  • Page 1 E100 USER’S MANUAL Rugged Mobile Computing Solutions...
  • Page 2 Nov. 2009 TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective companies. NOTE The information in this manual is subject to change without notice.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Getting Started ............. 1-1 Getting the Tablet PC Running ..........1-2 Unpacking ................1-2 Connecting to AC Power ............ 1-3 Using the Hand Strap ............1-6 Turning On and Off the Tablet PC ........1-7 Taking a Look at the Tablet PC ..........
  • Page 4 Connecting Audio Devices ..........2-12 Using the Communication Features ........2-13 Using the LAN ..............2-13 Using the Wireless LAN ............ 2-13 ® Bluetooth Using the Wireless Feature ......2-16 Using the GPS (Optional) ..........2-19 Using the 3G Feature (Optional) ........2-20 Chapter 3 Managing Power ............
  • Page 5 Boot Menu ................5-8 Exit Menu ................5-9 System Recovery ..............5-10 Chapter 6 Using Special Utilities ........... 6-1 Using TPM (Trusted Platform Module) ........6-2 Using the OSD Control Panel ..........6-3 Quick Button Setup Utility ..........6-7 Using the G-Manager Utility ..........6-10 Starting G-Manager ............
  • Page 6 Display Problems ..............8-4 Hardware Device Problems ..........8-4 Hard Disk Drive Problems ........... 8-5 LAN Problems ..............8-5 Wireless LAN Problems ............8-5 PC Card Problems (Optional) ..........8-7 Power Management Problems .......... 8-7 Software Problems ............. 8-8 Sound Problems ..............8-8 Startup Problems ..............

  • Page 7: Chapter 1 Getting Started

    Chapter 1 Getting Started Congratulations on purchasing this rugged tablet PC. This chapter first tells you step by step how to get the tablet PC up and running. Then, you will find a section briefly introducing the external components of the tablet PC.

  • Page 8: Getting The Tablet Pc Running

    Getting the Tablet PC Running This section guides you through the procedures for getting the tablet PC ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: Notebook tablet PC  Accessories:   AC adapter ...

  • Page 9: Connecting To Ac Power

    Connecting to AC Power The tablet PC operates either on the external AC power or internal battery power. It is suggested that you use AC power when you start up the tablet PC for the very first time. 1. Make sure that the tablet PC is turned off. 2.
  • Page 10 4. Fit the battery pack into place (). Tightening the two screws () is optional. The lack of the screws will not affect the rugged and waterproof feature of the tablet PC. 5. Replace the battery cover and turn the latch clockwise to the lock position.
  • Page 11 6. Plug the DC cord of the AC adapter to the power connector ( ) of the tablet PC (  ). Plug the female end of the AC power cord to the AC adapter and the male end to an electrical outlet (  ). 7.

  • Page 12: Using The Hand Strap

    Using the Hand Strap Align the four hooks of the hand strap with the four corresponding holes on the tablet PC and tighten the screws. The hand strap allows you to firmly hold the tablet PC by inserting your hand through the hand strap.

  • Page 13: Turning On And Off The Tablet Pc

    Turning On and Off the Tablet PC Turning On 1. Make sure that the tablet PC is connected to AC power or the battery has power. 2. Press the power button ( 3. Each time the tablet PC is turned on, it performs a Power-On Self Test (POST), and the operating system Windows XP Tablet PC edition should start (may support Windows Vista Business and Ultimate in the future).

  • Page 14: Taking A Look At The Tablet Pc

    Taking a Look at the Tablet PC Front Components Component Description See Also  Touchscreen Displays and receives information for the P. 2-7 tablet PC.  Power Button Turns the tablet PC power ON and OFF. P. 1-7 The LED lights green when tablet PC is on. ...
  • Page 15 Component Description See Also  Quick Buttons Toggles the Fn keylock ON and OFF. P. 2-9 Toggles the keypad lock ON and OFF by P. 2-9 pressing for three seconds to prevent accidental pressing of keypad during transport. Menu Toggles the “OSD Control Panel” utility ON P.

