Chapter 3: BIOS Setup
IR Device
This section is used to configure the IR device.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
IR Device
[Disabled]
Serial Port
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.

Parallel Port Configuration

This section is used to configure the parallel port.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Parallel Port
Enables or disables the parallel port.
Change Settings
Selects an optimal setting for the Super IO device.
Device Mode
Configures the operating mode of the parallel port. The options are Standard
Parallel Port Mode, EPP Mode, ECP Mode, EPP Mode & ECP Mode.
33
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=7;
Change Settings [Auto]
Device Mode [Standard Parallel ...]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Enable or Disable Parallel Port
(LPT/LPTE)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PEAK 886VL2 User Manual
