Page 1: Unilinc Control
Washer-Extractor Pocket Hardmount UniLinc Control Refer to Page 9 for Model Identification PHM14 PHM1423C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. F8434101R1 www.comlaundry.com April 2012... -
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 4 Audio Menu ..................41 Balance Retry Menu ................41 Water Management Menu ..............42 Alarms Program Menu ................. 44 Rapid Advance Menu ................44 Shakeout Menu ..................45 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 5 Invalid Parameter Set Error ............. 59 Maximum Current Exceeded Error..........59 Current Sensor Error ................ 59 Low DC Bus Error ................59 Invalid Command Error ..............59 Last Drive Error ................59 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 6 Service Schedule Menu ................ 62 Daily Menu (Service)............... 62 Weekly Menu (Service) ..............62 Monthly Menu (Service)..............63 Quarterly Menu (Service) ..............63 Cycle Charts ..................64 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 7: Safety Information
6. To reduce the risk of an electric shock or fire, DO NOT use an extension cord or an adapter to connect the washer to the electrical power source. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... - Page 8 The air gap must be maintained. 17. Do not operate the machine without the water reuse plug or water reuse system in place, if applicable. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 9: Safety Decals
SW020 CAUTION Be careful around the open door, particularly when loading from a level below the door. Impact with door edges can cause personal injury. SW025 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 10: Operator Safety
Do not bypass any safety devices in the machine. WARNING Operating the machine with severe out-of- balance loads could result in personal injury and serious equipment damage. W728 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 11: Introduction
Information in this manual is applicable to these models: UWL045T3V UWN065T4L UWL045T4V UWN065T4M UWL065T3V UWU045T3V UWL065T4V UWU045T4V UWN045T3V UWU065T3L UWN045T4V UWU065T3M UWN065T4V UWU065T3V UWN065T3L UWU065T4L UWN065T3M UWU065T4M UWN065T3V UWU065T4V © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 12: Nameplate Location
EXAMPLE OF MACHINE NAMEPLATE LOCATION Phone: +1 (920) 748-3121 Ripon, Wisconsin Alliance International +32 56 41 20 54 Wevelgem, Belgium PHM847N PHM847N In UniLinc Control At back of machine Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 13: Preliminary Information
The control has the ability to communicate through a network. The network link allows the user to program, collect data, and run diagnostics on any machine in the network from a central location. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 14: Ir Communications Menu
Advanced Options for Water Management = Disabled Water Leak Detection During Machine Cycle = Disabled Number of Cycles Between = 0 Day(s) Occuring = none © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 15: Entering Program Mode
UniLinc can only be made with an external communication device. Refer to UniLinc PC and PDA Applications User Instructions. Refer to Factory Defaults, Menu section for information on Restoring Factory Defaults. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 16: Unilinc Identification
Press to start or rapid advance a machine cycle during Run Mode. Also, press to START/ENTER save edited programming values when used in programming menus. Table 1 F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 17: Operation Modes
Mode if loading door unlocks or opens. or communication with a device. The diagnostic tests available from the Idle Mode are the Test Cycle, Test Balance Weight, and Inputs Outputs Menus. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 18: Machine Cycle Definition And Operation
Total Remaining Cycle Time displayed is corrected at the start of the cycle’s final enabled step that has programmed time duration. F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 19: To Start A Cycle
Monthly Menu displays on all other first days of the month. Weekly Menu displays on a Monday not on the first day of the month. All other days the control will display the Daily Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 20: Run Menu
Supplies are only shown during the fill and supply steps. During the agitate steps the type of agitation is shown. During the extract steps, the extraction speed displays. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... - Page 21 Run menus. When the keypad is pressed, the display will jump to the Cycle Stopped Menu showing an hourglass. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 22: Contrast/Backlight Menu
Press the keypad to enter the previous page. If the Contrast Adjust/Backlight Menu is selected from the Run Menu and the keypad is pressed, the Cycle is aborted. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 23: Lubricate Bearings Menu
If the keypad is pressed, display enters Run Menu. If nothing is selected for 15 seconds, the display will return to Run Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 24: Speed, Temp And Water Level Menu
The Cycle Aborted Retry Menu will be displayed for a fill, drain or heater alarm time error. The display will toggle this page with the Run Menu every three seconds. Press to resume the cycle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 25: Cycle Aborted Fatal Menu