  • Page 16: Rear Components

    Component Description See Also  Cursor-control Serves as the UP / DOWN / LEFT / RIGHT P. 2-4 Keys arrow keys (except pointer on screen). When Fn keylock is on, the alternative function of a key is activated. The alternative functions are identified by the color of orange on the keytop.

  • Page 17: Right-Side Components

    Right-Side Components Component Description See Also  Locks the tablet PC to a stationary P. 7-2 Kensington Lock object for security.  Touchscreen Pen Serves as the input device by tapping P. 2-7 on the touch screen to make selections and enter information.

  • Page 18: Top Components

    Top Components Component Description See Also  Smart Card Accepts a smart card for additional security P. 4-3 Reader feature.  PC Card Slot Accepts a PC card for additional functions. P. 4-4 (optional) There is no PCMCIA slot if your model comes with the 3G module.

  • Page 19: Bottom Components

    Bottom Components Component Description See Also  3G Pass-through Connects to the optional antenna for P. 2-20 Connector (option) wireless WAN (wide area network) 3G transmission. NOTE: Must be connected via a docking station.  GPS Pass-through Connects to the optional antenna for P.

  • Page 21: Operating Your Tablet Pc

    Chapter 2 Operating Your Tablet PC This chapter provides information about the use of the tablet PC. If you are new to tablet PCs, reading this chapter will help you learn the operating basics. If you are already a computer user, you may choose to read only the parts containing information unique to your tablet PC.

  • Page 22: Starting And Stopping The Tablet Pc

    Starting and Stopping the Tablet There are a number of ways to start and stop the tablet PC. Starting the Tablet PC You always start the tablet PC using the power button. A tablet PC starts up with an operating system (OS) existing on the storage device such as the hard disk.
  • Page 23 To stop in Do this... To start up or this mode... resume again Hibernation Depending on your settings in Windows, Press the power you can place the tablet PC in button. Hibernation mode by pressing the power button. If you choose to stop in Standby or Hibernation mode, you can return to where you left off the next time you start up the tablet PC.

  • Page 24: Using The Keypad

    Using the Keypad Your keypad can be divided into two major categories: Numeric, Delete (Del), and Enter (Ent) keys  Cursor-control keys  Numeric Keypad with Secondary Functions The 12-key numeric keypad with Delete and Enter keys is shown next: When the Fn keylock is ON ( icon appears on the system tray), you can use the following secondary functions with orange color on top of each...

  • Page 25: Cursor-Control Keys With Secondary Functions

    switches the sunlight-readable mode ON and OFF.  serves as the mouse right-click button.  C+A+D serves as the Ctrl+Alt+Del key combination.  ESC serves as the Escape key.  Cursor-Control Keys with Secondary Functions The word “cursor” refers to the indicator on the screen (except for pointer on screen) that lets you know exactly where on your screen anything you type will appear.

  • Page 26: Using The On-Screen Keyboard

    Using the On-screen Keyboard Use the on-screen keyboard to enter text and perform various keyboard functions. 1. Click the on-screen keyboard icon ( ) located on the Windows system tray and the software keyboard will appear onscreen. 2. Tap the characters on the on-screen keyboard with the touchscreen pen.

  • Page 27: Using The Touchscreen Pen

    Using the Touchscreen Pen The touchscreen is a touch-sensitive device that allows you to easily use the tablet PC without a mouse or touchpad to communicate with the tablet PC by controlling the location of the pointer on the screen and making selection with the buttons.
  • Page 28 Here are some common terms that you should know when using the touchscreen: Term Action Click/Point Tap gently on the touchscreen. Double-click Tap twice on the touchscreen rapidly. Drag and drop Press lightly on the touchscreen and move your finger until you reach your destination (drag).

