  • Page 1 E100 USER’S MANUAL Rugged Mobile Computing Solutions...
  • Page 2 All brand and product names are trademarks or registered trademarks of their respective companies. NOTE The information in this manual is subject to change without notice. For the latest version of the manual, please visit the Getac website at www.getac.com.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Getting Started ............. 1-1 Getting the Tablet PC Running ..........1-2 Unpacking ................1-2 Installing the Battery Pack and Connecting to AC Power 1-3 Using the Hand Strap ............1-6 Turning On and Off the Tablet PC ........1-7 Taking a Look at the Tablet PC ..........
  • Page 4 Connecting to another Bluetooth Device ....... 2-14 Using the 3G Feature (Optional) .......... 2-17 Installing the SIM Card ............. 2-17 Connecting to 3G Network ..........2-19 Using the Camera (Optional) ..........2-23 Using the Fingerprint Scanner (Optional) ......2-24 Chapter 3 Managing Power ............
  • Page 5 System Recovery ..............5-10 Chatper 6 Using Special Utilities ........... 6-1 Using the OSD Control Panel ..........6-2 Quick Button Setup ............6-6 Using G-Manager ..............6-8 Starting G-Manager ............6-8 System Tab ................6-9 Battery Tab ................ 6-10 ECO Tab ................6-12 ECO Information ...............
  • Page 6 Display Problems ..............8-4 Hardware Device Problems ..........8-4 Hard Disk Drive Problems ........... 8-5 LAN Problems ..............8-5 PC Card Problems ..............8-5 Power Management Problems .......... 8-6 Software Problems ............. 8-6 Sound Problems ..............8-7 Startup Problems ..............8-7 Wireless LAN Problems ............

  • Page 7: Chapter 1 Getting Started

    Chapter 1 Getting Started Congratulations on purchasing this rugged Tablet PC. This chapter first tells you step by step how to get the Tablet PC up and running. Then, you will find a section briefly introducing the external components of the Tablet PC.

  • Page 8: Getting The Tablet Pc Running

    Getting the Tablet PC Running Unpacking After unpacking the shipping carton, you should find these standard items: Tablet PC  Accessories:   AC adapter  AC power cord  Hand strap  Screen protector film (already attached to the screen) ...

  • Page 9: Installing The Battery Pack And Connecting To Ac Power

    Installing the Battery Pack and Connecting to AC Power The Tablet PC operates either on the external AC power or internal battery power. It is suggested that you use AC power when starting up the Tablet PC for the very first time. 1.
  • Page 10 4. Fit the battery pack into place (). Tightening the two screws () is optional. The lack of the screws will not affect the rugged and waterproof feature of the Tablet PC. 5. Replace the battery cover and turn the latch clockwise to the lock position.
  • Page 11 6. Plug the DC cord of the AC adapter to the power connector of the Tablet  PC ( ). Plug the female end of the AC power cord to the AC adapter and  the male end to an electrical outlet ( 7.

  • Page 12: Using The Hand Strap

    Using the Hand Strap Align the four hooks of the hand strap with the four corresponding holes on the Tablet PC and tighten the screws. The hand strap allows you to firmly hold the Tablet PC by inserting your hand through the hand strap.

  • Page 13: Turning On And Off The Tablet Pc

    Turning On and Off the Tablet PC Turning On Press the power button ( ). The operating system such as Microsoft Windows should start. Turning Off When you finish a working session, you can stop the system by turning off the power or leaving it in Sleep or Hibernation mode: To...

