INSTALLATION & OPERATING
INSTRUCTIONS
EC36
EC39
EC42

WOODBURNING FIREPLACE

Note:
An arrow ( ) found in the text signifies change in content.
WARNING!
Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this
manual. For assistance or additional information, consult a qualified installer, service agency or the gas supplier.
08/04
17339 Rev L
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC36 and is the answer not in the manual?

Questions and answers

Angela Knipker
March 5, 2025

Is the EC36 a gas unit

0
1 comments:
Mr. Anderson
March 5, 2025

Yes, the Heatilator EC36 is a gas log fireplace unit.

This answer is automatically generated

0

Related Manuals for Heatilator EC36

Summary of Contents for Heatilator EC36

  • Page 1: Woodburning Fireplace

    INSTALLATION & OPERATING INSTRUCTIONS EC36 EC39 EC42 WOODBURNING FIREPLACE Note: An arrow ( ) found in the text signifies change in content. WARNING! Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information, consult a qualified installer, service agency or the gas supplier.