  • Page 29: Using The Quick Buttons

    Using the Quick Buttons Located on top of the keypad are three quick buttons: Fn button toggles the Fn keylock ON and OFF ( icon appears on the  system tray when ON). You can use the secondary functions of keypad buttons with orange color on top of each button (as described in the “Using the Keypad”...

  • Page 30: Using The Video Features

    Using the Video Features The video subsystem of your tablet PC features: 8.4-inch wide TFT (Thin-Film Transistor) color LCD with SVGA  transmissive display Toggle display between landscape view and portrait view using the LCD  rotate button  Built-in light sensor to automatically adjust the LCD brightness ...

  • Page 31: Using The Audio Features

    Using the Audio Features The audio subsystem of your tablet PC features: High density audio codec  Manually adjust the sound volume using the sound volume up (  and down ( ) buttons Audio-out connector ( ) ()  Integrated speaker () ...

  • Page 32: Connecting Audio Devices

    Connecting Audio Devices For higher audio quality, you can send sound through external audio devices such as speakers, headphones, or earphone set using the audio-out connector.  ...

  • Page 33: Using The Communication Features

    Using the Communication Features Using the LAN The internal 10/100/1000Base-T LAN (Local Area Network) module allows you to connect your tablet PC to a network. It supports data transfer rate up to 1000 Mbps. To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector ( ) on the tablet PC and the other end to the network hub.
  • Page 34 Turning Off/On the WLAN Radio 1. Press the Menu button on your tablet PC to start up the OSD Control Panel utility. 2. Click the RF button to switch the WLAN radio on/off, indicated by the WLAN indicator ( ) glowing in green when on. If you need to temporarily turn off the radio, click the RF button.

  • Page 35: Connecting To A Wireless Network

    Connecting to a Wireless Network To connect to a wireless network: 1. Make sure that the wireless LAN radio is “on” indicated by the wireless LAN indicator ( ) glowing in green. 2. Double-click the Wireless Network Connection icon located on your Windows system tray.

  • Page 36: Using The Bluetooth Wireless Feature

    ® Bluetooth Using the Wireless Feature Depending on your model, your tablet PC may incorporate the Bluetooth capability for short-range (about 10 meters) wireless communications between devices without requiring a cable connection. With Bluetooth, data can be transmitted through walls, pockets and briefcases as long as two devices are within range.
  • Page 37 3. The Add New Connection Wizard window appears. Select Express Mode (Recommended), and then click Next. 4. Select the device to connect to and click Next.
  • Page 38 Bluetooth 5. Depending on the type of device that you want to connect to, you will need to enter the pertinent information. Sending a File Bluetooth 1. Make sure that the target device is turned on, discoverable and within close range. (See the documentation that came with the Bluetooth device.) 2.

  • Page 39: Using The Gps (Optional)

    Using the GPS (Optional) Depending on the model you purchased, your tablet PC may have the GPS receiver module built in. GPS (Global Positioning System) is a constellation of 24 well-spaced satellites that orbit the Earth and make it possible for devices enabled with GPS receivers to pinpoint their location.

  • Page 40: Using The 3G Feature (Optional)

    Using the 3G Feature (Optional) 3G is the third generation of mobile phone standards and technology, after 2G. It is based on the International Telecommunication Union (ITU) family of standards under the International Mobile Telecommunications programme, “IMT-2000”. Services include wide-area wireless voice telephony and broadband wireless data, all in a mobile environment.
  • Page 41  4. Remove the two screws if existing ( ). Pull on the ribbon strip to lift the  battery pack off the computer ( 5. Locate the SIM card slot and push the SIM card into the slot. Make sure the beveled corner on the SIM card is facing towards the tablet PC and that the golden contact area on the card is facing downwards.
  • Page 42 To remove the SIM card, just push in () the SIM card to pop-out () and remove the card. 6. Fit the battery pack into place and secure with two screws. 7. Replace the battery cover and turn the latch clockwise to the lock position.