  • Page 14: Taking A Look At The Tablet Pc

    Taking a Look at the Tablet PC Front Components Component Description See Also  Touchscreen Displays and receives information for the P. 2-2 Tablet PC.  Power Button Turns the power ON and OFF (Sleep mode P. 1-7 by default). The green LED beside the button glows when the power is on and blinks when the system is in Sleep mode.
  • Page 15 Component Description See Also  Microphone Receives sound and voice to record voice.  Light Sensor Senses the ambient light for automatic P. 6-2 adjustments of the display and keypad P. 6-14 backlight. The features can be enabled through OSD Control Panel and G-Manager. NOTE: Do not cover the sensor when in use.
  • Page 16 Component Description See Also Hard Disk Lights green when hard disk drive is being accessed. Drive Lights red when the optional heater is on during system operation. Blinks red when the optional heater is in an abnormal state.  Numeric Provides number, Delete, and Enter keys.

  • Page 17: Rear Components

    Rear Components Component Description See Also  Camera Lens Allows you to use the camera function. P. 2-23 (optional)  Battery Pack Inside is the battery pack that supplies P. 3-3 power to your Tablet PC when external power is not connected. Contains the SIM card slot (optional).

  • Page 18: Right-Side Components

    Right-Side Components Component Description See Also  Kensington Lock Locks the Tablet PC to a stationary object P. 7-2 for security.  Stylus Serves as the input device by tapping on P. 2-2 the touchscreen to make selections and enter information. ...

  • Page 19: Top Components

    Top Components Component Description See Also  Smart Card Accepts a Smart Card for additional P. 4-2 Reader security feature.  Can be one of the below depending on your model: PC Card Slot Accepts a PC card for additional P.

  • Page 20: Bottom Components

    Bottom Components Component Description See Also  3G Pass-through Connects to the external antenna for Connector 3G transmission. (optional) NOTE: Must be connected via a docking station.  GPS Pass-through Connects to the external antenna for Connector GPS receiver. (optional) NOTE: Must be connected via a docking station.

  • Page 21: Operating Your Tablet Pc

    Chapter 2 Operating Your Tablet PC This chapter provides information about the use of the Tablet PC. If you are new to Tablet PCs, reading this chapter will help you learn the operating basics. If you are already a computer user, you may choose to read only the parts containing information unique to your Tablet PC.

  • Page 22: Using The Touchscreen

    Using the Touchscreen   The screen of your Tablet PC is touch-sensitive. You can control the location of the cursor/pointer on the screen using your finger or the included stylus to communicate with the Tablet PC.

  • Page 23: Using Multi-Touch Gestures (Optional)

    Here are some common terms that you should know when using the touchscreen: Term Action Click/Point Tap gently on the touchscreen. Double-click Tap twice on the touchscreen rapidly. Drag and drop Press lightly on the touchscreen and move your finger until you reach your destination (drag).
  • Page 24 Gestures Actions Descriptions = finger down; = finger up) Zoom Use zooming to make (Pinch) an item (a photo for example) on the screen larger or smaller. The gesture works in applications that Move two fingers apart/toward each support mouse wheel other.
  • Page 25 Gestures Actions Descriptions = finger down; = finger up) Two- The function is defined finger by applications that support the specific gesture. Tap two fingers at the same time (where the target is in the midpoint between the fingers). Flicks Flick left or right to navigate back and forward in a browser...

  • Page 26: Using The Input Panel

    Using the Input Panel Use the Input Panel to enter text and perform various keyboard functions. There are two types of Input Panels for you to use in Windows 7: Touch Keyboard allows you to enter text by tapping the keys with your ...

  • Page 27: Using The Keypad

    Using the Keypad The keypad of your Tablet PC can be divided into three areas: Control buttons  Numeric, Delete (Del), and Enter (Ent) keys  Cursor-control keys  Control Buttons Located on top of the keypad are three control buttons: Fn button toggles the Fn keylock ON and OFF.

  • Page 28: Numeric Keypad With Alternative Functions

    Numeric Keypad with Alternative Functions Shown below is the 12-key numeric keypad with Delete and Enter keys. When the Fn keylock is ON (indicated by the icon on the taskbar), the keys with orange icons provide alternative functions as described below. ...

