Trotec PAC FT 2600 Portable air conditioner
The PAC FT 2600 portable room air conditioner comes with an infrared remote control and an air outlet
hose with a flat nozzle.The unit's primary function is to air condition rooms. It also filters and
dehumidifies the air, thus creating a comfortable climate in the room.
Safety Instructions
Please make sure that you follow the below safety instructions:
The unit is not suitable for outdoor operation
•
Do not set up or operate the unit in rooms susceptible to explosions
•
Ensure that the unit is set up at a safe distance from flammable materials
•
Do not set up or operate the unit if the atmosphere is contaminated by oil, sulphur or salt
•
Do not set the unit near curtains, drapes or blinds. Minimum distance of 50cm
•
Ensure that the air conditioners intake and outlet openings are always clear of foreign objects
•
Ensure that the air conditioner is securely placed on a level surface
•
The unit may only be operated in an upright position
•
Do not insert foreign objects into the air intake or outlet openings
•
Do not place any heavy or warm objects on top of the unit
•
Do not expose the unit to direct streams of water
•
Operate the unit only within its permissible operating ranges. Pay attention to the surrounding temperatures
•
This unit may only be connected to a correctly installed, grounded and fused plug socket. 230V / 50Hz, fuse 10A
•
When unplugging the unit, do not pull the power cord too forcefully or bend it too much. This may result in damage to
•
the cable
Do not move the unit while in operation. Wait at least 5 minutes before starting the unit after it has been moved. This
•
protects the unit from damage
Switch the unit off by pressing the power button. Do not switch the unit off by unplugging the power cord
•
Do not transport the unit during operation
•
Do not place the unit on its side
•
Protect all electrical cables from being damaged
•
Make sure that all extension cables are suitable in terms of capacity, length and intended use
•
Do not lay any lines underneath the carpet
•
Never operate the unit without its air filters
•
Never aim the air current directly at people
•
Never open the unit housing. This may cause an electric shock
•
Work on the cooling system and on the electrical equipment may only be performed by an authorised service centre
•
Operation/handling which does not comply with these instructions are prohibited
Control Panel
1. Power – Use this button to switch the unit on and off
2. Mode – This button is used to select the desired operating mode. There are three operating modes available which are:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trotec PAC FT 2600
Summary of Contents for Trotec PAC FT 2600
- Page 1 Trotec PAC FT 2600 Portable air conditioner The PAC FT 2600 portable room air conditioner comes with an infrared remote control and an air outlet hose with a flat nozzle.The unit’s primary function is to air condition rooms. It also filters and dehumidifies the air, thus creating a comfortable climate in the room.
-
Page 2: Prior To Initial Operation
Cooling mode – The unit cools the room to the set temperature, which can be set between 16°C and 32°C. • The fan speed can be freely selected 3. Dehumidification mode – The unit dehumidifies the room. The temperature can be set between 16°C and 32°C. The fan speed is preset to med and can not be changed 4. -
Page 3: Recommendations For Optimum Unit Operation
Recommendations for optimum unit operation 1. In case of direct sunlight, make sure to close all curtains and blinds 2. Keep doors and windows closed during operation Expelling warm air During cooling mode, the unit generates warm air. This air must be expelled from the room being cooled to retain the cooling effect. -
Page 4: Troubleshooting
How to set the unit to switch on automatically KEEP IN MIND: The unit will switch on with the most recently made settings. If you want different setting, you must switch the unit on, make the changes and then switch the unit off again. 1. - Page 5 Are all other electrical Check current and wait for the Power failure components working? unit to start again Defective power fuse / main Are all currents for lighting Replace power fuse / switch switch is off functional? on main switch Maintenance is required by an Are all other electrical Power supply line is damaged...
-
Page 6: London Cool Air Conditioner Rental And Sales
The air flap is not opened Check the position of the air Open the air flap as wide as wide enough flap possible Remote-controlled batteries Does the button function work Replace batteries / reduced are dead or the transmission at a distance of approx. 3m? distance or change location distance is too far The unit does not respond...