  • Page 43: Chapter 3 Managing Power

    Chapter 3 Managing Power Your tablet PC operates either on external AC power or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.

  • Page 44: Ac Adapter

    AC Adapter     The AC adapter serves as a converter from AC (Alternating Current) to DC (Direct Current) power because your tablet PC runs on DC power, but an electrical outlet usually provides AC power. It also charges the battery pack when connected to AC power.

  • Page 45: Battery Pack

    Battery Pack The battery pack is the internal power source for the tablet PC. It is rechargeable using the AC adapter. The operating time of a fully charged battery pack depends on how you are using the tablet PC. When your applications often access peripherals, you will experience a shorter operating time.

  • Page 46: Initializing The Battery Pack

    Initializing the Battery Pack You need to initialize a new battery pack before using it for the first time or when the actual operating time of a battery pack is much less than expected. Initializing is the process of fully charging, discharging, and then charging. It can take several hours.

  • Page 47: Replacing The Battery Pack

    By Gas Gauge On the exterior side of the battery pack is a gas gauge for displaying the estimated battery charge. When the battery pack is not installed in the tablet PC and you want to know the battery charge, you can press the switch with a pointed device to see the corresponding value of indicator segment that light green.
  • Page 48 3. Lift the latch handle of the battery cover and turn it counterclockwise to the unlock position. Then, detach the cover from the tablet PC. Unlock position  4. Remove the two screws if existing ( ). Pull on the ribbon strip to lift the ...

  • Page 49: Battery Low Signals And Actions

    6. Replace the battery cover and turn the latch clockwise to the lock position. Battery Low Signals and Actions Battery Low occurs when the battery has approximately 10% (Windows default setting) of its charge remaining. The tablet PC’s Battery Charge Indicator ( ) blinks red to alert you to take actions.

  • Page 50: Power Management

    Power Management Your tablet PC supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows, power supply to different tablet PC components is controlled on an as-needed basis.

  • Page 51: Hibernation

    Hibernation Hibernate Power Options Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the computer can be turned off. When you use the hibernation feature, you do not have to close the applications.

  • Page 52: Power-Saving Tips

    Power-Saving Tips Aside from enabling your tablet PC’s power saving mode (see previous section), you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management.  Decrease the LCD brightness to the lowest comfortable level. ...

  • Page 53: Expanding Your Tablet Pc

    Chapter 4 Expanding Your Tablet PC You can expand the capabilities of your tablet PC by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter.

  • Page 54: Connecting A Usb Device

    Connecting a USB Device Your tablet PC has two USB ports for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB ports support transfer rates up to 12 MB/s for USB 1.1 devices and 480 MB/s for USB 2.0 devices.

  • Page 55: Using Smart Cards

    Using Smart Cards Your tablet PC has a smart card slot for additional security feature, providing tamper-proof storage of user and account identity. A smart card is a type of plastic card embedded with a computer chip that stores and transacts data between you (user) and the tablet PC.

  • Page 56: Using Pc Cards (Optional)

    Using PC Cards (Optional) Depending on your model, your tablet PC has one PC card slot which supports type II card and CardBus specifications. Inserting and Removing a PC Card   To insert a PC card: 1. Locate the PC card slot on the top of the tablet PC. 2.
  • Page 57 To remove a PC card: 1. Double-click on the Safely Remove Hardware icon found on the Windows taskbar and the Safely Remove Hardware window appears on screen. 2. Select (highlight) the PC card from the list to disable the card. 3.

  • Page 58: Using The Docking Station

    Using the Docking Station A docking station is available as an option. This device eliminates the hassles of having you connect and disconnect the various cables when carrying your tablet PC around and allows a variety of peripherals to be connected including a headphone or microphone, etc.

  • Page 59: Using Bios Setup And System Recovery

    Chapter 5 Using BIOS Setup and System Recovery BIOS Setup Utility is a program for configuring the BIOS (Basic Input/ Output System) settings of the tablet PC. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the tablet PC hardware can understand.