  • Page 29: Cursor-Control Keys With Alternative Functions

    Cursor-Control Keys with Alternative Functions Cursor-control keys control cursor movement. The word “cursor” refers to the indicator on the screen (except for pointer on screen) that lets you know exactly where on your screen anything you type will appear. It can take the form of a vertical or horizontal line, a block, or one of many other shapes.

  • Page 30: Using The Network Features

    Using the Network Features Using the LAN The internal 10/100/1000Base-T LAN (Local Area Network) module allows you to connect your Tablet PC to a network. It supports data transfer rate up to 1000 Mbps. To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector ( ) on the Tablet PC and the other end to the network hub.
  • Page 31 Technology 802.11a 802.11g 802.11n Stated Maximum 100 Mbps or more Throughput (Mbps) 11, 5.5, 2, 1 Data Rates (Mbps) 54, 36, 18, 9 100 ~ 210 Band (GHz) 2.4 / 5 2.412 ~ 2.462 Modulation OFDM (Orthogonal OFDM (Orthogonal Spatial multiplexing, Technology Frequency Division Frequency Division...

  • Page 32: Connecting To A Wireless Network

    red X. (In case you have previously turned it off in Windows Mobility Center, be sure to turn it on when using the function the next time.) Connecting to a Wireless Network 1. Make sure that the WLAN function is enabled (as described above). 2.

  • Page 33: Using The Bluetooth Feature (Optional)

    Using the Bluetooth Feature (Optional) The Bluetooth technology allows short-range (about 10 meters) wireless communications between devices without requiring a cable connection. Data can be transmitted through walls, pockets and briefcases as long as two devices are within range. The status of the Bluetooth connection is indicated by the Bluetooth icon located in the taskbar.

  • Page 34: Connecting To Another Bluetooth Device

    3. The Bluetooth function is enabled by default, as indicated by the Bluetooth icon on the Windows taskbar. (In case you have previously disabled the function in the Bluetooth utility, be sure to enable it when using the function the next time.) Connecting to another Bluetooth Device 1.
  • Page 35 4. The Add New Connection Wizard window appears. Select Express Mode (Recommended), and then click Next. 5. Select the device to connect to and click Next.
  • Page 36 6. Depending on the type of Bluetooth device that you want to connect to, you will need to enter the pertinent information. For detailed information on using the Bluetooth Utility, see the Bluetooth Utility Help.

  • Page 37: Using The 3G Feature (Optional)

    Using the 3G Feature (Optional) 3G is the third generation of mobile phone standards and technology after 2G. Services include wide-area wireless voice telephony and broadband wireless data, all in a mobile environment. Unlike IEEE 802.11 networks, 3G networks are “wide area cellular telephone networks”...
  • Page 38  3. Remove the two screws if existing ( ). Pull on the ribbon strip to lift the  battery pack off the Tablet PC ( 4. Locate the SIM card slot and push the SIM card into the slot. Make sure the beveled corner on the SIM card is facing towards the Tablet PC and that the golden contact area on the card is facing downwards.

  • Page 39: Connecting To 3G Network

    5. Replace the battery pack. 6. Replace the battery cover and turn the latch clockwise to the lock position. Connecting to 3G Network Turning On/Off the 3G Radio 1. Press the Menu button on your Tablet PC to open the OSD Control Panel. 2.
  • Page 40 3. Make sure that the 3G Utility (OneClick Internet) has 3G radio turned on. Setting up a 3G Connection To set up a 3G connection for the first time, follow these steps: 1. Make sure that the SIM card is inserted and the 3G function is enabled (as described above).
  • Page 41 4. If necessary, enter the PIN of your SIM card. 5. If the radio is currently off, click to turn on the radio. 6. Click Settings. You will be in the Profile page. Click to set up a new profile. 7.
  • Page 42 Managing contacts from SIM and Outlook  GPS Management (for models having the GPS module) ...

