5.GENERAL INFORMATIONS

1、CHANGING FLOW DIRECTION
Air flow deflectors divert air from center flow to left or right.
Adjust deflectors divert for desired dir flow pattern
2、AIR FLOW AROUND UNIT
Check indoor grill and outdoor louvers for air flow obstructions . Do not block air flow to and from unit . The outdoor
coil should be checked and periodically cleaned for debris that may collect and block unit air flow .If air flow is
obstructed or deflected back into unit ,the compressor may cycle on and off rapidly ,causing early.
3、Electrical Grounding Instructions.
This appliance is equipped with a three-prong plug for protection against possible shock hazards .If a tow-prong wall
receptacle is encountered ,the customer is required to contact a qualified electrician and have the two-plug wall
receptacle replaced with a properly grounded three –plug wall receptacle with the National Electrical Code.
4、USE OF EXTENSION CORDS
Because of potential safety hazards under conditions we strongly recommend against the use of an extension
cord .However ,if you still elect to use an extension cord ,it is absolutely necessary that it is earthed and the marked
rating of the extension cord should be 250V 10A or more for DWA-1220R DWA-1220C,Also ,it is absolutely
necessary that it be a UL listed 3-wire grounding type appliance extension cord rated has a 3-blade grounding and
3-slot receptacle that will plug into appliance. The marked rating of the extension cord should be 125V 13A or
more ,for Model DWC-0520RLE DWC-1220R.
5、 USAGE OF POWER CORD(AFCI OR LCDI)
Testing:
CASE 1 : Lamp exists
1. Plug into power receptacle.
2. If light is not on, press "RESET" button, light should turn on
3. Press "TEST" button, light must turn off.
4. Press "RESET" button again for use. Light should turn on.Do not use of above test fails.
CASE 2 : Lamp not exist
1. Plug into power receptacle. Turn on Unit.
2. 2a. If unit operates normally, press "TEST" button. Unit should trip. Press "RESET" button again for use
3. .2b. If unit not operate, press "RESET" button for use. Unit should operate. Do not use if above test fails.
WARNING :
Do not remove, modify or immerse this plug. If this device trips, the cause is to be corrected before further use, see
owners manual.
This device must only be plugged on appropriate wall outlet.
Do not use on extension cords.
- 9 -