  • Page 60: Bios Setup

    BIOS Setup When to Use BIOS Setup When to Use You need to run BIOS Setup Utility when: You see an error message on the screen requesting you to run BIOS  Setup Utility. You want to restore the factory default BIOS settings. ...

  • Page 61: Moving Around And Making Selections

    The BIOS Setup Utility screen can be divided into four areas: On the top is the menu bar containing the titles of the available menus.  Each menu title brings a specific menu. The left column of the menu displays the menu items. ...

  • Page 62: Information Menu

    Function  ,  Selects a menu title.  ,  Selects an item or option. + / – Changes the value. 1) Brings up the sub-menu when available. 2) Opens or closes the option window when an item is selected.

  • Page 63: Main Menu

    Main Menu The Main menu contains the system time and date, as well as the USB setting of the system. System Time sets the system time. System Date sets the system date. Power Button Delay allows you to prevent accidental pressing of the power button.

  • Page 64: Advanced Menu

    Advanced Menu The Advanced menu contains the advanced settings as shown next. Total Graphics Memory allows you to select the amount of total graphics memory (pre-allocated + fixed + DVMT) for use by the internal graphics device. DVMT Graphics Memory shows the size of DVMT graphics memory. HDD Preheat allows your system to automatically turn on the optional heater when temperature of the hard disk drive is lower than 5 High Temperature Protection allows you to turn off hard disk drive power...

  • Page 65: Security Menu

    Security Menu The Security menu contains the TPM (Trusted Platform Module) setting. The TPM is a component on your tablet PC’s mainboard that is specifically designed to enhance platform security above-and-beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.

  • Page 66: Boot Menu

    Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a device from which to load the OS.

  • Page 67: Exit Menu

    Exit Menu The Exit menu displays ways of exiting BIOS Setup Utility. After finishing with your settings, you must save and exit so that the changes can take effect. Exit Saving Changes saves the changes you have made and exits BIOS Setup Utility.

  • Page 68: System Recovery

    System Recovery You need to run System Recovery when: Your Windows operating system does not start at all.  You want to restore the factory default Windows settings.  To run System Recovery: 1. During system startup when the following screen appears, press Ctrl + Alt + F2 keys for four seconds or press Ent and select HDI Recovery when a small window appears on the screen.
  • Page 69 1. The recovery software is solely the purpose of reinstalling or restoring software associated with the hard disk of this operating GETAC machine. 2. Except the above, no other use is granted hereunder. **************************************** (1)Yes, I agree to the provisions of this agreement and wish to continue.

  • Page 71: Using Special Utilities

    Chapter 6 Using Special Utilities Your tablet PC comes with an added security feature known as the TPM (Trusted Platform Module) – a component on your tablet PC’s mainboard that is specifically designed to enhance platform security above-and- beyond the capabilities of today’s software by providing a protected space for key operations and other security critical tasks.

  • Page 72: Using Tpm (Trusted Platform Module)

    Using TPM (Trusted Platform Module) TPM is a hardware-based security feature that can be used to create and manage computer-generated digital certificates. When combined with security software, the TPM enhances existing network and computer security by enabling features such as file protection capabilities and protected e-mail.

  • Page 73: Using The Osd Control Panel

    Using the OSD Control Panel The OSD Control Panel allows you to activate or operate certain functions on your tablet PC. To open the OSD Control Panel, press the Menu button on your tablet PC. The following screen appears.
  • Page 74 The following table shows the various functions on the OSD Control Panel. Operation OSD Control Panel Description Switches the keypad lock ON and OFF. Press the button one second to turn ON (lock) and continuously for more than three seconds to turn OFF (unlock). This would prevent accidental pressing of the keypad buttons during transport.
  • Page 75 Operation OSD Control Panel Description Toggles between NORMAL, MAX, and AUTO brightness for LCD backlight. Rotates the LCD display orientation from default landscape to 90 portrait, 180 landscape, 270 portrait, and vice versa. Toggles between LCD, VGA (external device e.g., monitor), and BOTH (LCD and external device).
  • Page 76 Operation OSD Control Panel Description Serves as the default virtual keyboard quick launch button. You can use the Quick Button Setup utility to assign a different function to this button (refer to the next section for details). Increases or decreases the sound volume. This function adjusts the volume of sound output both from the speakers and headphones.