  • Page 43: Using The Camera (Optional)

    Using the Camera (Optional) You can use G-Camera to perform the following: Take pictures  Record video  Path tracking and capture (for models having the GPS module)  GPS information and settings (for models having the GPS module))  To start G-camera, double click the G-Camera shortcut icon on the Windows desktop.

  • Page 44: Using The Fingerprint Scanner (Optional)

    Using the Fingerprint Scanner (Optional) The fingerprint scanner provides a strong authentication mechanism based on fingerprint recognition. You can log on to your computer or sign in to a web site with your fingerprint instead of a password. You can also encrypt files and folders with your fingerprint.
  • Page 45 You can then use the Fingerprint Software to set up how the fingerprint authentication works. For detailed information, click Start  All Programs  Fingerprint Software  Help.

  • Page 47: Chapter 3 Managing Power

    Chapter 3 Managing Power Your Tablet PC operates either on external AC power or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.

  • Page 48: Ac Adapter

    AC Adapter     The AC adapter serves as a converter from AC (Alternating Current) to DC (Direct Current) power because your Tablet PC runs on DC power, but an electrical outlet usually provides AC power. It also charges the battery pack when connected to AC power.

  • Page 49: Battery Pack

    Battery Pack The battery pack is the internal power source for the Tablet PC. It is rechargeable using the AC adapter. The operating time of a fully charged battery pack depends on how you are using the Tablet PC. When your applications often access peripherals, you will experience a shorter operating time.

  • Page 50: Checking The Battery Level

    Checking the Battery Level By Operating System You can check the approximate battery level using the battery meter function of the operating system. To read the battery level in Windows, click the battery icon on the taskbar. By Gas Gauge On the exterior side of the battery pack is a gas gauge for displaying the estimated battery charge.

  • Page 51: Replacing The Battery Pack

    Replacing the Battery Pack   If you often rely on battery power for a long period of time while traveling, you may consider the purchase of an additional battery pack from your dealer and keep it with you in a fully charged state as a backup. To replace the battery pack, follow these steps: 1.

  • Page 52: Battery Low Signals And Actions

     3. Remove the two screws if existing ( ). Pull on the ribbon strip to lift the  battery pack off the computer ( 4. Fit another battery pack into place. 5. Replace the battery cover and turn the latch clockwise to the lock position.

  • Page 53: Power Management

    Power Management Your Tablet PC supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows, power supply to different Tablet PC components is controlled on an as-needed basis.

  • Page 54: Hibernation

    Hibernation Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the computer can be turned off. When you use the hibernation feature, you do not have to close the applications.

  • Page 55: Power-Saving Tips

    Power-Saving Tips Aside from enabling your Tablet PC’s power saving mode (see previous section), you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management.  Decrease the LCD brightness to the lowest comfortable level. ...

  • Page 57: Expanding Your Tablet Pc

    Chapter 4 Expanding Your Tablet PC You can expand the capabilities of your Tablet PC by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter.

  • Page 58: Using Smart Cards

    Using Smart Cards Depending on your model, your Tablet PC has one or two smart card readers. With an embedded microcontroller, smart cards have the unique ability to store large amounts of data, carry out their own on-card functions (e.g., encryption and mutual authentication), and interact intelligently with a smart card reader.

  • Page 59: Using Pc Cards

    Using PC Cards The PC card slot supports type II card and CardBus specifications.   To insert a PC card: 1. Locate the PC card slot (the one with the eject button). 2. Slide the PC card, with its label facing up, into the slot until the eject button pops out.

  • Page 60: Connecting A Usb Device

    Connecting a USB Device Your Tablet PC has two USB ports for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB ports support transfer rates up to 12 MB/s for USB 1.1 devices and 480 MB/s for USB 2.0 devices.

  • Page 61: Connecting A Serial Device

    Connecting a Serial Device Your computer has a serial port for connecting a serial device such as a serial mouse or serial communication device. Follow this procedure to connect a serial device: 1. Make sure the computer is not turned on. 2.

