Owner's Manual
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fire hazard and will void the warranty.
• Fig. 3,4,5,6, 7 and Table 1,2,3,4 relate to installations with tested flue systems; as per AS/NZS
2918:2001 - Appendix F, with a ceiling angle between 0° - 30° inclusive.
• For installations with a ceiling angle greater than 30°, refer to Fig. 7 & 8 and AS/NZS 2918:2001
4.6.3(b)
• Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to
ordering the ceiling plate.
• Heatilator Eco Choice series wood burner's are tested and approved to the N.Z. National Environ-
mental Standards;
Particulate Emissions = 1.0 g/kg Space Heating Efficiency = 77%
Page 1
Eco-Choice Insert Wood Burner Installation Instructions
WINS18-AU
INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001
AND WILL REQUIRE A BUILDING CONSENT
WINS18-AU Eco-Choice Hardwood Certified
Model:
7065-144A
April 7, 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heatilator WINS18-AU
Summary of Contents for Heatilator WINS18-AU
- Page 1 • Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to ordering the ceiling plate. • Heatilator Eco Choice series wood burner’s are tested and approved to the N.Z. National Environ- mental Standards; WINS18-AU Eco-Choice Hardwood Certified Particulate Emissions = 1.0 g/kg Space Heating Efficiency = 77%...
- Page 2 Hearth & Home Technologies welcomes you to our tradi- our stoves, inserts and fireplaces. And yet we are old-fash- tion of excellence! In choosing a Heatilator appliance, you ioned when it comes to craftsmanship. Each unit is meticu- have our assurance of commitment to quality, durability, and lously fabricated and surfaces are hand-finished for lasting performance.
- Page 3 WS Series Wood Burner Heatilator WS18 Wood Burner Dimensions Surround Sizes SP-WINS18-STD 1092mm 787mm Figure 3.1 - Front View SP-WINS18-LRG 1295mm 864mm 7-5/16 in. 10-1/2 in. (186mm) (267mm) 24-1/4 in. 5-3/16 in. (616mm) (132mm) 15-11/16 in. (398mm) 10-1/2 in. (267mm) 21-1/16 in.
-
Page 4: Floor Protector
WS Series Wood Burner FLOOR PROTECTOR Heatilator WINS18 does require a insulating Floor Protector minimum 900mm deep, 800mm wide and 75mm thick (clay bricks), as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪... - Page 5 WS Series Wood Burner MINIMUM CLEARANCES (CONT.) Fig. 4 Mantle uprights must be less than 50mm thick 800mm Page 5 April 7, 2014 7065-144A...
-
Page 6: General Instructions For Flue System
WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM A. Venting Systems 3. Both methods must be removable and replaceable for cleaning and re-installation. Chimney Connector: It is also known as flue pipe or stove • When possible, install an airtight clean-out door to the pipe. - Page 7 WS Series Wood Burner E. Prefabricated Metal Chimney (Cont’d) flue, but will also help increase the unit’s efficiency and decrease creosote deposits in the chimney. To maintain the functionality of the fireplace’s chimney system you may use a Simpson Dura-Vent DuraLiner When a connected flue or liner is in use, the insert is able Slip Hanger, Part # 4671, and attach to the bottom of the to “breathe”...
- Page 8 WS Series Wood Burner UL 1777 Insulated Stainless Steel Follow Manufacturer’s Liner or Other Approved Lining System Instructions for Maximum Liner Extension Above Follow Manufacturer’s Instructions Chimney on Insulation and Support Maximum 30 Degrees Offset in Chimney For Zero or Other Non-Code Clearances, Follow Approved Liner Manufacturer’s Specific Insulation Requirements: Different Clearances May Require Different Specifications...
- Page 9 WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including firebox spigot. - fix with a minimum of 3 stainless steel rivets ▪...
- Page 10 WS Series Wood Burner A. WARNINGS: AS/NZS 2918:2001 General Notes WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULA- TORY AUTHORITY, I.E.
- Page 11 WS Series Wood Burner AUSTRALIAN WARRANTY INFORMATION Hearth & Home Technologies Inc (HHT) 1445 N. Highway Colville, WA 99114 (509-684-3745) www.quadrafire.com HHT extends the following manufacturer’s warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer.
-
Page 12: Other Rights
WS Series Wood Burner OTHER RIGHTS The HHT manufacturer’s warranty is in addition to other rights and remedies that you may have under Australian law. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. -
Page 13: Service & Maintenance Log
WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 13 April 7, 2014 7065-144A... - Page 14 WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 14 7065-144A April 7, 2014...
- Page 15 WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 15 April 7, 2014 7065-144A...
- Page 16 Please contact your Heatilator dealer with any questions or concerns. For the number of your nearest Heatilator dealer log onto www.jetmaster.com.au CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and • • follow these instruc-...