  • Page 77: Quick Button Setup Utility

    Quick Button Setup Utility By default, the five quick launch buttons on the OSD Control Panel have pre-assigned functions. The Quick Button Setup utility allows you to re-define the above five quick launch buttons. To re-define: 1. Click the Quick Button Setup utility button ( ) and the Quick Button Setup window appears as shown next.
  • Page 78 3. The Select a File to Open dialog box appears as shown next. Select the desired program, then click Open to complete the process. 4. You can change the image appearing on the button by clicking the Select Image icon.
  • Page 79 5. The Select Picture dialog box appears as shown next. After selecting the image file, the appropriate icon will then appear in the button. 6. Click Set to complete the changes.

  • Page 80: Using The G-Manager Utility

    GPS Status  Starting G-Manager You can start up G-Manager by any of the following methods: Click Start  All Programs  GETAC Utility  G-Manager, or  Right-click on the GETAC Utility icon ( ) located on the system tray ...

  • Page 81: System Tab

    System Tab The System tab provides an overview of the system status. The component to be viewed is selected from the tree view list on the left side of the screen. It contains eight major components namely: Summary  System ...

  • Page 82: Battery Tab

    The status of the selected component is displayed on the right side of the screen. Battery Tab The Battery tab allows you to minimize deterioration of the battery thereby ensuring a longer battery life. At most two batteries may be supported. Press Battery 1 or Battery 2 to view the details and configuration settings of each battery.
  • Page 83 Battery Status  Charging Mode The lower left portion of the Battery tab allows you to select the charging mode.  Normal Mode – the battery will be fully charged. When remaining charge reaches below 95%, then charging will start until it is fully charged.
  • Page 84 2. Click Yes to start the gauge reset session and the following screen appears. The percentage of completion will be shown on the progress bar. Depending on the number of battery, the screen will show the corresponding number of batteries to perform gauge reset. The value of Working Status will show alternately.

  • Page 85: Light Sensor Tab

    Light Sensor Tab The Light Sensor tab allows you to adjust the LCD brightness based on your surrounding’s lighting condition. Sensor Mode The left portion of the Light Sensor tab allows you to select the sensor mode. Normal – light sensor sensitivity is set at normal environment lighting ...

  • Page 86: Eco Tab

    The upper right portion of the Light Sensor tab shows the active profile based on your selection on sensor mode. The middle right portion of the Light Sensor tab shows the environment luminance (degree of Lux from weak to bright) as detected by your tablet PC’s light sensor.

  • Page 87: Eco Information

    ECO Information Depending on the system, the left portion of the ECO tab shows the available profile to manage the system’s power consumption. Active Profile The right upper portion of the ECO tab shows the name of the current profile selected. Profile Settings The lower right portion of the ECO tab contains the following: Turn on/off the following for power saving: WWAN, Bluetooth, WLAN,...

  • Page 88: Ignition Tab

    The amount of time between turning off your vehicle and tablet PC shutdown would depend on your setting on the next section Delay Time. This feature is only available when your tablet PC is docked to the GETAC docking station.

  • Page 89: Monitoring Tab

    Delay Time The right portion of the Ignition tab allows you to set the delay time (20 seconds, 30 seconds, 45 seconds, 1 minute, or 2 minute) to shut down the system when you turn off vehicle ignition. This will help prevent the tablet PC from using up the vehicle’s battery power thereby causing poor vehicle startup.

