection capabilities and protected e-mail.

  • Page 81: Using The Easytap Utility

    Using the EasyTap Utility The EasyTap utility allows you to activate or operate certain functions on your tablet PC. To start up the EasyTap utility: 1. Press the Menu button on your tablet PC. Using the TPM...
  • Page 82 2. Upon pressing the Menu button, the following screen appears. The following table shows the various functions on the EasyTap utility screen. Operation EasyTap Description Switches the keypad lock ON and OFF. Press the button one second to turn ON (lock) and continuously for more than three seconds to turn OFF (unlock).
  • Page 83 Operation EasyTap Description Closes and exits the EasyTap utility screen. Switches the RF module OFF and ON (wireless LAN, Bluetooth, 3G). Upon restarting your system, wireless LAN radio would be on even if you turned it off before system shutdown. Toggles the system power saving mode between OFF / Work / Quick and Power Saving.
  • Page 84 Operation EasyTap Description Toggles between LCD, VGA (external device e.g., monitor), and BOTH (LCD and external device). Switches the display output when external devices are connected. If the external device is not connected, the choice would only be LCD. Upon restarting your system, the setting would be LCD only.
  • Page 85 Operation EasyTap Description Increases or decreases the sound volume. This function adjusts the volume of sound output both from the speakers and headphones. It is synchronized with your Windows main volume controller. Upon restarting your system, Windows will memorize the last setting before system shutdown.

  • Page 86: Quick Button Setup Utility

    Operation EasyTap Description System enters “black-out” mode by turning off the LCD display, LED indicators, touchscreen, and sound volume. Press the power button ( ) to wake up the system from “black-out” mode. Quick Button Setup Utility By default, the five quick launch buttons on the EasyTap utility have pre-assigned functions.
  • Page 87 To re-define: ) and the Quick 1. Click the Quick Button Setup utility button ( Button Setup window appears as shown next. Using the TPM...
  • Page 88 2. To re-assign a program to a button, click to select a particular button to change (e.g., Explorer), then click the folder icon. 3. The Select a File to Open dialog box appears as shown next. Select the desired program, then click Open to complete the process. Using the TPM 6-10...
  • Page 89 4. You can change the image appearing on the button by clicking the Select Image icon. 5. The Select Picture dialog box appears as shown next. Using the TPM 6-11...
  • Page 90 6. After selecting the image file, the appropriate icon will then appear in the button. To launch the program, click the particular quick launch button. Click Set to complete the changes. Using the TPM 6-12...

  • Page 91: Using The G-Manager Utility

    Starting G-Manager You can start up G-Manager by any of the following methods: Click Start All Programs GETAC Utility, or Right-click on the GETAC Utility icon ( ) located on the system tray and click G-Manager. Using the TPM 6-13...
  • Page 92 The following screen appears. Using the TPM 6-14...

  • Page 93: System Tab

    System Tab The System tab provides an overview of the system status. The component to be viewed is selected from the tree view list on the left side of the screen. It contains eight major components namely: Summary System Sensors Disk Drives Battery Signal Strength...

  • Page 94: Battery Tab

    The status of the selected component is displayed on the right side of the screen. Battery Tab The Battery tab allows you to minimize deterioration of the battery thereby ensuring a longer battery life. At most two batteries may be supported.

  • Page 95: Battery Information

    Battery Information The upper portion of the Battery tab contains a live update of information about the selected battery. NOTE: When the percentage % Left is less than 10 % then the value will be displayed in red. When an abnormal battery condition is detected Battery Status value will be displayed in red.
  • Page 96 To perform a gauge reset: 1. Click Start to perform a gauge reset and the following screen appears. 2. Click Yes to start the gauge reset session and the following screen appears. The percentage of completion will be shown on the progress bar. Depending on the number of battery, the screen will show the corresponding number of batteries to perform gauge reset.

  • Page 97: Light Sensor

    Light Sensor The Light Sensor tab allows you to adjust the LCD brightness based on your surrounding’s lighting condition. Sensor Mode The left portion of the Light Sensor tab allows you to select the sensor mode. Normal – light sensor sensitivity is set at normal environment lighting condition.

  • Page 98: Eco Tab

    The lower left portion of the Light Sensor tab shows the selected sensor mode’s graph. The upper right portion of the Light Sensor tab shows the active profile based on your selection on sensor mode. The middle right portion of the Light Sensor tab shows the environment luminance (degree of Lux from weak to bright) as detected by your tablet PC’s light sensor.

  • Page 99: Eco Information

    ECO Information Depending on the system, the left portion of the ECO tab shows the available profile to manage the system’s power consumption. Active Profile The right upper portion of the ECO tab shows the name of the current profile selected. Profile Settings The lower right portion of the ECO tab contains the following: Turn on/off the following for power saving: WWAN, Bluetooth,...

  • Page 100: Ignition Tab

    The amount of time between turning off your vehicle and tablet PC shutdown would depend on your setting on the next section Delay Time. This feature is only available when your tablet PC is docked to the GETAC docking station.. Using the TPM 6-22...

