Model:
ECO-WINS18
WOOD BURNING INSERT
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfi re and generate
poisonous gases (i.e. carbon monoxide).
www.heatilatorecochoice.com
Consumer Care 1-877-427-3316 - Prior to calling, please have the model and serial number of the unit you are calling
about. This information can be found at the front of the unit.
DO NOT DISCARD THIS MANUAL
• Read, understand and
Important operating
follow these instructions
a n d m a i n t e n a n c e
for safe installation and
instructions included.
operation.
WARNING
CAUTION
• Leave this manual with
party responsible for
use and operation.
Hot glass will cause burns.
Do not touch glass until it is cooled
NEVER allow children to touch glass
Keep children away
CAREFULLY SUPERVISE children in same room as
fi replace.
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
Keep clothing, furniture, draperies and other
fl ammable materials away.
Installation and service of this appliance should
be performed by qualifi ed personnel. Hearth &
Home Technologies recommends NFI certifi ed
professionals, or technicians supervised by an NFI
certifi ed professional.
7065-132F • May 4, 2015
Owner's Manual
Installation and Operation
WARNING
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EcoChoice ECO-WINS18 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heatilator EcoChoice ECO-WINS18

  • Page 1 Owner’s Manual Installation and Operation Model: ECO-WINS18 WOOD BURNING INSERT CAUTION DO NOT DISCARD THIS MANUAL • • Read, understand and • Leave this manual with Important operating follow these instructions party responsible for a n d m a i n t e n a n c e for safe installation and use and operation.
  • Page 2: Congratulations

    2015 2016 2017 JAN FEB MAR APR MAY JUN JUL AUG SEP OCT NOV DEC pièces d’origine américaine et Mfg Date pièces importées. 1445 N. Highway, Colville, WA 99114 DO NOT REMOVE THIS LABEL / NE PAS ENLEVER L'ÉTIQUETTE 7065-134E www.heatilatorecochoice.com Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 3: Table Of Contents

    Snap Disc Replacement........21 Service Maintenance Log..........47 Wiring Diagram ..........21 Contact Information ...........48 Blower Replacement .........22 Baffl e & Ceramic Blanket Removal ....23 Door Handle Assembly ........23 Tube Channel Assembly Replacement .....24 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 4: Warranty Policy

    HEATILATOR ECO-CHOICE WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (“HHT”), extends the following warranty for ECO- CHOICE by heatilator wood and pellet hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrantes to the original owner of the HHT appliance at the site of installation, and to any transferree taking own- ership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture.
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EX- PRESSED WARRANTY SPECIFIED ABOVE. Page 2 of 2 7014-212B 1-10-11 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 6: Section 1: Listing And Code Approvals A

    NOTE: Hearth & Home Technologies, manufacturer of glass only with 5mm ceramic glass. Please contact your this appliance, reserves the right to alter its products, dealer for replacement glass. their specifi cations and/or price without notice. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 7: Section 2: Operating Instructions H

    Failure to operate appliance according to operating instructions could cause fi re or injury. SURROUND & TRIM SET BURN RATE CONTROL DOOR HANDLE SERIAL LABEL POWER CORD BLOWER CONTROL PANEL Figure 7.1 General Operating Parts Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 8: Fire Safety

    Evidence of over-fi ring NFPA Level III inspection criteria includes, but is not limited to: • Warped air tube • Deteriorated refractory brick retainers • Deteriorated baffl e and other interior components Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 9: Burning Process

    The heat generated from the fi re should be warming your home and establishing the fl ue draft, not evaporating the mois- ture out of wet, unseasoned wood, resulting in wasted heat. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 10: Burn Rate Air Control

    *NOTE: These are approximate settings, and will vary with type of wood or chimney draft. Due to altitude and other environmental circumstances, this operational information is a guideline only. Figure 10.1 - Burn Rate Air Control Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 11: Correct Baffl E & Blanket Placement

    fi rebox and NOT even with the Baffl e Board in the front. Figure 11.1 - Correct Baffl e and Blanket Positions Figure 11.2 - Incorrect Baffl e and Blanket Positions Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 12: Building A Fire

    8. If you have installed the optional blower, please note that the blower tends to cool the appliance. Leave the blower off until the burn is well established, i.e., 30 minutes. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 13: Wood Fuel & Storage