  • Page 90: Monitoring Options

    Items to Monitor The left portion of the Monitoring tab allows you to select which item to monitor by selecting on the checkbox before each item. When enabled the status of the selected Item is displayed and a live update is shown on the screen.

  • Page 91: Antenna Tab

    Transparency – allows you to set the level of transparency of the  monitoring window (10 ~ 90 %). Antenna Tab The Antenna tab allows your system to connect to an external GPS or 3G antenna. Select the checkbox I have external GPS antenna or 3G antenna to allow your system to connect to an external GPS/3G antenna.

  • Page 92: Gps Status Tab

    GPS Status Tab The GPS Status tab shows the GPS signal availability status of the system’s GPS module, allowing you to check if the GPS feature is working properly. You may also need to install a third-party map of your particular location (purchased separately).
  • Page 93 Message Log The lower left portion of the GPS Status tab shows a summary of raw data string received from satellites which can only be viewed but not editable. The Message Log window is auto-scrollable and will be cleared as soon as GPS signal is disconnected.
  • Page 94 to free up the COM port. After closing the other GPS program, click Open GPS button again to try. GPS COM port is somehow not functioning –  A warning window pops-up and displays the message “Time out opening GPS COM port!” when GPS COM port is not responding after 5 seconds.

  • Page 95: Caring For The Tablet Pc

    Chapter 7 Caring for the Tablet Taking good care of your tablet PC will ensure a trouble-free operation and reduce the risk of damage to your tablet PC. This chapter gives you guidelines covering areas such as protecting, storing, cleaning, and traveling.

  • Page 96: Protecting The Tablet Pc

    Protecting the Tablet PC To safeguard the integrity of your tablet PC data as well as the tablet PC itself, you can protect the tablet PC in several ways as described in this section. Using the Cable Lock You can use a Kensington-type cable lock to protect your tablet PC against theft.

  • Page 97: Taking Care Of The Tablet Pc

    Taking Care of the Tablet PC Location Guidelines  For optimal performance, use the tablet PC where the recommended temperature is between 10 C (50 F) and 35 C (95 F) – actual operating temperature depending on product specifications. Avoid placing the tablet PC in a location subject to high humidity, ...

  • Page 98: Cleaning Guidelines

    a screen saver or other software that prevents the power management from working. Cleaning Guidelines  Never clean the tablet PC with its power on.  Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the tablet PC. Gently wipe the display with a soft, lint-free cloth.

  • Page 99: Touchscreen Guidelines

    It is recommended that you do not charge the battery pack more than  once a day. It is recommended that you charge the battery pack with the tablet PC’s  power off.  To maintain the battery pack’s operating efficiency, store it in a cool dark place removed from the tablet PC and with 30 % ~ 40 % charge remaining.
  • Page 100 Use a soft cloth to remove dirt on the display. The touchscreen surface  has a special protective coating that prevents dirt from sticking to it. Not using a soft cloth may cause damage to the special protective coating on the touchscreen surface.

  • Page 101: When Traveling

    When Traveling Before traveling with your tablet PC, make a backup of your hard disk  data into flash disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure that the battery pack is fully charged. ...

  • Page 103: Chapter 8 Troubleshooting

    Chapter 8 Troubleshooting Tablet PC problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common tablet PC problems.

  • Page 104: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the tablet PC is causing the problem.  Make sure that you turn on all peripheral devices before turning on the ...

  • Page 105: Solving Common Problems

    Solving Common Problems Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected.  Make sure that the battery is not too hot or cold. Allow time for the ...

  • Page 106: Display Problems

    Make sure that the other device is not in “Hidden” mode.  Make sure that both devices are compatible.  Display Problems Nothing appears on the screen. During operation, the screen may automatically turn off as a result of  power management.

