Chapter 2: Jumpers and Connectors

Jumpers

CMOS Connector

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP7
1 3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Settings
Normal
Clear CMOS
Definition
NC
RTCRST#
GND

AT/ATX Pin Header

Connector type: 1x3 3-pin header, 2.00mm pitch
Connector location: JP4
1 3
Pin
1-2 On
2-3 On
1-2 On: default
Pin
1
2
3
8
Settings
ATX
AT
Definition
AT_PWRBT#
PCH PWRBT#
EXTAL PWRBT#