    Processed Solid Fuel Fire Logs • NOT permitted for use in this appliance WARNING Fire Risk Do NOT store wood: • In front of the appliance. • In space required for loading or ash removal. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 14: Blower Control Box Snap Disc Operations

    “OFF” as far as possible without turning the blower off. For a low blower speed, turn the control knob clockwise as far as possible Figure 14.1 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 15: Clear Space

    The blower may produce a whirring sound which increases in volume as the speed is increased. CAUTION Odors and vapors released during initial operation. • Curing of high temperature paint. • Open windows for air circulation. Odors may be irritating to sensitive individuals. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 16: Quick Start Guide

    The air control should LIGHT THE PAPER supply adequate draft. ADD MORE WOOD REDUCE AIR CONTROL Set to desired heat output The stove is ready for normal operation. HIGH Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 17: Section 3: Maintenance And Service J

    WARNING! Risk of Fire! Do not use chimney cleaners or fl ame colorants in your appliance. It will corrode your pipe. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 18: Glass Cleaning

    • Avoid striking, scratching or slamming glass • Avoid abrasive cleaners • Do not clean glass while it is hot Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 19: Quick Reference Maintenance Guide

    Spring Handle Loads of Wood Door Handle Check door handle for smooth cam operation. Spacing Washers Square Key Note: These are generic drawings and may not represent your specifi c model. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 20: Section 4: Troubleshooting Guide

    Extremely dry or soft wood (refer to Wood Fuel Section). Check for correct vent height; too much vertical height creates overdrafting. Overdrafting Check location of vent termination (refer to Chimney Termination Requirement Section). Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 21: Section 5: Service Parts Replacement

    1. Remove surround from unit. 2. Using a phillips head screwdriver, remove 8-32 screw, Switch Rheostat washer and bushing assemblies holding left side panel in place. Remove panel. Figure 21.1 Figure 21.2 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 22: Blower Replacement

    Do NOT allow hot coals or embers to overfl ow ash lip • May melt protective wire coating on fan power cord causing electrical short, fi re or injury Figure 22.1 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 23: Baffl E & Ceramic Blanket Removal

    Protection Channel Door Cross Section (example) Latch Cam Locknut Spring Handle Door Handle 2 pc Baffle Board Manifold Tubes Spacing Washers Square Key Figure 23.1 Figure 23.3 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 24: Tube Channel Assembly Replacement

    4. Slide the tube channel assembly all the way to left until it 7. Re-install in reverse order. TUBE CHANNEL NUTS CERAMIC BLANKET BAFFLE PROTECTION CHANNEL BAFFLE BOARDS Figure 24.1 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 25: Installer's Guide

    • DO NOT CONNECT TO ANY AIR DISTRIBUTION you are overfi ring. DUCT OR SYSTEM. Any such action that may cause a fi re hazard. May allow fl ue gases to enter the house. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 26: Negative Pressure

    Recessed lighting should be a “sealed can” design • Attic hatches weather stripped or sealed • Attic mounted duct work and air handler joints and seams taped or sealed • Basement installations should be avoided Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 27: Locating Your Appliance And Chimney

    Must be located away from trees or other structures NOTICE: • Chimney performance may vary. • Trees, buildings, roof lines and wind conditions affect performance. • Chimney height may need adjustment if smoking or overdraft occurs. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 28: Rule

    Pitched Roof 10 ft. (305cm) or more Less than 10 ft. (305cm) Wall or Parapet 2 ft. (61cm) Minimum 3 ft. (91cm) Minimum 3 ft. (91cm) Minimum Flat Roof Figure 28.2 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 29: Tools And Supplies Needed

    Report to your dealer any parts damaged in shipment. • Read all the instructions before starting the installation. Follow these instructions carefully during the installation to ensure maximum safety and benefi t. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 30: Section 7: Dimensions And Clearances

    6 in. (152mm) 21-1/16 in. 20 in. (534mm) (508mm) 23-3/4 (603mm) 6-1/16 in. (154mm) 4-1/2 in. (114mm) Figure 30.3 - Side View With Optional Flue Adapter Figure 30.4 - Side View Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 31: Clearances To Combustibles (Ul And Ulc)