  • Page 62: Connecting An Audio Device

    Connecting an Audio Device For higher audio quality, you can send sound through external audio devices such as speakers, headphones, or earphone set using the headphone out connector.

  • Page 63: Using The Docking Station

    Using the Docking Station Docking Station is available as an option. The device eliminates the hassles of having you connect and disconnect the various cables when carrying your Tablet PC around and allows a variety of peripherals to be connected. 1.

  • Page 65: Using Bios Setup And System Recovery

    Chapter 5 Using BIOS Setup and System Recovery BIOS Setup Utility is a program for configuring the BIOS (Basic Input/ Output System) settings of the Tablet PC. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the Tablet PC hardware can understand.

  • Page 66: Bios Setup

    Ent again to perform the first option (Launch System Setup). The BIOS Setup Utility main screen appears as shown next. Information Main Advanced Security Boot Exit Model E100-A Serial NO: 0123456789 Processor Info: Intel(R) Atom(TM) CPU N450 @1.66GHz Installed System Memory: 2048MB SATA Port 1 [INTEL SSDSA1M080G2GN] 80GB BIOS Revision: R0.51.070520F...

  • Page 67: Information Menu

    The Information menu contains the basic configuration information of the system. There are no user-definable items in this menu. Information Main Advanced Security Boot Exit Model E100-A Serial NO: 0123456789 Processor Info: Intel(R) Atom(TM) CPU N450 @1.66GHz Installed System Memory: 2048MB SATA Port 1 [INTEL SSDSA1M080G2GN] 80GB BIOS Revision: R0.51.070520F...

  • Page 68: Main Menu

    Main Menu The Main menu contains the various system settings. Information Main Advanced Security Boot Exit Item Specific Help System Time: :33:08] System Date: [05/14/2010] <Tab>, <Shift-Tab>, or <Enter> selects field. Legacy USB Support: [Enabled] SATA Controller Mode Option: [Enhanced] SATA AHCI Enable [Enabled] Help...

  • Page 69: Advanced Menu

    Advanced Menu The Advanced menu contains the advanced settings. Information Main Advanced Security Boot Exit Item Specific Help IGD – Memory Size: 128MB DVMT Graphics Memory: 120MB Select the amount of Power Button Delay: [Disabled] Main Memory that the AC Initiation: [Disabled] Internal Graphics Emergency Button:...
  • Page 70 HDD Preheat keeps the hard disk drive’s temperature above 3 C (37 Enabled during system shutdown period. When set to , the optional heater will automatically turn on whenever the hard disk drive’s temperature drops below 3 C (37 F). (The availability of this item depends on your model.) High Temperature Protection enables or disables the hard disk protection against high temperatures.

  • Page 71: Security Menu

    Security Menu The Security menu contains the security settings, which safeguard your system against unauthorized use. Information Main Advanced Security Boot Exit Item Specific Help Supervisor Password Is: Clear Set Supervisor Password [Enter] Enter Supervisor Password controls access to the Setup utility.

  • Page 72: Boot Menu

    Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. Information Main Advanced Security Boot Exit Item Specific Help Boot priority order: 1: USB KEY: Keys used to view or 2: SATA HDD: INTEL SSDSA1M080G2GN-(S1) configure devices: 3: SATA HDD: Up and Down arrows select...

  • Page 73: Exit Menu

    Exit Menu The Exit menu displays ways of exiting BIOS Setup Utility. After finishing with your settings, you must save and exit so that the changes can take effect. Information Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults...

  • Page 74: System Recovery

    System Recovery Use System Recovery when: The Windows operating system does not start at all.  You want to restore the system to the factory state.    To run System Recovery: 1. It is recommended that you connect the AC adapter to ensure power supply throughout the process.
  • Page 75 3. A message appears asking if you want to continue. Type 1 to continue. 4. A warning message appears asking if you accept the terms as shown on the screen. Type 1 to continue. 5. Type 1 again when the next message appears asking for confirmation. 6.
  • Page 76 10. When completed, the system restarts and displays Windows desktop.

