RT-10
Note the following:
• The RT-10 is manufactured for sale in several different countries.
Certain parameters are not available on some versions. Default
parameter settings might differ among versions.
• The Setup menu can be opened while the RT-10 is in playback,
pause, resume, or stop mode. However, certain parameters
cannot be adjusted when some playback modes are activated.
In addition, certain parameters can be adjusted when playback
is activated, although the setting does not take effect until stop
mode is activated.
• The Setup menu can be opened regardless of the format of the
loaded disc. However, certain parameters cannot be adjusted
when some disc formats are loaded.
• Certain parameter settings have no effect on some disc formats.
When a parameter is selected, colored boxes appear next to
each parameter setting on the on-screen display to indicate the
disc formats on which each setting has an effect. The table
shown below indicates the disc formats each color represents.
Color Disc Formats
Green All disc formats
Blue DVD-V, DVD-A, DVD-RW/R
Yellow DVD-V and Video CD
Orange DVD-A, Audio CD, SACD
This table lists colors that might differ depending on RT-10 settings
and display device capabilities.
• The icon shown at the right appears on the on-screen
display when a Setup menu parameter that is
exclusive to DVD formats is adjusted while another
disc format is loaded. These adjustments will take
effect the next time a DVD is loaded.
AUDIO1
Includes parameters that control digital audio output format.
Parameter Default Setting
Audio DRC Off
Dolby Digital Out Dolby Digital `
DTS Out
DTS PCM
Linear PCM Out Down Sample On
MPEG Out MPEG PCM `
Digital Out* On `
SACD Playback* 2ch Area
* These parameters only appear when the Setup menu is displayed in expert mode
(3-9 and 3-42).
` These settings are recommended when the RT-10 is connected to an MC-12 or MC-8
Digital Controller. When no setting is indicated, any setting can be selected.
Setup Menus
Possible Settings
• Off
• On
• Dolby Digital `
• Dolby Digital PCM
• DTS `
• DTS PCM
• Down Sample On
• Down Sample Off `
• MPEG
• MPEG PCM `
• On `
• Off
• 2ch Area
• Multi-ch Area `
• CD Area
. . . Audio1 continues on page 3-12
3-11
