Page 1: Moxa Etherdevice Switch
MOXA EtherDevice Switch & PoE Splitter EDS-P308 & SPL-24 Hardware Installation Guide First Edition, July 2006 Moxa Networking Co., Ltd. Tel: +886-2-2910-1230 Fax: +886-2-2910-1231 www.moxa.com support@moxanet.com (Worldwide) support@moxa.com (The Americas) P/N: 1802003080000... - Page 2 PoE (Power-over-Ethernet) on ports 1 to 4, which means that the EDS-P308 can double as a piece of power source equipment (PSE). When used in this way, the EDS-P308 can supply up to 15.4 watts of power per port, and can power IEEE 802.3af compliant powered devices (PD), eliminating the need for additional wiring.
-
Page 3: Wiring Requirements
environment for installing devices. PoE technology lets you eliminate the need for using power outlets to deploy Ethernet-enabled devices—such as a wireless access point (AP) or an IP camera—on a ceiling or outdoors. The devices can be placed up to 328 feet (100 m) from a PSE. Wiring Requirements WARNING Do not disconnect modules or wires unless the power supply has... - Page 4 Package Checklist for EDS-P308 The MOXA EDS-P308 is shipped with the following items. If any of these items is missing or damaged, please contact your customer service representative for assistance. MOXA EtherDevice™ Switch EDS-P308 Hardware Installation Guide MOXA Product Warranty Statement...
- Page 5 Power Input Voltage 48 VDC, redundant inputs Input Current 1.6 A (@ 48 VDC) Connection Removable “6-pin” Terminal Block Overload Current 2.5 A (@ 48 VDC) Protection Reverse Polarity Present Protection PoE (per port) Minimum output voltage 44 VDC Maximum output current 350 mA (@ 48V, normal powering mode) Inrush current 400 to 450 mA (startup mode) Overload detection...
- Page 6 EDS-P308 Panel Layout Top Panel View Grounding screw Terminal block for power inputs PWR1, PWR2, and relay output Heat dissipation orifices DIP switches Power input PWR1 LED Power input PWR2 LED Fault LED 10/100BaseT(X) Port TP port’s 100 Mbps LED TP port’s 10 Mbps LED...
-
Page 7: Mounting Dimensions (Unit = Mm)
The aluminum DIN-Rail attachment plate should already be fixed to the back panel of the EDS-P308 when you take it out of the box. If you need to reattach the DIN-Rail attachment plate, make sure the stiff metal spring is situated towards the top, as shown in the figures below. -
Page 8: Wall Mounting (Optional)
Wall Mounting (optional) For some applications, you will find it convenient to mount EDS-P308 on the wall, as illustrated below. STEP 1: Remove the aluminum DIN-Rail attachment plate plate from the EDS-P308’s rear ⇒ panel, and then attach the wall mount plates, as shown in the diagram below. -
Page 9: Wiring The Redundant Power Inputs
DC power source voltage is stable. EDS-P308’s Alarm Contact The EDS-P308 has one alarm contact located on its top panel. For detailed instructions on how to connect the alarm contact power wires to the two middle contacts of the 6-contact terminal block connector, see the Wiring the Alarm Contact section on page 9. -
Page 10: Wiring The Alarm Contact
EDS-P308’s DIP Switch Settings ON: Enables the corresponding PORT Alarm. If the port’s link fails, the relay will form an open circuit and the fault LED will light up. Off: Disables the corresponding PORT Alarm. The relay will form a closed circuit and the Fault LED will never light up. -
Page 11: Led Indicators
LED Indicators The front panel of the EDS-P308 contains several LED indicators. The function of each LED is described in the table below. Color State Description Power is being supplied to power input PWR1 PWR1 AMBER Power is not being supplied to power... - Page 12 Package Checklist for SPL-24 The MOXA SPL-24 is shipped with the following items. If any of these items is missing or damaged, please contact your customer service representative for assistance. MOXA PoE Splitter, SPL-24 Hardware Installation Guide MOXA Product Warranty Statement Features of SPL-24 High Performance Network Switching Technology IEEE802.3af compliance...
- Page 13 Ambient Relative 5 to 95% (non-condensing) Humidity Regulatory Approvals Safety Pending: UL60950, UL 508, CSA C22.2 No. 60950, EN60950 Hazardous Location Pending: UL/cUL Class I, Division 2, Groups A, B, C, and D Pending: ATEX Class I, Zone 2, EEx nC IIC FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), Level 3 EN61000-4-3 (RS), Level 3...
- Page 14 Mounting Dimensions (unit = mm) 10.5 24.87 DATA OUT OUTPUT : 24 VDC PoE IN 86.5 24.87 Side View Front View Rear View Top View DIN-Rail Mounting for SPL-24 The plastic DIN-Rail attachment plate should already be fixed to the back panel of SPL-24 when you take it out of the box.
- Page 15 Grounding the SPL-24 Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the right most contact of the 3-contact terminal block to the grounding surface prior to connecting devices. ATTENTION This product is intended to be mounted to a well-grounded mounting surface, such as a metal panel.
-
Page 16: Moxa Internet Services