  • Page 77: Using Special Utilities

    Chapter 6 Using Special Utilities Special utilities are provided for enhanced capabilities and management. This chapter describes how to use these utilities.

  • Page 78: Using The Osd Control Panel

    Using the OSD Control Panel The OSD (On Screen Display) Control Panel provides a user-friendly interface for you to quickly activate or operate certain functions on your Tablet PC with a simple tap of the screen. To open the OSD Control Panel, press the Menu button on your Tablet PC. The following screen appears.
  • Page 79 The following table shows the various functions on the OSD Control Panel. Icon Function Shows the current ON/OFF status of keypad lock. Shows the current ON/OFF status of Fn keylock. Opens the Help file explaining the OSD Control Panel. Opens the Quick Button Setup menu (refer to the next section for details).
  • Page 80 Icon Function Switches the LCD backlight to the next choice (MAX, AUTO, or MANUAL.) The word on the button indicates the current status. When set to MAX, the backlight is adjusted to the highest brightness level. When set to AUTO, the brightness will be automatically adjusted according to the current ambient light.
  • Page 81 Icon Function Opens the Input Panel by default. You can assign a different function to this button (refer to the next section for details). Allows you to adjust the sound volume by dragging the knob along the bar. Switches the system sound output OFF (mute) and ON. Allows you to adjust the LCD brightness level by dragging the knob along the bar.

  • Page 82: Quick Button Setup

    Quick Button Setup By default, the five quick buttons on the OSD Control Panel have pre-assigned functions. You can re-define the buttons: 1. Click the Quick Button Setup button ( ) on the OSD control panel and the Quick Button Setup window appears. 2.
  • Page 83 5. You can change the image appearing on the button by clicking the Select Image button. After selecting the image file, the original image on the button will be replaced. 6. Click Set to complete the changes.

  • Page 84: Using G-Manager

    GPS Status  Starting G-Manager You can start up G-Manager by any of the following methods: Click Start  All Programs  Getac Utility  G-Manager, or  Click and hold the icon located on the taskbar until a ring appears.

  • Page 85: System Tab

    System Tab The System tab provides system information. To view specific information, select the component from the list on the left side of the screen. The information of the selected component will be displayed on the right side of the screen.

  • Page 86: Battery Tab

    Battery Tab The Battery tab allows you to check the battery status and configure the battery. At most two batteries may be supported. Click Battery 1 or Battery 2 to view the information of each battery (if your model has a second battery). % Left ...
  • Page 87 Charging Mode The lower left portion of the screen allows you to select the charging mode. Normal Mode – The battery will be fully charged. When remaining  charge reaches below 95%, then charging will start until it is fully charged.

  • Page 88: Eco Tab

    4. Wait till the process is completed. Click Exit when finished. ECO Tab The ECO tab allows you to configure ECO modes (or called power profiles). To put the system into an ECO mode, use the ECO button (one of the buttons in the OSD Control Panel).

  • Page 89: Eco Information

    ECO Information The left portion of the screen lists the available power profiles (Quick, Power Saving, and Work). Each profile is a combination of power settings that results in different power consumptions. To change the settings of a profile, select (highlight) the profile name in the list. Profile Settings The right portion of the screen displays the settings of the current selected profile.

  • Page 90: Light Sensor Tab

    Light Sensor Tab The Light Sensor tab allows you configure how the light sensor works. Sensor Mode The left portion of the screen lists the sensor modes:  Normal – Light sensor sensitivity is set at normal environment lighting condition. ...

  • Page 91: Antenna Tab

    Environment Illuminance To have the keypad backlight automatically turn on in poor lighting environment, click the checkbox Automatic Keyboard Backlit. Click Apply or OK to save the changes. Antenna Tab The Antenna tab allows you to set if your system will automatically use the external GPS or 3G antenna when connected to the Docking Station.

