Elite Fitness ITM 4600-E Owner's Manual

Elite Fitness ITM 4600-E Owner's Manual

Deluxe heat & massage inversion table

Advertisement

Deluxe Heat & Massage Inversion Table
Model ITM 4600-E
CAUTION:
WARNING: Do not use this
inversion table without a
physician's approval.
Do not let children use the
inversion table unsupervised.
Read all instructions carefully
before using.
Tighten all bolts before using
equipment.
Leave adequate space to
Leave adequate space to
properly invert.
Questions/ Comments
PLEASE DO NOT CONTACT THE
STORE
Elite Fitness is committed to
providing the very best of quality
and customer satisfaction for all of
the products we distribute. If for
any reason , you are dissatisfied
with the product you have
purchased or need assistance in
any way, please do not hesitate to
contact our knowledgeable support
623-888-6379
staff at:
Mon.-Fri 9:00 am – 5:00 pm Mountain Time
Photo may differ from actual product
1
Owner's Manual
Version:041713

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ITM 4600-E and is the answer not in the manual?

Questions and answers

Susan Weckwerth
June 15, 2025

Can I order a new AC power adapter for my Elite Fitness Deluxe Massage Inversion Table Model ITM 4600-E?

Subscribe to Our Youtube Channel

Summary of Contents for Elite Fitness ITM 4600-E

  • Page 1 Leave adequate space to properly invert. Questions/ Comments PLEASE DO NOT CONTACT THE STORE Elite Fitness is committed to providing the very best of quality and customer satisfaction for all of the products we distribute. If for any reason , you are dissatisfied...
  • Page 2 Fitness Customer Service Number at 623-888-6379 for assistance in the repair or replacement of the product or any covered part. Elite Fitness will repair or replace, at its own option, the product or any covered part, except that this warranty does not cover damage caused by accident ( including transit) , or repairs or attempted repairs by any person not authorized by Elite Fitness, or by vandalism, misuse, abuse, or alteration.
  • Page 3: Parts Listing

    Parts Listing Part# Description Part# Description Bottom Front Tube Bolt-M8x20mm Backrest Support Tube Oval End Caps-Foot Rest Body Height Adjustment Tube Base Frame End Caps- Foot Rest Plate Hexagonal Bolt-M8x65mm Adjustable Leg Hold Tube Square End Cap-for Part3 Handlebar-RIGHT Stopper Handlebar-LEFT EVA Space Pad Base-frame-REAR-LEFT...
  • Page 4: Exploded View

    Exploded View...
  • Page 5 Base Frame and Handlebar Assembly STEP 1- Base Frame Unpack Base frame from Carton. Attach the Bottom Front Tube(1) Parts Needed to the Front Baseframe(9) using 2-Bolts(32). Insert two Base Frame End Caps (31) into the Bottom Front Tube (1). Attach the Bottom Rear Tube(53) to the Front Baseframe(9) using 2-Bolts(54).
  • Page 6: Handlebar Assembly

    Handlebar Assembly STEP 2 ( Cont) Attach the Handlebar Right (6) to the Base frame Rear(8R) using 2 Bolts (20), 2 Washers (19), and 2 Nuts (21). Use Bolt (22) and Flat Washer (19) to fix the Base frame Rear(8R) .Repeat for Handlebar Left (7) except there will not be a part 22 or 19 for this side.
  • Page 7 Backrest Assembly to Base Frame Note: Heat Massage Lumbar Pad can be adjusted up and down the back pad with the use of the Velcro strips included mounted to the rear of the pad STEP 3 Connecting Backrest Attach the Completed Backrest Pad Assembly to the Base frame Unit using Bolts (29), Flat Washers (19) and Lock Nuts (21).
  • Page 8 STEP 4-Body Height Adjustment Tube and Rollers Install Foot Rest Plate (4) into Adjustment Tube (3) using Hexagonal Bolt (52), Metal Bushing (51) Flat Washer (19) and Lock Nut (21). Pull out Adjustable Leg Hold Tube(5) and position horizontally as shown.( This will have spring pre-assembled inside Tube from factory which should not be removed) Install Leg Tube (10) through hole in Adjustment Tube (3) using Hexagonal...
  • Page 9: Step 5-Final Assembly

    STEP 5-Final Assembly Slide Height Adjustment Tube (3) into Backrest Support Tube ( 2) and lock into place using Height Adjustment Knob (38). Ball Pin (26) is used to lock Height Adjustment Tube in place when desired Height Adjustment is obtained. Note: This product is designed to adjust from 5’1”...
  • Page 10 Heat/Massage Pad and Head Pad Assembly to Backrest Pad Step 6 Connecting Head Pad and Massage/Heat Pad Step 6 Connecting Head Pad and Massage/Heat Pad Attach the Backrest Massage/heat Pad(56)and the Head Pad(48) to Backrest Pad(47) in Desired Position using Velcro. Controller(58) can be stored in Right Side Pocket of Backrest Pad(47) for easy access.
  • Page 11: Controller Instruction

    Controller Instruction Connect the product with power source by 12V 1.2A adaptor and the indicator light of "POWER" will blink into standby. Press the "POWER" button to start the massage function, Press “AUTO” button the power indicator and the massage light will stop modes and intensities blinking, the massage...
  • Page 12 To reduce the risk of serious injury, read all important precautions instructions and warnings in this manual before using the Inversion System. Elite Fitness, or Extreme Products Group assumes no responsibility for personal injury or property damage sustained by or through the use of the Inversion System.
  • Page 13: Usage Guidelines

    USAGE GUIDELINES INVERSION SELECTOR PIN Familiarize yourself with the Inversion Selector Pin located on the Right Side of the Inversion Table. The positioning of the pin will determine the degree of Inversion that you are comfortable with. The 3 selections are: 20- Slight Inversion 40-Moderate Inversion 60- Enhanced Inversion...
  • Page 14 USAGE GUIDELINES- Securing Feet and Ankles WARNING: ALWAYS WEAR ATHLETIC SHOES WITH LACES TIGHT TO HELP SECURE YOUR FEET IN THE INVERSION SYSTEM, AND FOR FOOT PROTECTION WHILE EXERCISING. ALWAYS MAKE SURE THAT THE ANKLE LOCK IS SECURED SNUGLY AGAINST YOUR ANKLES AND THAT THE LONG KNOB IS FULLY TIGHTENED BEFORE YOU USE THE INVERSION SYSTEM Step 1- Expand the front rollers by pulling up on the...
  • Page 15 USAGE GUIDELINES Finding the Proper Height and Weight Adjustment With head flat on back pad, slowly raise one arm up toward the ceiling. If the bed starts to invert backward, the height adjustment should be correct. If the bed does not start to invert, adjust the center slider arm upward one position at a time, until the bed starts to invert backward.
  • Page 16 ELITE FITNESS ELITE FITNESS Distributed By: Extreme Products Group 6635 W. Happy Valley Rd Suite A-104, #213 Phoenix, AZ 85310 Phone: 623-888-6379 Fax: 623-434-9100 service@extremeproductsgroup.com For All parts requests, please visit our web site at www.extremeproductsgroup.com...