  • Page 101: Monitoring Tab

    Delay Time The right portion of the Ignition tab allows you to set the delay time (20 seconds, 30 seconds, 45 seconds, 1 minute, or 2 minute) to shut down the system when you turn off vehicle ignition. This will help prevent the tablet PC from using up the vehicle’s battery power thereby causing poor vehicle startup.
  • Page 102 Items to Monitor The left portion of the Monitoring tab allows you to select which item to monitor by selecting on the checkbox before each item. When enabled the status of the selected Item is displayed and a live update is shown on the screen.

  • Page 103: Monitoring Options

    Monitoring Options The right portion of the Monitoring tab allows you to set how the monitored items are displayed. The changes made to the monitoring options are immediately implemented on the monitoring window. Always On Top – allows the monitoring window to remain on top of your display.

  • Page 104: Antenna Tab

    Antenna Tab The Antenna tab allows your system to connect to an external GPS or 3G antenna. Select the checkbox I have external GPS antenna or 3G antenna to allow your system to connect to an external GPS/3G antenna. When this option is selected, you can choose the following: Switch to external GPS antenna signal when system is docked.

  • Page 105: Gps Status Tab

    GPS Status Tab The GPS Status tab shows the GPS signal availability status of the system’s GPS module, allowing you to check if the GPS feature is working properly. You may also need to install a third-party map of your particular location (purchased separately).
  • Page 106 Message Log The lower left portion of the GPS Status tab shows a summary of raw data string received from satellites which can only be viewed but not editable. The Message Log window is auto-scrollable and will be cleared as soon as GPS signal is disconnected.
  • Page 107 GPS COM port is not available – When other GPS program is running, a warning window pops-up and displays the message “GPS COM port not available! Please close all GPS program and try again.” to inform you to close the other GPS program to free up the COM port.

  • Page 108: Chapter 7 Caring For The Tablet Pc

    Chapter 7 CHAPTER Caring for the Tablet PC Taking good care of your tablet PC will ensure a trouble-free operation and reduce the risk of damage to your tablet PC. This chapter gives you guidelines covering these areas of maintenance: How to protect the tablet PC What to note when using and storing the tablet PC How to clean the tablet PC...

  • Page 109: Protecting The Tablet Pc

    Protecting the Tablet PC To safeguard the integrity of your tablet PC data as well as the tablet PC itself, you can protect the tablet PC in several ways as described in this section. Using the Cable Lock You can use a Kensington-type cable lock to protect your tablet PC against theft.

  • Page 110: Taking Care Of The Tablet Pc

    Taking Care of the Tablet PC Location Guidelines For optimal performance, use the tablet PC where the recommended temperature is between 10 °C (50 °F) and 35 °C (95 °F) – actual operating temperature depending on product specifications. Avoid placing the tablet PC in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust.

  • Page 111: Cleaning Guidelines

    Cleaning Guidelines Never clean the tablet PC with its power on. Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the tablet PC. Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the display.

  • Page 112: Touchscreen Guidelines

    To maintain the battery pack’s operating efficiency, store it in a cool dark place removed from the tablet PC and with 30 % ~ 40 % charge remaining. Important guidelines when using the battery pack. When installing or removing the battery pack take note of the following: –...
  • Page 113 Use the touchscreen within the intended area only. The display area and touchscreen operating area is the same. Do not use excessive force on the display. Avoid placing objects on top of the display as this may cause the glass to break thereby damaging the display.

  • Page 114: When Traveling

    When Traveling Before traveling with your tablet PC, make a backup of your hard disk data into flash disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure that the battery pack is fully charged. Make sure that the tablet PC is turned off.

  • Page 115: Chapter 8 Troubleshooting

    Chapter 8 CHAPTER Troubleshooting Tablet PC problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems.

  • Page 116: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the tablet PC is causing the problem. Make sure that you turn on all peripheral devices before turning on the tablet PC.

  • Page 117: Solving Common Problems

    Solving Common Problems For easy reference, the problems are divided into these categories. Problem Type Go to Battery Problems P. 8-4 Bluetooth Wireless Transmission Problems P. 8-4 Display Problems P. 8-5 ExpressCard Problems P. 8-5 Hardware Device Problems P. 8-5 Hard Disk Drive Problems P.

  • Page 118: Battery Problems

    Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected. Make sure that the battery is not too hot or cold. Allow time for the battery pack to return to room temperature. Make sure that the battery pack is installed correctly.

  • Page 119: Display Problems

    Display Problems Nothing appears on the screen. During operation, the screen may automatically turn off as a result of power management. Press any key to see if the screen comes back. The brightness level might be too low. Increase brightness by pressing the button.

  • Page 120: Hard Disk Drive Problems

    Make sure if any device driver needs to be installed. (Refer to the documentation that came with the device.) Make sure if the device needs any jumper or switch settings. (Refer to the documentation that came with the device.) Check the cables or power cords for correct connections. For an external device that has its own power switch, make sure that the power is turned on.