  • Page 107: Hard Disk Drive Problems

    Hard Disk Drive Problems The hard disk drive error message appears on the screen. The hard disk drive has defects. Ask your dealer for help.  The hard disk drive operations seem slow.  The data files stored on the hard disk drive may be fragmented. Use a tool such as Window’s Disk Defragmenter to defragment the files.
  • Page 108 Transmission quality is poor.  Your tablet PC may be in an out-of-range situation. Move your tablet PC closer to the Access Point or another wireless LAN device it is associated with. Check if there is high interference around the environment and solve the ...

  • Page 109: Pc Card Problems (Optional)

    Use the Web Manager/Telnet of the Access Point to check whether it is  connected to the network. Reconfigure and reset the Access Point.  I cannot access the network. Make sure that the network configuration is appropriate.  Make sure that the user name or password is correct. ...

  • Page 110: Software Problems

    The tablet PC does not resume from Standby or Hibernation mode.  The tablet PC automatically enters Standby or Hibernation mode when the battery pack is empty. Do any one of the following:  Connect the AC adapter to the tablet PC. ...

  • Page 111: Startup Problems

    Check the volume control of your tablet PC.  Startup Problems When you turn on the tablet PC, it does not respond and the Power Indicator does not light green. If you are using an external AC power, make sure that the AC adapter is ...

  • Page 112: Resetting The Tablet Pc

    Resetting the Tablet PC You may have to reset (reboot) your tablet PC on some occasions when an error occurs and the program you are using hangs up. If the tablet PC operation seems to hang up, first wait. It is possible that the tablet PC is processing data.

  • Page 113: Appendix A Specifications

    Appendix A Specifications Parts Specifications Intel® A110 processor, 512 KB L2 cache, 800 MHz RAM (system) Up to 1 GB DDRII DRAM Display Panel 8.4-inch wide TFT LCD, SVGA transmissive display, integrated touchscreen, 800 Nits LCD brightness (option) Audio Features High Definition audio, volume control via keypad and software Speaker Integrated speaker...
  • Page 114 Parts Specifications Operating: –20 C (–4 F) to 60 C (140 F) Environment Temperature Storage: –40 C (–40 F) to 75 C (167 F) Thermal shock: –20 C (–4 F) to 60 C (140 F) Humidity Relative: 0 % to 95 % non-condensing Compliance MIL-STD 810F and IP54...

  • Page 115: Appendix B Regulatory Information

    Appendix B Regulatory Information This appendix provides regulatory statements and safety notices on your tablet PC.

  • Page 116: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 117: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

  • Page 118: About The Ac Adapter

    FINNISH VAROITUS: Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan valmistajan suosittelemaan tyyppiin. Hävitä käytetty paristo valmistajan ohjeiden mukaisesti. ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer.
  • Page 119 paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a carrying case. Connect the adapter to a proper power source. The voltage  requirements are found on the product case and/or packaging. ...

  • Page 120: On The Use Of The Rf Device

    On the Use of the RF Device USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 121 The use of wireless devices on airplanes is governed by the Federal  Aviation Administration (FAA). The use of wireless devices in hospitals is restricted to the limits set forth  by each hospital. Antenna use: In order to comply with FCC RF exposure limits, low gain integrated ...
  • Page 122 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.

  • Page 123: European Union Ce Marking And Compliance Notices

    shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournir un écran de blindage maximal.
  • Page 124 Icelandic Þessi vara stenst reglugerð Evró pska Efnahags Bandalagsins nú mer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC. Portuguese Este produto cumpre com as normas da Diretiva Européia 1999/5/EC. Spanish Este producto cumple con las normas del Directivo Europeo 1999/5/EC.
  • Page 125 Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “Turning Off the Wireless LAN Radio.” France Departments in Which the Wireless LAN Module Can Be Used (Indoors Only) The wireless LAN module can currently be used indoors only in the following 38 departments of mainland France.
  • Page 126 Frequency Ranges Indoors Outdoors (MHz) 2400 – 2446.5 10 mW Not permitted 2446.5 – 2483.5 100 mW 100 mW on private property with Ministry of Defense approval Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.

Table of Contents
