11. KN6 TECHNICAL DETAILS

Power handling
Maximum
amplifier power
Impedance
Operating
frequency range
SPL 1W/1mt
Maximum SPL
Horizontal
Vertical
Type
Frequency
Low - Mid frequency
High frequency 3 x 0.5" Neodymium compression driver with 1" voice coil
Connectors
Wiring
Connectors
2 x 250W class D amplifier channel - DSP controlled
Type
Power (woofer)
Power (driver)
Protection Dynamic limiter, over current, over temp, short circuits
Operating range
Max continuous
and burst current
Dimensions
Weight
Notes for data
1. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS
voltage that the amplifier will produce into the nominal load impedance .
New materials and design are introduced into existing products without previous
notice. Present systems may differ in some respects from those presented in this
brochure.
KN6
Acoustics
2x250 + 3x20 w
(AES)
2x500 + 3x40 w
(EIAJ)
2x4Ω + 3x16Ω
45Hz - 19 KHz +/- 3dB (preset dependent)
96 dB (low) 104 dB (high)
125 dB continuous - 131 dB peak
Coverage
(in horizontal position)
130°
selectable from 10° to 130°
Crossover
DSP controlled
1.8 KHz minimum (preset dependent)
Transducers
2 x 6" Neodymium speakers with 2.5" voice coil
Audio Input
male + female parallel 3-pin balanced XLR
PIN1= ground PIN2 = hot (+) PIN3 = cold (-)
Power Input
1 x 3-pin PowerCon
Amplifiers
+ 2 x 20W class A/B amplifier channel
350 + 350 Watt
2 x 40 Watt
1
AC power
85 - 270 Vac 50/60Hz
140VA(>10 sec) - 700VA (<1 sec) autorange
Physical
19 x 50.5 x 17.5 cm (7.48"x 19.88"x 6.89")
9 Kg (19.84 lbs)
1
autorange
rev.A
