ADJ LED Beam Scan User Instructions page 6

LED Beam Scan
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to activate sound active mode, or
"OFF" to deactivate sound active mode.
3. Press ENTER to confirm.
BLND -
Blackout or Stand by mode.
1. Tap the MENU button until "BLND" is displayed, press
ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until "Yes"
is displayed, press ENTER to confim. The fixture will now be in
Blackout mode. To deactivate Blackout mode, select "No" and
press Enter.
LED -
With this function you can have the LED display
turn off after 10 seconds.
1. Tap the MENU button until "LED" is displayed, press ENTER.
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to keep the LED display on at
all times, or "OFF" to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to confirm.
IDSP -
This function will reverse the display 180º.
1. Tap the MENU button until "IDSP" is displayed, press ENTER.
2. Press ENTER to "flip" the display. Press ENTER to "flip" it
again. Press ENTER when you have made your desired setup.
TEST
- This function will run a self test program. The test
program will test pan/tilt movement and colors.
American DJ - www.americandj.com - LED Beam Scan Instruction Manual Page 11
®
System Menu LED Beam Scan
1. Tap the MENU button until "TEST" is displayed, press ENTER.
2. The fixture will now run a self test.
FHRS
of the unit.
1. Tap the MENU button until "FHRS" is displayed, press
ENTER.
2. The running time of the fixture will now be displayed. Press
MENU to exit.
VER
ware of the unit.
1. Tap the MENU button until "VER" is displayed, press ENTER.
2. The software version will now be displayed. Press MENU to
exit.
REST
1. Tap the MENU button until "REST" is displayed, press ENTER.
2. The fixture will now reset.
LED Beam Scan
With this feature you can connect the fixtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 48 fixtures maximum. After 48 fixtures you will need
to use a new power outlet. They must be the same fixtures. DO
NOT mix fixtures.
American DJ
- With this function you can display the running time
- With this function you can display the version soft-
- Use this function to reset the unit.
- www.americandj.com - LED Beam Scan Instruction Manual Page 12
®
System Menu
Power Cord Daisy Chaining