Idle Mode. The control will return to the previously aborted cycle in the Last 10 Cycles Rapid Advance or displayed menu when the error clears. Stopped Audit Queue. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 26: Delayed Start Countdown Menu
Press keypad to return to the Cycle Menu. When there is sixty seconds left on the countdown, control will enter the Delayed Start Final Countdown Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 27: Menu Navigation
“0” through “9” when using the keypad. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 28: Display Screen Maps
Drive Test Alarms Confirmation Second Audio Confirmation Confirmation Save Changes Menu All Defaults Confirmation (After all Step Menus and Global Menus except Factory Defaults) PHM1483R PHM1483R Figure 20 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 29: Run Menu Map Tree
Lube Bearing Menu Daily Menu ..Delayed Start Menu Weekly Menu Auto - Leak Detect Menu Monthly Menu Quarterly Menu PHM1272R PHM1272R Figure 22 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 30: Programming Unilinc
Reset and the control resets the total operation time since the bearings were last serviced. This menu item will not be an option on machines that do not have a greasable bearing. F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 31: Program Menu
Modify Cycle character of the string. PHM1023R Press the keypad to exit string edit mode. Figure 26 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 32: Available Characters
ç è é ê ë ì í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü ý þ ÿ Table 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 33: Cycle, Segment And Step Programming Flow Diagram
Fill Step but not the Reuse Fill Step, so, the water temperature parameter will not be shown in the Reuse Fill Step. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 34: Reuse Fill Step Menu
Fill A and Reuse Fill B are deactivated, Aux Fill will activate by default. If Water Reuse is enabled, the Aux Fill will be on by default. Press the keypad to return to Save Changes Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 35: Fill Step Menu
Press the keypad to enter the Save Changes (HIGH). Menu. The valves used to fill can be selected individually. The valve settings are Fill, Spray or Both. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 36: Heater Option
E S 6 Changes Menu. E S 3 E S 7 E S 4 E S 8 m m : s s Modify Cycle PHM1027R Figure 30 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 37: Agitate Step Menu
“No Rotation”, the cycle step time can be programmed to a value from one (1) minute to 24 hours. Pressing the keypad will jump to the Save Changes Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 38: Drain Step Menu
Pressing the keypad will jump to the Save step would be the EOS Audio Signal Menu. Changes Menu. Press the keypad to jump to the Save Changes Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 39: Extract Step Menu
Time. Press . Blinking underline will indicate number to change. Use keypads to change numbers. Press the keypad to jump to the Save Changes Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 40: End Of Segment Audio Signal Step Menu
Save Changes Menu. Modify Cycle PHM1034R PHM1034R Figure 38 Cycle01: Towels White Bleach Segment01: Prewash EOS Audio Signal: Modify Cycle PHM1035R PHM1035R Figure 39 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 41: Global Setup
“Yes” or “No”. The Language Menu is used to select the language displayed. The user can choose English, Spanish, Italian, French, German or Portuguese. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 42: Water Level Menu
The regions are found in Table 3. option will allow the user, with a temperature sensor present, to chose whether to run the machine with Temperature controlled Fill On or Off. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 43: Audio Menu
Audio Menu. Once the item is highlighted, press the keypads to change the value. Press keypad to return to the Save Changes Menu if changes were made. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 44: Water Management Menu
Global Setup menu. Cycle textbox is highlighted. To view Water Management 2 Menu, press keypad while the “External Dispenser Pause” textbox is highlighted/ © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... - Page 45 To view Water Management 1 Menu, press Cycle textbox is highlighted. keypad until the menu is displayed. To view Water Management 3 Menu, press keypad while Auto-Water Leak Detection textbox is highlighted. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 46: Alarms Program Menu
Rapid Advance, the user may still execute a Rapid Advance using the PC/PDA through the network. Enable the Rapid Advance Feature During Cycle Operation? Rapid Advance PHM1045R Figure 52 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 47: Shakeout Menu
“Yes” or “No”. Press the Figure 54 keypad to return to Global Setup menu. If no changes were made, press the keypad to return to Global Setup Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 48: Water Level Confirmation Menu
Factory Defaults Menu. Once the confirmation is chosen the display will jump back to the Factory Defaults Menu. “No” is selected by default. Factory Defaults PHM1050R Figure 57 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 49: Audio Confirmation Menu
Selecting “Yes” will restore all the factory settings and take the user back to the Global Settings Menu. Selecting “No” will take the user back to the Factory Defaults Menu. Factory Defaults PHM1053R Figure 60 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 50: Diagnostic
DC bus value. Press the keypad to return to Diagnostic Menu. F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 51: Test Cycle
