ADJ LED Beam Scan User Instructions page 8

LED Beam Scan
Channel Value
1 0 - 255
2
0 - 7
8 - 190
191 - 200
201 - 247
248 - 255
3
0 - 7
8 - 29
30 - 50
51 - 71
72 - 93
94 - 114
115 - 135
136 - 157
158 - 178
179 - 199
200 - 221
222 - 242
243 - 255
American DJ - www.americandj.com - LED Beam Scan Instruction Manual Page 15
®
3 Channel Mode - DMX Traits
Function
PAN
MASTER DIMMER/STROBE
BLACKOUT
DIMMING 0% - 100%
SOUND ACTIVE STROBE
STROBING SLOW - FAST
OPEN
MOVEMENT
NO FUNCTION
MOVEMENT 1
MOVEMENT 2
MOVEMENT 3
MOVEMENT 4
MOVEMENT 5
MOVEMENT 6
MOVEMENT 7
MOVEMENT 8
MOVEMENT 9
MOVEMENT 10
MOVEMENT 11
MOVEMENT 12
LED Beam Scan
Channel Value
1 0 - 255
2
0 - 255
3
0 - 7
8 - 29
30 - 50
51 - 71
72 - 93
94 - 114
115 - 135
136 - 157
158 - 178
179 - 199
200 - 221
222 - 242
243 - 255
4
0 - 255
5
0 - 8
9 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 255
American DJ - www.americandj.com - LED Beam Scan Instruction Manual Page 16
®
5 Channel Mode - DMX Traits
Function
PAN
PAN SPEED
FAST - SLOW
MOVEMENT
NO FUNCTION
MOVEMENT 1
MOVEMENT 2
MOVEMENT 3
MOVEMENT 4
MOVEMENT 5
MOVEMENT 6
MOVEMENT 7
MOVEMENT 8
MOVEMENT 9
MOVEMENT 10
MOVEMENT 11
MOVEMENT 12
MASTER DIMMER
0% - 100%
STROBE
OPEN
STROBING SLOW - FAST
OPEN
FAST CLOSE - SLOW OPEN
OPEN
FAST OPEN - SLOW CLOSE
OPEN