    • Failure to comply may cause house fi re. NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction Figure 31.1 - Mantel Clearance Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 32 Figure 32.2 - Thermal Protection Required USA and CANADA Hearth Height Greater than 7 inches (178mm) Thermal Protection Required Greater than 7 inch (178mm) Non-Combustible Ember Protection Figure 32.3 - Ember Protection Only Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 33: Alternate Floor Protection Calculation

    For multiple layers, add R-values of each layer to determine overall R-value. 3. If the overall R-value of the system is greater than the R-value of the specifi ed fl oor protector, the alternate is ac- ceptable. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 34: Section 8: Chimney Systems

    NOTICE: Check with your local building authorities and/or consult the National Fire Protection Association (NFPA 211). Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 35: Masonry Chimney

    Seal with Non-Combustible Material Listing Combustible Floor NOTE: Generic wood insert shown - not model specifi c Figure 35.1 - Masonry Chimney with a Full Liner Kit Type UL103HT Rquirement per UL1777 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 36: Metal Heat Circulating Chimney

    fi replace. 3. Both methods must be removable and replaceable WARNING! Risk of Fire! for cleaning and re-installation. Follow venting manufacturer’s clearances and instructions when installing venting system. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 37: Securing Chimney Components

    This may allow fl ue gases to enter the house. THIS FIREPLACE MAY HAVE BEEN ALTERED TO ACCOMMODATE AN INSERT. IT MUST BE RETURNED TO ITS ORIGINAL CONDITION BEFORE USE AS A SOLID FUEL BURNING FIREPLACE. 250-2061 250-2061 Figure 37.2 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 38: Ovalizing Round Stainless Steel Liners

    • Lose protection to combustible surfaces from the K. Chimney Height / Rise and Run liner in case of fi re. To be sure that your Heatilator insert burns properly, the • Poor performance and start-ups. chimney draft (static pressure) should be approximately -0.10 •...
  • Page 39: Section 9: Appliance Set-Up

    5. After sliding can into fi replace, feed fl ex into cut opening to obtain outside combustion air. 6. Install appliance. Rear Outside Air Cover Plate Front Outside Air Cover Plate Optional Outside Air Venting Kit OAK-ACC Figure 39.1 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 40: Securing Stove Pipe/Liner To Flue Collar

    Attach the upper and lower chambers with screws provided. Figure 40.5. 5. Repeat the process on the bottom side. Figure 40.5 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 41: Securing Appliance To Stove Pipe/Liner

    Secure 2 Side Surrounds to Top Surround Figure 41.2 5/16 Bolts Attachment Corner Brackets Figure 41.3 5/16 Nuts Figure 41.1 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 42: Section 10: Moble Home Installation

    UMC Table 9C. This installation must also comply with NFPA 211. NOTICE: Top sections of chimney must be removable to allow maximum clearance of 13.5 feet (411cm) from ground level for transportation purposes. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 43: Section 11: Reference Materials

    Reference Materials ECO-WINS18 Service Parts Beginning Manufacturing Date: May 2011 Wood Insert Ending Manufacturing Date: Active 16 17 Part number list on following page. 05/11 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 44 Fiber baffle Baffle protection Channel sits In between This tab sits behind the front tube. Front tube and Fiber baffle. Baffl e Protection Channel SRV7056-147 Additional Service Parts on following page. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 45 Brick 2 (9 X 3.25 X 1.25) Qty 2 req. 13.3 Brick 3 (9 x 2.5 x 1.25) Qty 2 req. Brick, Single Uncut 832-0550 Brick, 6 Pack Uncut 832-3040 Additional Service Parts on following page. Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 46 226-0130/4 Nut, Wing 8-32 226-0160/24 Screw Hwh Ms 1/4 X 34 Ns 220-0080/25 Screw Pan Head Phillips Tc 8-32X1/2 220-0030/25 Screw, Pan Head Phillips 8-32 X 3/8 225-0500/40 Washer, SAE 227-0080/24 Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 47: Service Maintenance Log

    Service And Maintenance Log Date of Service Performed By Description of Service Heatilator • ECO-WINS18 • 7065-132F • May 4, 2015...
  • Page 48: Contact Information

    Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Heatilator dealer with any questions or concerns. For the number of your nearest Heatilator dealer, please visit www.heatilator.com or www.heatilatorecochoice.com. For Consumer Care 1-866-427-3316 Prior to calling, please have the model and serial number of the unit you are calling about.
