Lexmark Optra C710 User Manual page 154

140
Chapter 7: Replacing the transfer kit
9
Align the bottom of the transfer belt with rails
inside the printer.
To install the transfer belt, hold it by the green tabs.
10
Push the transfer belt into the printer until it is
firmly seated.
To replace the transfer roller:
1
Squeeze the two green snap locks on each side of
the transfer roller.
When you squeeze the two snap locks, the springs
under the transfer roller will cause the transfer
roller to raise up.