  • Page 92: Ignition Tab

    Ignition Tab The Ignition tab allows you to configure how your system works with the vehicle ignition. Ignition Control When your system is connected to the Vehicle Dock (available as an option), you can have your system derive power from the vehicle and have the on/off of the vehicle ignition turn on/off your system.

  • Page 93: Monitoring Tab

    Monitoring Tab The Monitoring tab allows you to configure the monitoring function of G-Manager. Items to Monitor The left portion of the screen lists the items. Click the checkbox before an item to include it as a monitored component. Click Apply or OK to save the changes.
  • Page 94 Monitoring Interval – sets the frequency of updates on the monitoring  window (1/3/5/10/30 seconds or 1/5/30 minutes). Click Apply or OK to save the changes. Starting and Stopping the Monitoring To start monitoring, click START Monitor. The monitoring window similar to the one below appears displaying requested information at specified intervals.

  • Page 95: Gps Status Tab

    GPS Status Tab The GPS Status tab shows the GPS status for models having the GPS module. To start GPS positioning, click Start GPS. The screen displays:  Ongoing raw data strings in the Message Log section  Overhead satellite positions in the Satellite Map section ...

  • Page 97: Caring For The Tablet Pc

    Chapter 7 Caring for the Tablet Taking good care of your Tablet PC will ensure a trouble-free operation and reduce the risk of damage to your Tablet PC. This chapter gives you guidelines covering areas such as protecting, storing, cleaning, and traveling.

  • Page 98: Protecting The Tablet Pc

    Protecting the Tablet PC To safeguard the integrity of your Tablet PC data as well as the Tablet PC itself, you can protect the Tablet PC in several ways as described in this section. Using the Cable Lock You can use a Kensington-type cable lock to protect your Tablet PC against theft.

  • Page 99: Using An Anti-Virus Strategy

    Using an Anti-Virus Strategy You can install a virus-detecting program to monitor potential viruses that could damage your files. Using Action Center (for Windows 7) Action Center alerts you to take action on the following security essentials: Windows Firewall  Windows Update ...

  • Page 100: Taking Care Of The Tablet Pc

    Taking Care of the Tablet PC Location Guidelines  For optimal performance, use the Tablet PC where the recommended temperature is between 10 C (50 F) and 35 C (95 F) – actual operating temperature depending on product specifications. Avoid placing the Tablet PC in a location subject to high humidity, ...

  • Page 101: Cleaning Guidelines

    a screen saver or other software that prevents the power management from working. Cleaning Guidelines Never clean the Tablet PC with its power on. Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the Tablet PC. Gently wipe the display with a soft, lint-free cloth.

  • Page 102: Touchscreen Guidelines

    Also, charging will not start if the battery pack is not within the allowed temperature range. It is recommended that you do not charge the battery pack more than once a day. It is recommended that you charge the battery pack with the Tablet PC’s power off.
  • Page 103 Avoid using excessive force that may cause damage to the display. Use a soft cloth to remove dirt on the display. The touchscreen surface has a special protective coating that prevents dirt from sticking to it. Not using a soft cloth may cause damage to the special protective coating on the touchscreen surface.

  • Page 104: When Traveling

    When Traveling Before traveling with your Tablet PC, make a backup of your hard disk  data into flash disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure that the battery pack is fully charged. ...

  • Page 105: Chapter 8 Troubleshooting

    Chapter 8 Troubleshooting Tablet PC problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common Tablet PC problems.

  • Page 106: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the Tablet PC is causing the problem.  Make sure that you turn on all peripheral devices before turning on the ...

  • Page 107: Solving Common Problems

    Solving Common Problems Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected.  Make sure that the battery is not too hot or cold. Allow time for the ...