Int Supply #1 “Internal Supply #1” Keypress or Wash Speed Agitate 30 seconds Int Supply #2 “Internal Supply #2” Keypress or Wash Speed Agitate 30 seconds Table 4 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... - Page 52 Step skipped if Global or 5 seconds Audio Signal and Global External Signal is disabled. Coast Time “Coast” Table 4 * Step is skipped if no heater in machine. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 53: Factory Valve Purge Menu
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... - Page 54 External Supply 8 Water Level (Level Satisfied) Hot Fill Temp Temperature Sensor Value Hot Spray Revolutions per Minute Heater Reuse Drain B Reuse Fill A Table 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
-
Page 55: Water Leak Detection Diagnostic
Begin Then Press START to Begin Test Finished, Result: RPM: 0 DC Bus: 0 PASS Drive Test Water Leak Detection PHM1480R Figure 69 PHM1207R Figure 68 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 56: Alarms
Alarms (2 of 3) PHM1417R Figure 71 ALARM COUNTS Count Short Count Unbalance Count Heat Count Level Count Count Count Network Alarms (3 of 3) PHM1418R Figure 72 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 57: Machine Identification
The machine cycle is aborted and the user is only given the option of clearing the Cycle Aborted Error Menu and returning to the Cycle Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 58: Frame Balance Switch Error
The machine cycle is aborted and the user is only given the option of clearing the Cycle Aborted Error Menu and returning to the Cycle Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 59: Water Level Sensor Error
The error is added to a queue that holds the last 8 machine errors. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 60: Slow Drain Detected During A Machine Cycle Error
(1 of 3) Menu. The audio signal will also be turned on for the error condition. If the loading door is locked, the control will unlock the door once no water and no coastdown time are detected. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 61: Ipm Overtemperature Error
(1 of 3) Menu. The audio signal will also be turned on for the error condition. The Cycle Aborted Error Menu is displayed with the alarm on until the appropriate user input occurs. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 62: Laundry Management
Laundry Management 1 of 3 CY08: CY16: CY24: screen. Laundry Mgmt. (2 of 3) Press the keypad in any of the Laundry PHM1065R Management Menus to enter System Menu. Figure 77 F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 63: Total Number Of Machine Cycle Counters
Total Number of Operation Minutes audit counter (not re-settable and displayed in hours) and the Total Number of Operating Minutes Since Bearings Last Serviced auto counter. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 64: Maintenance
2. Inspect all chemical inlets, lines and connections for leaks. 3. Clean inverter drive box filter. 4. Clean door gasket. 5. Clean top, front and side panels. Service Schedule PHM708N Figure 80 F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 65: Monthly Menu (Service)
The Monthly Menu contains all monthly service reminders that need to be performed. Press to view Monthly Menu (2 of 2). Press the keypad to return to Service Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101... -
Page 66: Cycle Charts
Warm 18/3/18 Warm High 2 Min 2 Min #5 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) F8434101 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... - Page 67 Cold 18/3/18 Cold High 2 Min 2 Min #5 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 68 Cold 18/3/18 Cold High 2 Min 2 Min #5 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 4 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 69 Warm 18/3/18 Warm High 2 Min 2 Min #6 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 70 Cold 18/3/18 Cold High 2 Min 2 Min #5 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 71 18/3/18 Cold High 2 Min 2 Min #5 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 72 Warm 18/3/18 Warm High 2 Min 2 Min #7 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 73 Warm 18/3/18 Warm High 2 Min 2 Min #9 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 74 Warm 18/3/18 Warm High 2 Min 2 Min #7 Rinse Warm S3, S4 18/3/18 Medium Yes & ES3, 45 Sec 4 Min 3 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 75 Cold 18/3/18 Cold High 2 Min 2 Min #6 Rinse Warm S3, S4 18/3/18 Medium Yes & ES3, 45 Sec 4 Min 3 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 76 #5 Rinse Warm 18/3/18 Warm High 2 Min 2 Min #6 Rinse Warm S5, ES5 18/3/18 Ultra High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 77 #4 Rinse Warm 18/3/18 Warm High 2 Min 2 Min #5 Rinse Warm S5, ES5 18/3/18 Ultra High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 78 ES1, 45 Sec 8 Min 2 Min 30 Sec #2 Rinse Warm S3, S4, 18/3/18 Ultra ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 79 High 2 Min #8 Rinse Warm 18/3/18 High 2 Min #9 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 2 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 80 Warm 18/3/18 Warm High 2 Min 2 Min #9 Rinse Warm S3, S4 18/3/18 Ultra & ES3, High 45 Sec 4 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 81 #2 Rinse Warm 18/3/18 Medium High 3 Min 1 Min #3 Rinse Warm 18/3/18 Warm Ultra High High 3 Min 2 Min 5 Min Table 6 (Continued) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
- Page 82 S3, S4, 18/3/18 Set Up Set Up & S5 & ES1, ES3, ES4, 45 Sec 45 Sec 2 Min #2 Rinse Warm 18/3/18 1 Min Table 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8434101...