  • Page 121: Wireless Lan Problems

    Make sure that the user name or password is correct. Wireless LAN Problems I cannot use the wireless LAN feature. Make sure that the wireless LAN feature is turned on. Transmission quality is poor. Your tablet PC may be in an out-of-range situation. Move your tablet PC closer to the Access Point or another wireless LAN device it is associated with.

  • Page 122: Pc Card Problems

    If the operating radio channel is in poor quality, change the Access Point and all the wireless station(s) within the BSSID to another radio channel. Your tablet PC may be in an out-of-range situation. Move your tablet PC closer to the Access Point it is associated with. Make sure that your tablet PC is configured with the same security option (encryption) to the Access Point.

  • Page 123: Power Management Problems

    Power Management Problems The tablet PC does not enter Standby or Hibernation mode automatically. If you have a connection to another computer, the tablet PC does not enter Standby or Hibernation mode if the connection is actively in use. Make sure that the Standby or Hibernation time-out is enabled. The tablet PC does not enter Standby or Hibernation mode immediately.

  • Page 124: Sound Problems

    Sound Problems No sound is produced. Make sure that the volume control is not set too low. Increase volume by pressing the button. Make sure that the tablet PC is not in Standby mode. If using an external speaker, make sure that the speaker is properly connected.

  • Page 125: Other Problems

    When the tablet PC is connected to AC power and hard disk drive temperature is below 5 C, the optional heater would turn on as indicated by the hard disk drive / heater indicator ( ) glowing in red (if the item HDD Preheat under the Advanced menu of your BIOS Setup is set at Enabled).

  • Page 126: Resetting The Tablet Pc

    Resetting the Tablet PC You may have to reset (reboot) your tablet PC on some occasions when an error occurs and the program you are using hangs up. If the tablet PC operation seems to hang up, first wait. It is possible that the tablet PC is processing data.

  • Page 127: Appendix A Specifications

    Appendix A APPENDIX Specifications NOTE: Specifications are subject to change without any prior notice. Parts Specifications Intel® Stealy processor, 512 KB L2 cache, 800 MHz RAM (system) Up to 1 GB DDRII DRAM Display Panel 8.4-inch wide TFT LCD, SVGA transmissive display, integrated touchscreen, duo mode to support digitizer (option), 800 Nits LCD brightness (option), sunlight-readable (option) Audio...
  • Page 128 Parts Specifications Dimension (W×D) 280×184×32 mm (11×7.2×1.3 inch) Weight 1.4 kg (3.09 lb) Operating: –20 °C (–4 °F) to 60 °C (140 °F) Environment Temperature Storage: –40 °C (–40 °F) to 75 °C (167 °F) Thermal shock: –20 °C (–4 °F) to 60 °C (140 °F) Humidity Relative: 0 % to 95 % non-condensing Compliance...

  • Page 129: Appendix B Regulatory Information

    Appendix B APPENDIX Regulatory Information This appendix provides regulatory statements and safety notices on your tablet PC. NOTE: Marking labels located on the exterior of your tablet PC indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.

  • Page 130: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 131: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

  • Page 132: About The Ac Adapter

    ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.
  • Page 133 Caution (for USA Users) To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord. Regulatory Information...

  • Page 134: On The Use Of The Rf Device

    On the Use of the RF Device NOTE: The information in this section applies to models with the wireless LAN module. USA and Canada Safety Requirements and Notices Radio Frequency Interference Requirements and SAR The FCC with its action in ET Docket 93-62 has adopted a safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC certified equipment.
  • Page 135 Explosive Device Proximity Warning WARNING: Do not operate a portable transmitter (such as a wireless network device) near unshielded blasting caps or in an explosive environment unless the device has been modified to be qualified for such use. Use on Aircraft Caution CAUTION: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices because their signals could interfere with critical aircraft instruments.

  • Page 136: European Union Ce Marking And Compliance Notices

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. CAUTION: The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any changes or modification to said product not expressly approved by the manufacturer could void the user’s authority to operate this device.
  • Page 137 Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC. Portuguese Este produto cumpre com as normas da Diretiva Européia 1999/5/EC. Spanish Este producto cumple con las normas del Directivo Europeo 1999/5/EC.
  • Page 138 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “Turning Off the Wireless LAN Radio.”...
  • Page 139 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) Indoors Outdoors 2400 – 2446.5 10 mW Not permitted 2446.5 – 2483.5 100 mW 100 mW on private property with Ministry of Defense approval Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.
  • Page 140 产 质 称 量标 质 项 称 铅 镉 六 铬 (Pb) (Cd) (Hg) (Cr+6) (PBB) (PBDE) 金 料 路 组 盘 驱 键盘 组 线 连 线 钮 热 (金 喇 SJ/T 11363-2006 规 该 质 该 质 料 量...
  • Page 141 项 1. 铅 铅为 85wt% 内 连 锡 铅锡 压 组 ・ 质 料 内 铅量 内 铅量 组 料 连 理 针 铅 量 过 80wt% 85wt% 5. 铅 路 内 铸 锡 铝 铅量 盘状 数组 层 料 铅...

Table of Contents