  • Page 108: Display Problems

    Make sure that the distance between the two devices are not over 10  meters or that there are no walls or other obstructions between the devices.  Make sure that the other device is not in “Hidden” mode.  Make sure that both devices are compatible.

  • Page 109: Hard Disk Drive Problems

    For an external device that has its own power switch, make sure that the  power is turned on. Hard Disk Drive Problems The hard disk drive error message appears on the screen. The hard disk drive has defects. Ask your dealer for help. ...

  • Page 110: Power Management Problems

    The PC card stops communicating properly.  The application may have been reset when the Tablet PC is turned off or in Sleep mode. Exit and restart the application. Power Management Problems The Tablet PC does not enter Sleep or Hibernation mode automatically.

  • Page 111: Sound Problems

    Sound Problems No sound is produced. Make sure that the volume control is not set too low. Increase the  volume.  Make sure that the sound is not muted.  Make sure that the Tablet PC is not in Sleep mode. ...

  • Page 112: Wireless Lan Problems

    When you turn on the Tablet PC, it stops after POST.  Reset your Tablet PC. (See “Resetting the Tablet PC” later in this chapter.) Wireless LAN Problems I cannot use the wireless LAN feature. Make sure that the wireless LAN feature is turned on. ...

  • Page 113: Other Problems

    I cannot communicate with the computer in the network when Infrastructure mode is configured. Make sure that the Access Point your Tablet PC is associated with is  powered on and all the LEDs are working properly. If the operating radio channel is in poor quality, change the Access Point ...

  • Page 114: Resetting The Tablet Pc

    Resetting the Tablet PC You may have to reset (reboot) your Tablet PC on some occasions when an error occurs and the program you are using hangs up. If the Tablet PC operation seems to hang up, first wait. It is possible that the Tablet PC is processing data.

  • Page 115: Appendix A Specifications

    Appendix A Specifications NOTE: Specifications are subject to change without any prior notice. Parts Specifications Intel® Pine View N450, 512 KB L2 cache, FSB 667 MHz, 1.66 GHz speed, with integrated graphics (Dx9) Chipset Intel® Tiger Point NM10 Express BIOS Phoenix, 1MB Flash EEPROM Up to 2 GB DDR2-667 SO-DIMM DRAM Video...
  • Page 116 Parts Specifications Dimension (LxW× D) 280× 184× 32 mm (11× 7.2× 1.3 inch) Weight 1.4 kg (3.09 lb) Temperature Operating: –20 C (–4 F) to 60 C (140 F) Environ- Storage: –40 C (–40 F) to 75 C (167 F) ment Thermal shock: –20 C (–4 F) to 60 C (140 F) Humidity...

  • Page 117: Appendix B Regulatory Information

    Appendix B Regulatory Information This appendix provides regulatory statements and safety notices on your Tablet PC.

  • Page 118: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 119: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

  • Page 120: About The Ac Adapter

    FINNISH VAROITUS: Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan valmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer.
  • Page 121 paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a carrying case. Connect the adapter to a proper power source. The voltage  requirements are found on the product case and/or packaging. ...

  • Page 122: On The Use Of The Rf Device

    On the Use of the RF Device USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 123 The use of wireless devices on airplanes is governed by the Federal  Aviation Administration (FAA). The use of wireless devices in hospitals is restricted to the limits set forth  by each hospital. Antenna use: In order to comply with FCC RF exposure limits, low gain integrated ...
  • Page 124 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.

  • Page 125: European Union Ce Marking And Compliance Notices

    Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé...
  • Page 126 Greek To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evró pska Efnahags Bandalagsins nú mer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
  • Page 127 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. France Departments in Which the Wireless LAN Module Can Be Used (Indoors Only) The wireless LAN module can currently be used indoors only in the following...
  • Page 128 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges Indoors Outdoors (MHz) 2400 – 2446.5 10 mW Not permitted 2446.5 – 2483.5 100 mW 100 mW on private property with Ministry of Defense approval Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.

Table of Contents
